Elation ACL 360 MATRIX User Manual page 19

DMX Channel Values / Functions Version 1 (115 DMX Channels)
Specifications are subject to change without any prior written notice.
*Pixel control position depends on the specific Pan/Tilt position of the head.
MODE / CHANNEL
BASIC STAND EXTEND
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
ELATION© ACL 360 MATRIX™
VALUE
*RED - LED 3
0-255 0 to 100%
*GREEN - LED 3
0-255 0 to 100%
*BLUE - LED 3
0-255 0 to 100%
*WHITE - LED 3
0-255 0 to 100%
*RED - LED 4
0-255 0 to 100%
*GREEN - LED 4
0-255 0 to 100%
*BLUE - LED 4
0-255 0 to 100%
*WHITE - LED 4
0-255 0 to 100%
*RED - LED 5
0-255 0 to 100%
*GREEN - LED 5
0-255 0 to 100%
*BLUE - LED 5
0-255 0 to 100%
*WHITE - LED 5
0-255 0 to 100%
*RED - LED 6
0-255 0 to 100%
*GREEN - LED 6
0-255 0 to 100%
*BLUE - LED 6
0-255 0 to 100%
*WHITE - LED 6
0-255 0 to 100%
*RED - LED 7
0-255 0 to 100%
*GREEN - LED 7
0-255 0 to 100%
*BLUE - LED 7
0-255 0 to 100%
*WHITE - LED 7
0-255 0 to 100%
19
w w w . e l a t i o n l i g h t i n g . c o m
FUNCTION
ACL 360 MATRIX™ User Manual Ver 1
