Planning Information

Integrated Model 700BR

Refrigerator Drawers

Seamless molding
Location of serial
number
Model 700BR
Magnetic drawer
gaskets
Front venting with
removable kickplate
The Sub-Zero Model 700BR integrated
design accepts custom wood or stainless
steel drawer panels. Stainless steel
panels and handles are available as sales
accessories in three finishes—classic,
platinum and carbon.
Dimensions in parentheses are in
millimeters unless otherwise specified.
11/06
These appliances are Star-K certified from the
factory to meet strict religious regulations in
conjunction with specific instructions found on
star-k.org. No extra wiring harness is required.
O
ne of the more popular models of the Integrated
line, this handy two drawer refrigeration system is a
must for large and small homes alike. It is a perfect
illustration of the concept of a refrigeration system
where you can place units where they make the most
sense. They can stand alone or work together with
other Sub-Zero models to satisfy anyone's needs.
Many homeowners are using them to supplement the
main Built-In unit that is installed in the home. With a
temperature range of 34˚F (1˚C) to 45˚F (7˚C), they are
perfect for beverages and vegetables in the island
application.
Removable crisper
cover
Electronic digital
control panel
Upper refrigerator
storage drawer
Lower refrigerator
storage drawer
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 700BR and is the answer not in the manual?

Questions and answers

Related Manuals for Sub-Zero 700BR

Summary of Contents for Sub-Zero 700BR

  • Page 1 They can stand alone or work together with other Sub-Zero models to satisfy anyone’s needs. Many homeowners are using them to supplement the main Built-In unit that is installed in the home. With a temperature range of 34˚F (1˚C) to 45˚F (7˚C), they are...

  • Page 2: Features

    Planning Information Integrated Model 700BR F E A T U R E S Drawer unit with refrigerator storage drawers Integrated design for "point-of-use" refriger- ation anywhere in the home Energy Star qualified Refrigeration system ensures the freshest food and energy efficiency Microprocessor offers precise temperature control ranging from 34˚F (1˚C) to 45˚F (7˚C)
  • Page 3 Dozen egg container with lid Drawer crisper cover with lid Dual installation heater kit Accessories are available through your Sub-Zero dealer. To obtain local dealer information, visit the Locator section of our website, subzero.com. Dimensions in parentheses are in millimeters unless otherwise specified.
  • Page 4 Location of Electrical * The depth of the Model 700BR is 24" (610) from the front of the unit to its back. Your design may necessitate moving the unit back, or cabinets forward to achieve a flush fit. This will require a minimum rough opening depth of 25"...
  • Page 5 Refer to the illustrations and specifications for overall dimensions, finished rough opening dimensions and installation specifics. IMPORTANT NOTE: The depth of Model 700BR is 24" (610) from the front of the unit to its back. Your design may necessitate moving the unit back, or cabinets forward to achieve a flush fit.
  • Page 6 Planning Information Integrated Model 700BR Dimensions in parentheses are in millimeters unless otherwise specified. C A B I N E T R Y A P P L I C A T I O N S Integrated refrigeration is compatible with virtually any style and look of cabinetry.
  • Page 7 Planning Information Integrated Model 700BR F R A M E D C A B I N E T R Y SUB-ZERO (610) UNIT TO WALL CABINET FRAME CABINET PANEL " (3) DOOR REVEAL (686) Traditional Frame – full overlay (top view).
  • Page 8 Planning Information Integrated Model 700BR F R A M E D C A B I N E T R Y – B E A D E D I N S E T A P P L I C A T I O N 24"...
  • Page 9 Planning Information Integrated Model 700BR F R A M E L E S S C A B I N E T R Y "* (679) PANEL WIDTH " (345) "* (424) 4"* (102) 27" (686) TOE KICK FINISHED OPENING A) ALL REVEALS ARE "...
  • Page 10 BBDUAL for two drawer units installed side by side or a drawer unit and a tall unit installed side by side. This optional component is available through your Sub-Zero dealer. To obtain local dealer informa- tion, visit the Locator section of our website, subzero.com.
  • Page 11 Planning Information Integrated Model 700BR T O E K I C K A R E A D E T A I L (268) PANEL (424) PANEL (254) OPTIONAL (102) Dimensions in parentheses are in millimeters unless otherwise specified. T O E K I C K C L E A R A N C E The toe kick clearance can vary with the height of the lower drawer panel;...
