Sealed System Information
Integrated
3
Series
(700-
BASE)
SEALED SYSTEM REFRIGERANT FLOW DIAGRAM
Heater Loop
Evaporator
Heat Exchanger
Condenser
Compressor
High-Side Filter Drier
Figure 4-1. Model 700BC/I-2 Refrigerant Flow
Heater Loop
Evaporator
Heat Exchanger
Condenser
Compressor
High-Side Filter Drier
Figure 4-2. Model 700BR-2 Refrigerant Flow
4-6
#3758424 - Revision B - December, 2005
