Sub-Zero 700-3 BASE Technical & Service Manual page 111

Integrated
WIRING SCHEMATIC
MODEL 700BR-3
LOW VOLTAGE SCHEMATIC
DISPLAY
THERMISTOR UPPER DRAWER/REFRIGERATOR
HIGH VOLTAGE SCHEMATIC
ORANGE
J2
PIN 1
P4
P3
MAIN BOARD
P1
P2
PIN 1
J6
J4
PIN 1
PIN 1
PIN 1
J5
ORANGE W/BLACK STRIPE
ORANGE
3 Series
(700- BASE)
MEMBRANE KEYPAD
J2
PIN 1
DISPLAY BOARD
PIN 1
J3
THERMISTOR EVAPORATOR
115 VOLTS
60 CYCLES
L1
NEUTRAL
WHITE
RED
WHITE
BLACK
PURPLE
J3
ORANGE
UPPER
LIGHT SWITCH
LOWER
LIGHT SWITCH
10-7
Wire Diagrams & Schematics
-This wiring information is provided for use by qualified
service personnel only.
-Disconnect appliance from electrical supply before
beginning service.
-Be sure all grounding devices are connected when
service is complete.
-Failure to observe the above warnings may result in
severe electrical shock.
J6
BLUE
ORANGE
YELLOW
RED
WHITE
BLACK
ORANGE W/YELLOW STRIPE
BLUE W/YELLOW STRIPE
J5
BLUE W/BLACK STRIPE
BLUE W/BLACK STRIPE
M
REF FAN MOTOR
OVERLOAD
PROTECTOR COMPRESSOR
M
M
CONDENSER FAN
UPPER DRAWER LIGHT
LOWER DRAWER LIGHT
#3758424 - Revision B - December, 2005
J2
PIN 1
P4
P3
MAIN BOARD
P1
P2
PIN 1
J4
PIN 1
PIN 1
PIN 1
J3
WHITE
RUNNING
CAPACITOR
(WHEN
USED)
COMPRESSOR
STARTING
RELAY
P/N 3758575 REV A
