General Information
MODEL DESCRIPTIONS
This page briefly describes the Models 700BC-3, 700BCI-3, 700BF-3, 700BFI-3 and 700BR-3.
Model 700BC-3
(Figure 1-2)
700 B C
Series, ase ombination,
(Combination Refrigerator / Freezer with Two Temperature
Zones - Upper Refrigerator over Freezer)
(Overall Dimensions = 34" H x 27" W x 24" D)
Model 700BCI-3
(Figure 1-7)
700 B C
Series, ase ombination,
Design Build
(Combination Refrigerator / Freezer with Two Temperature
Zones - Upper Refrigerator over Freezer)
(Overall Dimensions = 34" H x 27" W x 24" D)
Model 700BR-3
(Figure 1-3)
700 B R
Series, ase efrigerator,
(Refrigerator with One Temperature Zone)
(Overall Dimensions = 34" H x 27" W x 24" D)
Model 700BF-3
(Figure 1-4)
700 B F
Series, ase reezer,
(Freezer with One Temperature Zone)
(Overall Dimensions = 34" H x 27" W x 24" D)
Model 700BFI-3
(Figure 1-3)
700 B F
Series, ase reezer,
Build
(Freezer with One Temperature Zone)
(Overall Dimensions = 34" H x 27" W x 24" D)
#3758424 - Revision B - December, 2005
3
rd Design Build
I , 3
cemaker Incl. rd
3
rd Design Build
3
rd Design Build
I , 3
cemaker Incl. rd Design
Integrated 3
(700-
Upper
Refrigerator
Zone
Lower
Freezer
Zone
Figure 1-2. Model 700BC-3 & 700BCI-3
Two Drawer
All Refrigerator
(One Zone)
Two Drawer
All Freezer
(One Zone)
Figure 1-4. Model 700BF-3 & 700BFI-3
1-6
Series
BASE)
Figure 1-3. Model 700BR-3
