Elation ACL 360 MATRIX User Manual page 14

Specifications and features are subject to change without any prior written notice.
MAIN MENU SUB MENU
Receive
Set DMX Address
User Mode
Edit A
User Mode
Edit B
Edit C
Status
Fixture ID
Function
Fan. Set
ProtocolSet
Net Switch
LCD. Set
Dim Curve
Temp. C/F
Init. Effect
Disp. Set
DFSE
Time. Info
Temp. Info
Information
Error. Info
Model. Info
Software Version
Error Info
w w w . e l a t i o n l i g h t i n g . c o m
ELATION© ACL 360 MATRIX™
S Y S T E M M E N U
OPTIONS / VALUES
(Default Settings in BOLD)
A001~AXXX
Standard, Basic, Extend, User A, User B, User C
Max. Chan
:
Fade Time
Remote Add ON/OFF
NoDMX Mode Hold / Auto / Blackout
Pan Invert ON/OFF
TiltInvert ON/OFF
Pan Degree
630/540
Feedback ON/OFF
Move. Spd Speed 1 ~ 4
OFF, 01M~99M,
Stand By
15M
ServicePIN PIN=XXX
RDM PID XXXXX
UnitIPAddr XXX.XXX.XXX.XXX.
Universe 000-255
Auto, High, Low
ArtNet, Kling-Net
ON/OFF
Backlight 02~60m 05m
FlipDisplay ON/OFF
Key Lock ON/OFF
Disp Flash ON/OFF
Standard, Stage, TV, Architectur, Theatre
Celsius/Fahrenheit
PAN =XXX
Chan. Value PAN...
Slave Set
Slave 1, Slave 2, Slave 3
Auto.Pro Alone, Master
ON/OFF
Current XXXX (Hours)
Total Time XXXX (Hours)
Last Clear XXXX (Hours)
Timer PIN PIN= 066
Clean Last ON / OFF
Head Temp.
XXX C° / F °
ACL 360 Bar
1U01: ≥V1.12
2U01: ≥V1.06
3U01: ≥V1.12
Error Record 1 ~ Error Record 10
14
DESCRIPTION
DMX Address Setting
Set DMX Channel Mode
Edit User Defined
Channel Assignments
Address Via DMX
Fucntion If NO DMX Detected
Pan Reverse Movement
Tilt Reverse Movement
Pan Degree Select
Movement Feedback
Movement Mode Select
Stand By Mode
Service PIN 050
RDM PID Code
Enter Fixture's IP Address
Enter Universe Number
Set Head Fan Speed
Fans Speed Select
Activate NET OUT Port.
LCD Backlight Shut Off Time
Flip Display 180º
Control Buttons Key Lock
Display flashes when NO DMX
Set Dimmer Curve Mode
Initial Effect Position
Value of each Channel Displayed
Set Slave Mode Preset
Set Auto Program Mode
Restore Factory Settings
Fixture Run Time From Power ON
Fixture Total Run Time
Clear Fixture Last Run Time
Enter PIN to Acess Clear Last. Menu
Reset Fixture Last Run Time
Temperature in Fixture Head
Reset Error Message
Display Model Name
Software Versions
Pan....
ACL 360 MATRIX™ User Manual Ver 1
