Sub-Zero 700-3 BASE Technical & Service Manual
  1. Manuals
  2. Brands
  3. Sub-Zero Manuals
  4. Refrigerator
  5. 700-3 BASE
  6. Technical & service manual

Sub-Zero 700-3 BASE Technical & Service Manual

Integrated series
Hide thumbs
Table of Contents

Advertisement

Quick Links

T T e e c c h h n n i i c c a a l l
S S e e r r v v i i c c e e M M a a n n u u a a l l
Integrated
3
Series
(700-
BASE)
SUB-ZERO FREEZER COMPANY INC.
2005 ALL RIGHTS RESERVED
JOB AID #3758424
(Revision B - December, 2005)

Advertisement

Table of Contents
loading

Related Manuals for Sub-Zero 700-3 BASE

Summary of Contents for Sub-Zero 700-3 BASE

  • Page 1 S S e e r r v v i i c c e e M M a a n n u u a a l l Integrated Series (700- BASE) SUB-ZERO FREEZER COMPANY INC. 2005 ALL RIGHTS RESERVED JOB AID #3758424 (Revision B - December, 2005)

  • Page 3: Section 1 - General Information

    General Information Integrated Series (700- BASE) SECTION 1 GENERAL INFORMATION #3758424 - Revision B - December, 2005...

  • Page 4: Introduction

    700-3 Base units. This information will enable the service techni- cian to troubleshoot and diagnose malfunctions, perform necessary repairs, and return a 700-3 Base unit to proper operational status.

  • Page 5: Table Of Contents

    General Information Integrated Series (700- BASE) TABLE OF CONTENTS Page # Page # Section 1 - General Information Temperature Log Recall Mode ........3-22 Compartment Temperature History Only ....3-22 Introduction ............... 1-2 Compartment & Evaporator Temperature History ..3-23 Important Safety Information ..........
  • Page 6 General Information Integrated Series (700- BASE) Page # Page # Section 7 - Component Access and Removal Section 8 - Troubleshooting Guides Section Table of Contents ..........7-2 Troubleshooting Guides ............ 8-2 WARNINGS & CAUTIONS ..........7-2 How to Use the Error Code Troubleshooting Guide ..8-2 Exterior Cosmetic and Mechanical Components ..

  • Page 7: Warranty Information

    This information is now also stored under the cus- labor. tomer's last name. • Five year LIMITED SEALED SYSTEM warranty, NOTE: Sub-Zero still requests that you have the sealed system **parts only. model and serial number available whenever contact- ing the factory or parts distributor.

  • Page 8: Model Description

    General Information Integrated Series (700- BASE) MODEL DESCRIPTIONS This page briefly describes the Models 700BC-3, 700BCI-3, 700BF-3, 700BFI-3 and 700BR-3. Model 700BC-3 (Figure 1-2) Series, ombination, rd Design Build Upper Refrigerator (Combination Refrigerator / Freezer with Two Temperature Zone Zones - Upper Refrigerator over Freezer) (Overall Dimensions = 34”...

  • Page 9: Section 2 - Installation Information

    Installation Information Integrated Series (700- BASE) SECTION 2 INSTALLATION INFORMATION #3758424 - Revision B - December, 2005...

  • Page 10: Installation Considerations

    . NOTE: If additional installation information is needed, refer to the complete Installation Manual and/or installation video, or contact the Sub-Zero Technical Assistance Department. UNIT COULD TIP FORWARD UNDER CERTAIN LOAD CONDITIONS. FAILURE TO INSTALL ANTI-TIP COM- PONENTS AND EXTEND LEVELERS TO THE FLOOR ACCORDING TO INSTALLATION MANUAL COULD RESULT IN SERIOUS PERSONAL INJURY OR DEATH.

  • Page 11: Dual Unit Installation

    Installation Information Integrated Series (700- BASE) Rear levelers are adjusted at front of base by turning Phillips head adjusting rod, which engages rear leveler assembly. Turn rod clockwise to raise rear or counter- clockwise to lower it (See Figure 2-4). NOTE: Rear leveling legs will only move 1/16”...
  • Page 12 Installation Information Integrated Series (700- BASE) #3758424 - Revision B - December, 2005...

  • Page 13: Section 3 - Electronic Control System Information

    Electronic Control System Integrated Series (700- BASE) SECTION 3 ELECTRONIC CONTROL SYSTEM INFORMATION #3758424 - Revision B - December, 2005...

  • Page 14: Electronic Control Terminology & Component Descriptions

    Electronic Control System Integrated Series (700- BASE) ELECTRONIC CONTROL TERMINOLOGY & COMPONENT DESCRIPTIONS All 700-3 Series units utilize an electronic control system which monitors, regulates, controls and displays a variety of functions and operations in the appliance. The table below defines some of the basic electronic control system terminology. Term/Component Definition / Description Main Control Board ..……..……...

  • Page 15: Electronic Control System Overview

    Electronic Control System Integrated Series (700- BASE) ELECTRONIC CONTROL SYSTEM OVERVIEW This page contains the wiring schematic of the model 700BCI-3. Input operations for the electronic control system are performed at the control panel (located inside the upper drawer), with monitoring, regulating and controlling func- tions taking place at the main control board.

  • Page 16: Control Board Layout & Summary Table

    Electronic Control System Integrated Series (700- BASE) MAIN CONTROL BOARD LAYOUT AND SUMMARY TABLE Electrical connection points on the main control board are labeled alphanumerically. These labels correspond with the alphanumeric summary table, located on the wiring diagram. By referencing the summary table, it is possible to identify which components are connected at which points on the main control board.

  • Page 17: Control Panel Layout

    Electronic Control System Integrated Series (700- BASE) CONTROL PANEL LAYOUT NOTE: The LCD on the base units is not back lit. It will appear darker than the LCD on tall units. REFRIGERATOR SET-POINT DRAWER AJAR (Liquid Crystal Display) ADJUSTMENT KEYS ALARM ON/OFF KEY SERVICE UNIT...

  • Page 18: Basic Electronic Control Input Operations

    Electronic Control System Integrated Series (700- BASE) BASIC ELECTRONIC CONTROL INPUT OPERATIONS The following pages describe the basic input operations performed at A 700BCI-3 control panel (switching unit ON and OFF; adjusting set-point (temperature adjustment); switching ice maker system ON and OFF and enabling and disabling door ajar alarm feature.

  • Page 19: Icemaker System On/Off

    Electronic Control System Integrated Series (700- BASE) Icemaker System ON/OFF All units with icemakers are shipped with the icemaker system switched OFF. By pressing the ICE ON/OFF key on the control panel, power is allowed to the icemaker system, and “ICE” appears on the LCD (See Figure 3-9). To disable the icemaker system, press the ICE ON/OFF key again and “ICE”...

  • Page 20: Unique Electronic Control Input Operations

    Electronic Control System Integrated Series (700- BASE) UNIQUE ELECTRONIC CONTROL INPUT OPERATIONS The following pages describe unique electronic control input operations performed at the control panel that you would not expect a customer to perform every day. The following input operations described are Temperature Unit Selection Mode, Sabbath Mode, Showroom Mode, and Manual Freezer Evaporator Defrost.

  • Page 21: Showroom Mode

    Electronic Control System Integrated Series (700- BASE) Showroom Mode Showroom Mode was incorporated into the electronic control system so that units could be displayed in a showroom setting. When in Showroom Mode, all cooling functions are disabled, but the lighting system and LCD remain active.

  • Page 22: Functions Of Electronic Control System

    Electronic Control System Integrated Series (700- BASE) FUNCTIONS OF ELECTRONIC CONTROL SYSTEM The following few pages explain monitoring, regulating and controlling functions of the electronic control system. Display Zone Temperatures The temperature signals from the thermistors in the refrigerator and freezer compartments are monitored by the microprocessor and then displayed on the LCD.

  • Page 23: Regulate Freezer Zone Temperature (Bc/Bf)

    Electronic Control System Integrated Series (700- BASE) Regulate Freezer Zone Temperature (700BCI-3, 700BFI-3) When the thermistor in the freezer compartment reaches high off-set temperature, calling for cooling, the compres- sor and condenser fan are energized, but the evaporator fan is not allowed to run until the thermistor on the evapo- rator reaches 35°F (2°C).

  • Page 24: Regulate Refrigerator Zone Temperature (Bc)

    Electronic Control System Integrated Series (700- BASE) Regulate Refrigerator Zone Temperature (700BCI-3) When the thermistor in refrigerator compartment reaches high off-set temperature, calling for cooling, the refrigerator compartment fan is energized and microprocessor sends an 18 Volt pulse signal to the air baffle control to open, regardless of operational state of the compressor.
  • Page 25 Electronic Control System Integrated Series (700- BASE) Regulate Refrigerator Zone Temperature (700BR-3) When the thermistor in the refrigerator compartment reaches high off-set temperature, calling for cooling, the evapo- rator fan is energized, but the compressor and condenser fan are not allowed to run until the thermistor on the evap- orator reaches 38°F (3°C).
  • Page 26 Electronic Control System Integrated Series (700- BASE) Monitor and Control “Adaptive Defrost” (700BCI-3, 700BFI-3) Initially, the compressor will cycle-run for 12 hours, after which the microprocessor sends a signal to the defrost relay on the control board to close. This supplies power to the defrost heater, drain tube heater and fill tube heater. At the same time the compressor, condenser fan and evaporator fan are switched off.
  • Page 27 Electronic Control System Integrated Series (700- BASE) Monitor and Control Refrigerator Fan-Assisted, Off-Cycle Defrost (700BR-3) Temperature signals from refrigerator evaporator's thermistor’s are observed by the microprocessor. During off cycle defrost, if a refrigerator zone temperature reaches high offset (calling for cooling) before evaporator temperature rises to 38°F (3°C), no power will be supplied the the compressor.
  • Page 28 Electronic Control System Integrated Series (700- BASE) Monitor Compressor Run Duration, Displays If Service is Needed The microprocessor observes the state of the compressor relay to determine the length of compressor run time (See Figure 3-22). If the compressor runs 100% (Freezer = 6 hours, Refrigerator = 4 hours), an error code is logged (EC 40), and defrost will be initiated, but SERVICE will not flash.
  • Page 29 Electronic Control System Integrated Series (700- BASE) Monitor Icemaker System and Display If Service is Needed The microprocessor observes the power supplied to the icemaker water valve solenoid. If the solenoid is energized for more than 15 seconds, power to the icemaker system is disabled for 24 hours and an error code is logged (EC 30).

  • Page 30: Possible Error Indicators

    Electronic Control System Integrated Series (700- BASE) POSSIBLE ERROR INDICATORS The diagrams on this page illustration what a customers may see on LCD if a problem/error exists with the unit. NOTE: To clear indicators and error codes, problem must be corrected then press bell ON/OFF key for 15 seconds. SERVICE UNIT FREEZER...

  • Page 31: Troubleshooting Input Operations

    Electronic Control System Integrated Series (700- BASE) ELECTRONIC CONTROL TROUBLESHOOTING INPUT OPERATIONS The following few pages explain troubleshooting input operations performed at the control panel. The input opera- tions described are Diagnostic Mode, Manual Component Activation Mode and Temperature Log Recall. Diagnostic Mode Initiating Diagnostic Mode allows the Service Technician to observe real-time temperature readings from all thermis- tors without temperature averaging.

  • Page 32: Diagnostic Mode Indicators

    Electronic Control System Integrated Series (700- BASE) Diagnostic Mode Indicators If “EE” is observed in left display area during Diagnostic Mode, the thermistor in that location is open or shorted, or there is a break in that thermistor’s wiring (See Figure 3-36). SERVICE UNIT FREEZER...

  • Page 33: Manual Component Activation Mode

    Electronic Control System Integrated Series (700- BASE) If Error Codes are observed in Diagnostic Mode, a non-flashing SERVICE icon will appear on the LCD when Diagnostic Mode ends, indicating error codes are still stored (See Figure 3-39). To clear a non-flashing SERVICE icon and the error codes, the problem must be corrected and the unit must be ON, then the door ajar alarm bell ON/OFF key must be pressed and held for 15 seconds.

  • Page 34: Temperature Log Recall Mode

    Electronic Control System Integrated Series (700- BASE) Temperature Log Recall Mode The electronic control system is equipped with a temperature history data storage system. This system logs/stores the average temperature of each individual thermistor every two hours, along with any event indicators (explained later in this section), that may have occurred.

  • Page 35: Compartment & Evaporator Temperature History

    Electronic Control System Integrated Series (700- BASE) Initiate Temperature Log Recall Mode To View Compartment and Evaporator Temperature History - To view compartment and/or evaporator temperature history, begin with the unit ON and in Diagnostic Mode (See Figure 30- 46). While in Diagnostic Mode, toggle through the readings until the desired thermistor temperature is displayed on the LCD (See Figure 3-47).

  • Page 36: Temperature Log Event Indicators

    Electronic Control System Integrated Series (700- BASE) Temperature Log Event Indicators The diagrams below illustrate possible event indicators that may be observed while in Temperature Log Recall Mode. (See Figures 3-50 through 3-52 and Temperature Log Index Chart on next page)) UNIT FREEZER REFRIGERATOR...

  • Page 37: Temperature Log Index Chart

    Electronic Control System Integrated Series (700- BASE) Temperature Log Index Chart NOTE : The chart below applies to the hours in which the control has power. Temperature history data will only be stored when the control has 115V AC supplied to it. If power to the unit is interrupted, the average temperatures for that time period are stored with the event indicator.

  • Page 38: Service Input Operations

    Model Configuration Mode The main control board is used in several different models, so when a 700-3 Base Unit is manufactured, the main control board must be configured/programmed for the specific model it is used in by a series of key strokes at the control panel.

  • Page 39: Manual Entry Model Configuration Mode

    Manual Entry Model Configuration Mode Manual Entry Model Configuration Mode allows a Service Technician to verify a main control board in a 700-3 Base unit was configured correctly, and/or to reconfigure the main control board if a mistake was made during the configu- ration process.
  • Page 40 Electronic Control System Integrated Series (700- BASE) 3-28 #3758424 - Revision B - December, 2005...

  • Page 41: Section 4 - Sealed System Information

    Sealed System Information Integrated Series (700- BASE) SECTION 4 SEALED SYSTEM INFORMATION #3758424 - Revision B - December, 2005...

  • Page 42: Hfc-134A Refrigerant Service Information

    Sealed System Information Integrated Series (700- BASE) HFC-134a REFRIGERANT SERVICE INFORMATION The sealed systems contain HFC-134a refrigerant. This section provides some general rules for working with 134a, and explains procedures to be followed while servicing the sealed system. This is followed by diagrams which illus- trate sealed system operation, then model-specific refrigerant flow diagrams.

  • Page 43: Sealed System Repair Procedures

    Sealed System Information Integrated Series (700- BASE) 700-2 SERIES SEALED SYSTEM REPAIR PROCEDURES Problem Service Procedures Non-Operating, Inefficient, Capture refrigerant Noisy Compressor Replace Compressor Replace filter-drier Evacuate or sweep charge system Recharge system with Virgin 134a refrigerant. NOTE: To check for a non-operating compressor, a hard start kit can be used. High Side leak Capture refrigerant.

  • Page 44: Sealed System Operation

    Sealed System Information Integrated Series (700- BASE) SEALED SYSTEM OPERATION The six diagrams on these pages illustrate a basic sealed system. The components are listed in order of refrigerant flow, with an explanation of their fundamental role as part of a sealed system. Compressor (Figure 4-1) The compressor creates a high side and low side pressure dif-...
  • Page 45 Sealed System Information Integrated Series (700- BASE) Capillary Tube (& Heat Exchanger) (Figure 4-4) The warm liquid refrigerant travels through the long skinny capillary tube which is soldered to the suction line. (These two (EVAPORATOR SUMP) tubes soldered together create the heat exchanger.) As the warm liquid refrigerant travels through the capillary tube it...

  • Page 46: Sealed System Refrigerant Flow Diagrams

    Sealed System Information Integrated Series (700- BASE) SEALED SYSTEM REFRIGERANT FLOW DIAGRAM Heater Loop Evaporator Heat Exchanger Condenser Compressor High-Side Filter Drier Figure 4-1. Model 700BC/I-2 Refrigerant Flow Heater Loop Evaporator Heat Exchanger Condenser Compressor High-Side Filter Drier Figure 4-2. Model 700BR-2 Refrigerant Flow #3758424 - Revision B - December, 2005...
  • Page 47 Sealed System Information Integrated Series (700- BASE) Heater Loop Evaporator Heat Exchanger Condenser Compressor High-Side Filter Drier Figure 4-3. Model 700BF/I-2 Refrigerant Flow #3758424 - Revision B - December, 2005...
  • Page 48 Sealed System Information Integrated Series (700- BASE) #3758424 - Revision B - December, 2005...

  • Page 49: Section 5 - Air Flow & Fan Blade Spacing

    Airflow & Fan Blade Spacing Integrated Series (700- BASE) SECTION 5 AIRFLOW & FAN BLADE SPACING #3758424 - Revision B - December, 2005...
  • Page 50 Airflow & Fan Blade Spacing Integrated Series (700- BASE) AIRFLOW AND FAN BLADE SPACING DIAGRAMS REFRIGERATOR COMPARTMENT FAN BLADE HUB TO FAN BRACKET SPACING EVAPORATOR 13/16" ± 1/16" FAN BLADE HUB (20.64 mm ± 1.59 mm) TO FAN BRACKET Blade SPACING Clamp 11/16"...
  • Page 51 Airflow & Fan Blade Spacing Integrated Series (700- BASE) EVAPORATOR FAN BLADE HUB TO FAN BRACKET SPACING 11/16" ± 1/16" (17.46 mm ± 1.59 mm) Blade Clamp Back Bracket Figure 5-3. 700BF/I-3 Airflow and Fan Blade Spacing #3758424 - Revision B - December, 2005...
  • Page 52 Airflow & Fan Blade Spacing Integrated Series (700- BASE) #3758424 - Revision B - December, 2005...

  • Page 53: Section 6 - Icemaker Information

    Icemaker Information Integrated Series (700- BASE) SECTION 6 ICEMAKER INFORMATION #3758424 - Revision B - December, 2005...

  • Page 54: Modular Icemaker

    Icemaker Information Integrated Series (700- BASE) MODULAR ICEMAKER All 700-2 Series units utilize a “modular icemaker.” The icemaker operation is not complex, however, an understanding of its cycle of operation is necessary in order for a serviceman to make a proper diagnosis. Modular Icemaker Operation When the icemaker thermostat has sensed temperatures of 17°F, the thermostat closes.

  • Page 55: Additional Icemaker Operation Notes

    Icemaker Information Integrated Series (700- BASE) Additional Icemaker Operation Notes NOTE 1: The ICE ON/OFF key at the control panel activates the icemaker system. If “ICE” is not displayed on the LCD, the icemaker system is OFF. NOTE 2: To allow ice to freeze fully and reduce effects of low water pressure, the electronic control system disables the icemaker system for 45 minutes after each ice harvest.

  • Page 56: Modular Icemaker Test Procedures

    Icemaker Information Integrated Series (700- BASE) MODULAR ICEMAKER TEST PROCEDURES Perform the following tests if the icemaker is thought to be defective. See Figure 6-3 for icemaker test port loca- tions. Test 1 through 5 are performed with power supplied to the icemaker, so read the “WARNING” below and the “additional Ice Production Notes”...

  • Page 57: Water Fill Adjustment

    Icemaker Information Integrated Series (700- BASE) WATER FILL ADJUSTMENT The water valve should energize for approximately 7.5 seconds. This should supply 140cc. of water to the ice- maker, or approximately 4.75oz. If this is not the case, the fill amount can be adjusted with the water fill adjust- ment screw.
  • Page 58 Icemaker Information Integrated Series (700- BASE) #3758424 - Revision B - December, 2005...

  • Page 59: Section 7 - Component Access And Removal

    Component Access/Removal Integrated Series (700- BASE) SECTION 7 COMPONENT ACCESS AND REMOVAL #3758424 - Revision B - December, 2005...
  • Page 60 Component Access/Removal Integrated Series (700- BASE) COMPONENT ACCESS AND REMOVAL This section explains how to adjust, access and/or remove 700-3 Series base unit components. If different models have similar procedures, they are grouped together under the appropriate heading. The units covered in the proce- dures are listed between brackets after the heading.

  • Page 61: Exterior Cosmetic And Mechanical Components

    Component Access/Removal Integrated Series (700- BASE) EXTERIOR COSMETIC AND MECHANICAL COMPONENTS Kickplate/Grille Removal (All Base Units) The kickplate/grille is attached by four screws passing through the kickplate into adjustable kickplate brackets. NOTE: Because drawer panels may extend down in front of the kickplate/grille, it may be necessary to Kickplate/Grille remove the bottom drawer to gain access.

  • Page 62: Side Trim Molding Strip (All Base Units)

    Component Access/Removal Integrated Series (700- BASE) Side Trim Molding Strip Removal (All Base Units) Unit to Cabinet Side trim molding strips are held in place by two unit-to- Bracket cabinet brackets which are attached to the sides of the cabinet. Side Molding NOTE: Removing the drawers first will make this task...

  • Page 63: Interior Cosmetic, Mechanical Components

    Component Access/Removal Integrated Series (700- BASE) INTERIOR COSMETIC AND MECHANICAL Screws COMPONENTS Control Panel Assembly Removal (All Base Units) The control panel assembly is attached inside top draw- er assembly with three screws. Control Panel Assy To remove control panel assembly (See Figure 7-6): 1.

  • Page 64: Mullion Divider (700Bc/I-3 )

    Component Access/Removal Integrated Series (700- BASE) Mullion Divider Removal (700BC/I-3 Only) The mullion divider assembly is set between the two drawer areas. To remove a mullion divider (See Figure 7-9): Mullion Divider 1. Remove display wire harness from wire clip. 2.

  • Page 65: Drawer Slide Assembly (All Base Units)

    Component Access/Removal Integrated Series (700- BASE) Drawer Slide Assembly Removal (All Base Units) White Thread Pin There are four drawer slide assemblies, two on each side wall. Drawer slide assemblies are attached to side walls with Allen-head screws passing through the draw- er slide bracket into blind threaded inserts.

  • Page 66: Refrigerator Compartment Thermistor (700Bc/I-3)

    Component Access/Removal Integrated Series (700- BASE) Refrigerator Fan Baffle and Cold Plate Removal Stand-off (700BR-3 Only) Screws pass though the refrigerator fan shroud into rivnuts that are attached to the refrigerator cold plate. Behind the baffle, Screws pass though the cold plate into screw grommet/stand-offs.

  • Page 67: Refrigerator Compartment Thermistor (700Br-3)

    Component Access/Removal Integrated Series (700- BASE) Refrigerator Compartment Thermistor Removal Left False Wall Right False Wall (700BR-3 Only) The refrigerator compartment thermistor passes through a hole in the left false wall from behind, and is attached to the front of the false wall with a screw. To remove the refrigerator compartment thermistor (See Figure 7-18): Switches...

  • Page 68: Sump Cover Assembly (700Bci-3, 700Bfi-3)

    Component Access/Removal Integrated Series (700- BASE) Icemaker Assembly Removal Mounting Screw (700BC/I-3, 700BFI-3 Only) The icemaker assembly is attached at right rear of lower compartment with two screws at top and one screw at bottom that pass through the air duct into screw grommet/stand-offs to hold assembly in place.
  • Page 69 Component Access/Removal Integrated Series (700- BASE) Lower Air Duct Removal (700BC/I-3 Only) Baffle Mount Screws pass though the lower air duct into screw grom- met/stand-offs and a grounding bracket to secure the Baffle Control duct to the back wall. NOTE: Both lower drawer slides must be removed first. To remove the lower air duct (See Figure 7-22): 1.
  • Page 70 Component Access/Removal Integrated Series (700- BASE) Freezer Light Switchs and Icemaker Switch Left Air Duct Main Air Duct Removal (700BF/I-3 Only) The light switches and fan switch are inserted into square holes in the main air duct. NOTE: The sump cover assembly must be removed first.

  • Page 71: Defrost Terminator (700Bc/I-3, 700Bf/I-3)

    Component Access/Removal Integrated Series (700- BASE) Evaporator Thermistor Removal (700BC/I-3, 700BFI-3 Only) Evaporator Thermistor A cable tie holds the evaporator thermistor to the third elbow down on the right side of the evaporator. To remove the evaporator thermistor (See Figure 7-25): 1.

  • Page 72: Control Board Assembly (700Bc/I-3, 700Bf/I-3)

    Component Access/Removal Integrated Series (700- BASE) Control Board Assembly Removal (700BC/I-3, 700BFI-3 Only) Control Board Assembly The control board assembly sets in the right side of sump. Flanges and grooves on the sides of control board assembly help to locate it. To remove the control board assembly (See Figure 7- 28): 1.

  • Page 73: Compressor Area Mechanical Components

    Component Access/Removal Integrated Series (700- BASE) COMPRESSOR AREA MECHANICAL Screw COMPONENTS Main Control Board (700BR-3 Only) The main control board is attached to the inside of the control housing assembly with screws. The control housing assembly is attached to the unit tray at the front right corner.
  • Page 74 Component Access/Removal Integrated Series (700- BASE) Icemaker Water Valve Removal (700BCI-3, 700BFI-3 Only, Prior to Serial #2421189) Screw The icemaker water valve assembly is attached to the valve bracket, located on right side of compressor area. A screw passing through a key-hole slot in valve assembly secures the valve to the valve bracket.
  • Page 75 Component Access/Removal Integrated Series (700- BASE) Icemaker Water Valve Removal (700BCI-3, 700BFI-3 Only, Starting w/ith Serial Screw #2421189) The icemaker water valve assembly is located at the right side of the compressor area, and is attached to the valve bracket with screws. NOTE: Before accessing the icemaker water valve, turn off the water supply to the unit.

  • Page 76: Condenser Fan Assembly (All Base Units)

    Component Access/Removal Integrated Series (700- BASE) Condenser Fan Assembly Removal (All Base Units) Screw The condenser fan shroud sets on pegs protruding from unit tray, with two screws at top securing it to the con- denser. The condenser fan is mounted to the condens- er fan shroud with three fan mounting brackets that are hooked into grommeted holes in the fan shroud.
  • Page 77 Component Access/Removal Integrated Series (700- BASE) Drain Tube Heater Removal (700BC/I-3, 700BF/I-3 Only) Screw The electrical connections for the drain tube heater are located at the back of the compressor area with the braided heater leads entering the sump drain tube from the compressor area.

  • Page 78: Sealed System Components

    Component Access/Removal Integrated Series (700- BASE) SEALED SYSTEM COMPONENTS Screw NOTE: When entering the sealed system, always use solder-on process valves. Do NOT use bolt-on process valves as they are prone to leak. NOTE: Whenever servicing the sealed system, the high-side filter-drier must be replaced.
  • Page 79 Component Access/Removal Integrated Series (700- BASE) Compressor Removal (All Base Units) Screw The compressor has four rubber compressor grommets inserted into its base. Cylindrical metal spacers are placed over threaded studs that are press fit to the unit tray. The compressor grommets fit over the spacers and a washer sets on top of the grommet and spacer.
  • Page 80 Component Access/Removal Integrated Series (700- BASE) Condenser Removal (All Base Units) Screw The condenser is secured to the unit tray by four rivets that pass up through the unit tray into the condenser side brackets. NOTE: Before attempting to remove the condenser, evacuate the refrigerant from the sealed system.
  • Page 81 Component Access/Removal Integrated Series (700- BASE) Evaporator / Heat Exchanger Assembly Removal (700BC/I-3, 700BF/I-3 Only) The evaporator / heat exchanger assembly was installed into the unit by inserting the heat exchanger down through the hole at top left front of sump. As the heat exchanger is fed through the hole, the side brack- ets of the evaporator slide down into channels in sump and control board enclosure.
  • Page 82 Component Access/Removal Integrated Series (700- BASE) Evaporator Removal (700BR-3 Only) The evaporator is attached to the rear walls of the com- partments with screws. NOTE: Before attempting to remove the evaporator, evacuate the refrigerant from the sealed system. To remove the refrigerator evaporator (See Figure 7- 54): 1.

  • Page 83: Section 8 - Troubleshooting Guides

    Troubleshooting Guides Integrated Series (700- BASE) SECTION 8 TROUBLESHOOTING GUIDES #3758424 - Revision B - December, 2005...

  • Page 84: How To Use The Error Code Troubleshooting Guide

    Troubleshooting Guides Integrated Series (700- BASE) TROUBLESHOOTING GUIDES This section of the manual contains: • The Error Code Table and the Error Code Troubleshooting Guide. • The General Troubleshooting Guide, which covers all problems that a 700-3 Series Base unit may experience. •...

  • Page 85: Error Code Troubleshooting Guide

    Troubleshooting Guides Integrated Series (700- BASE) ERROR CODE TROUBLESHOOTING GUIDE TEST / ACTION A. If “EE” for refrigerator compartment was displayed and “SERVICE” flashing, check the following: Thermistor electrical connections and continuity from thermistor to J5 on control board. Reconnect / repair. Resistance of thermistor - 30,000 to 33,000 ohms at 32°F.
  • Page 86 Troubleshooting Guides Integrated Series (700- BASE) ERROR CODE TROUBLESHOOTING GUIDE TEST / ACTION A. With cold evap. (< 10°F), initiate Manual Defrost, then initiate Diagnostic Mode (press UNIT ON/OFF key every 20 seconds to keep in Diagnostic Mode) and observe evap. temp. If temp. exceeds 45°F and defrost lasts longer then 5 minutes, error code is false.
  • Page 87 Troubleshooting Guides Integrated Series (700- BASE) ERROR CODE TROUBLESHOOTING GUIDE TEST / ACTION A. If Error Code 07, 20, 21, 22, 23, or 24 is also displayed during Diagnostic Mode, see Test/Actions under that code. B. Check for obstructions to freezer drawer closing, including drawer closer position. Remove obstruction/Trip drawer closer forward.

  • Page 88: How To Use The General Troubleshooting Guide

    Troubleshooting Guides Integrated Series (700- BASE) HOW TO USE THE GENERAL TROUBLESHOOTING GUIDE • The table on page 8-6 indicate how the General Trouble Shooting Guide is arranged. • Identify the description of the problem that the unit is experiencing from the table. •...

  • Page 89: General Troubleshooting Guide

    Troubleshooting Guides Integrated Series (700- BASE) GENERAL TROUBLESHOOTING GUIDE TABLE OF CONTENTS Page # “EE” Displayed in place of Freezer Temperature with “SERVICE” Flashing ............ 8-7 “EE” Displayed in place of Refrigerator Temperature with “SERVICE” Flashing ..........8-7 Warm or Normal Temperatures Displayed with “SERVICE” Alone Flashing ............ 8-7 Warm or Normal Temperatures Displayed with non-flashing “SERVICE”...

  • Page 90: (700- 3 Base) Series

    Troubleshooting Guides Integrated Series (700- BASE) PROBLEM POSSIBLE CAUSE TEST / ACTION A. “EE” Displayed in place of Freezer Compartment Thermistor Check freezer compartment thermistor elec- Freezer Temperature with Disconnected, Shorted, or misread trical connections from thermistor to control “SERVICE” Flashing board.
  • Page 91 Troubleshooting Guides Integrated Series (700- BASE) PROBLEM POSSIBLE CAUSE TEST / ACTION (Continued) Refrigerator Compartment Fan Fault F. Warm Refrigerator a. Fan blade obstructed or out of position a. Move obstruction or reposition blade. Temperatures, “SERVICE” b. Evaporator fan motor disconnected b.

  • Page 92: Warm Freezer Temperatures, "Service" Not Displayed Or Flashing

    Troubleshooting Guides Integrated Series (700- BASE) PROBLEM POSSIBLE CAUSE TEST / ACTION G.) Warm Freezer Temperatures, No Power to Unit Check power to unit, plug unit in or switch “SERVICE” not displayed or supply circuit breaker ON. Flashing Unit Switched OFF Check for “OFF”...
  • Page 93 Troubleshooting Guides Integrated Series (700- BASE) PROBLEM POSSIBLE CAUSE TEST / ACTION (Continued) Evaporator Heavily Frosted G.) Warm Freezer Temperatures, a. Drawer ajar a. See Drawer Ajar above. “SERVICE” not displayed or b. Evaporator fan fault b. See Evaporator Fan Fault above. Flashing c.

  • Page 94: Product Temperature 10° Or More Colder Than Displayed Temperature

    Troubleshooting Guides Integrated Series (700- BASE) PROBLEM POSSIBLE CAUSE TEST / ACTION H. Product Temperature 10° or Compartment Thermistor Misread Check resistance of compartment thermistor More Colder than Displayed for 30,000 to 33,000 ohms at 32°F. Replace Temperature if defective. I.

  • Page 95: Icemaker Produces Too Much Ice

    Troubleshooting Guides Integrated Series (700- BASE) PROBLEM POSSIBLE CAUSE TEST / ACTION (Continued) Icemaker System Fault Press ICE key to OFF, then to ON to bypass 45 minute dwell. Then, depress icemaker switch & K. No Ice, "ICE" Displayed, but manually start icemaker with jumper between not Flashing ports “T”...

  • Page 96: Water Or Clump Of Ice In Ice Bucket

    Troubleshooting Guides Integrated Series (700- BASE) PROBLEM POSSIBLE CAUSE TEST / ACTION P. Water or Clump of Ice in Ice Icemaker Not Level Check level of icemaker, level if needed. Bucket High Fill Adjustment on Icemaker Check for 100-110 cc. fill (3.5-3.75 oz.). Turn adjusting screw clockwise to decrease.

  • Page 97: Drawers Not Able To Close Completely

    Troubleshooting Guides Integrated Series (700- BASE) PROBLEM POSSIBLE CAUSE TEST / ACTION S. Lights Stay ON when Door or Drawer Ajar Drawers Closed - (May be Accompanied by /Drawer a. Food product obstruction a. Move obstruction. Ajar Alarm Bell) b. Drawer closer tripped backwards b.

  • Page 98: Sealed System Troubleshooting / Diagnostic Tables

    Troubleshooting Guides Integrated Series (700- BASE) SEALED SYSTEM TROUBLESHOOTING / DIAGNOSTICS TABLES Before tapping into the sealed system to check pressures, see General Troubleshooting Guide, taking note of prob- lems “A” through “J”, and if applicable, be sure to reference the “Pointers” in the first column. By initiating Diagnostic Mode and observing evaporator temperatures, it may be determined unnecessary to tap the sealed system.

  • Page 99: Temperature/Pressure Table

    Troubleshooting Guides Integrated Series (700- BASE) EVAPORATOR TEMPERATURE / SEALED SYSTEM LOW-SIDE PRESSURE CORRELATION NOTE: The temperature/pressure table at right Temp °F Pressure is for reference only. A unit's temperature/pres- sure correlation may differ from those listed due 10” Vac to: variations in evaporator thermistor location, 7”...

  • Page 100: Membrane Switch / Ribbon Cable Test

    Troubleshooting Guides Integrated Series (700- BASE) BASE UNIT MEMBRANE SWITCH / RIBBON CABLE TEST If the integrity of a Base Unit control panel assembly is suspect, continuity tests should be performed at the mem- brane switch ribbon cable terminal housing. Begin by removing the control panel assembly from the unit and place it on a solid surface.

  • Page 101: Technical Data

    Technical Data Integrated Series (700- BASE) SECTION 9 TECHNICAL DATA #3758424 - Revision B - December, 2005...

  • Page 102: Model 700Bc/I-3

    Technical Data Integrated Series (700- BASE) Model 700BC/I-3 FREEZER CHARGE (R-134a Refrigerant) NOTE: Always check serial tag for exact charge 6 oz. NORMAL OPERATING PRESSURES Low Side 3” vacuum to 2 psi High Side 90 psi to 120 psi COMPRESSOR NOTE: Always check current parts price list for possible substitutions.

  • Page 103: Model 700Br-3

    Technical Data Integrated Series (700- BASE) Model 700BR-3 FREEZER CHARGE (R-134a Refrigerant) NOTE: Always check serial tag for exact charge 3.75 oz. NORMAL OPERATING PRESSURES Low Side X” vacuum to X psi High Side XX psi to XXX psi COMPRESSOR NOTE: Always check current parts price list for possible substitutions.

  • Page 104: Model 700Bf/I-3

    Technical Data Integrated Series (700- BASE) Model 700BF/I-3 FREEZER CHARGE (R-134a Refrigerant) NOTE: Always check serial tag for exact charge 6 oz. NORMAL OPERATING PRESSURES Low Side 3” vacuum to 2 psi High Side 90 psi to 120 psi COMPRESSOR NOTE: Always check current parts price list for possible substitutions.

  • Page 105: Section 10 - Wiring Diagrams

    Wire Diagrams & Schematics Integrated Series (700- BASE) SECTION 10 WIRING DIAGRAMS AND SCHEMATICS 10-1 #3758424 - Revision B - December, 2005...
  • Page 106 Wire Diagrams & Schematics Integrated Series (700- BASE) WIRING DIAGRAM MODEL 700 BC/BCI-3 (Prior to Serial #2300444) WHITE GREEN/ YELLOW STRIPE GRAY ORANGE PIN 1 PIN 1 WHITE ORANGE YELLOW DISPLAY BOARD REF LIGHT SWITCH REF (TOP) DRAWER LIGHT REF FAN MOTOR GREEN W/YELLOW STRIPE WHITE...
  • Page 107 Wire Diagrams & Schematics Integrated Series (700- BASE) WIRING SCHEMATIC MODEL 700 BC/BCI-3 -This wiring information is provided for use by qualified service personnel only. -Disconnect appliance from electrical supply before beginning service. (Prior to Serial #2300444) -Be sure all grounding devices are connected when service is complete.
  • Page 108 Wire Diagrams & Schematics Integrated Series (700- BASE) WIRING DIAGRAM MODEL 700 BC/BCI-3 (Starting with Serial #2300444) WHITE GREEN/ YELLOW STRIPE GRAY ORANGE PIN 1 PIN 1 WHITE ORANGE YELLOW DISPLAY BOARD REF LIGHT SWITCH REF (TOP) DRAWER LIGHT REF FAN MOTOR GREEN W/YELLOW STRIPE WHITE...

  • Page 109: Wiring Schematic

    Wire Diagrams & Schematics Integrated Series (700- BASE) WIRING SCHEMATIC MODEL 700 BC/BCI-3 -This wiring information is provided for use by qualified service personnel only. -Disconnect appliance from electrical supply before beginning service. -Be sure all grounding devices are connected when (Starting with Serial #2300444) service is complete.
  • Page 110 Wire Diagrams & Schematics Integrated Series (700- BASE) WIRING DIAGRAM MODEL 700BR-3 GREEN/ YELLOW STRIPE ORANGE PIN 1 PIN 1 WHITE ORANGE YELLOW DISPLAY BOARD UPPER SWITCH LIGHT UPPER DRAWER LIGHT REF FAN MOTOR GREEN W/YELLOW STRIPE WHITE ORANGE/BLACK LOWER DRAWER LIGHT LOWER SWITCH LIGHT...
  • Page 111 Wire Diagrams & Schematics Integrated Series (700- BASE) WIRING SCHEMATIC -This wiring information is provided for use by qualified MODEL 700BR-3 service personnel only. -Disconnect appliance from electrical supply before beginning service. -Be sure all grounding devices are connected when service is complete.
  • Page 112 Wire Diagrams & Schematics Integrated Series (700- BASE) WIRING DIAGRAM MODEL 700 BF/BFI-3 ORANGE PIN 1 PIN 1 WHITE ORANGE YELLOW DISPLAY BOARD UPPER LIGHT UPPER SWITCH DRAWER LIGHT GREEN W/YELLOW STRIPE WHITE ORANGE/BLACK LOWER DRAWER LIGHT ICEMAKER SWITCH LOWER LIGHT SWITCH ORNG/BLK THERMAL...
  • Page 113 Wire Diagrams & Schematics Integrated Series (700- BASE) WIRING SCHEMATIC -This wiring information is provided for use by qualified service personnel only. MODEL 700 BF/BFI-3 -Disconnect appliance from electrical supply before beginning service. -Be sure all grounding devices are connected when service is complete.
  • Page 114 Wire Diagrams & Schematics Integrated Series (700- BASE) 10-10 #3758424 - Revision B - December, 2005...

Table of Contents
