Showroom Mode

Showroom Mode was incorporated into the electronic control system so that units could be displayed in a showroom
setting. When in Showroom Mode, all cooling functions are disabled, but the lighting system and LCD remain
active.
To initiate Showroom Mode, the unit must first be switched OFF using the UNIT ON/OFF key (See Figure 3-14).
With the unit switched OFF, press and hold either pair of WARMER and COLDER keys, then press the UNIT
ON/OFF key, then release all three keys (See Figure 3-15).
To return unit to normal operating condition, repeat the steps above.
NOTE: Always recheck set-points after returning unit to normal operating condition.
NOTE: It is possible to determine if a unit is in Showroom Mode by initiating Diagnostic Mode. If "Sr" is observed in
the left temperature display area during Diagnostic Mode, the unit is in Showroom mode. Initiating Diagnostic Mode
is covered later in this section.
Figure 3-14. To Enter (or Exit) Showroom Mode, Switch Unit OFF First
Figure 3-15. After Unit is Switched OFF, Press and Hold the WARMER and COLDER Keys,

Manual Freezer Evaporator Defrost

Manual Freezer Evaporator Defrost was incorporated into the electronic control to assist in servicing the appliance.
To manually defrost the freezer evaporator, press and hold the ICE ON/OFF key for 5 seconds (See Figure 3-16).
NOTE: Manual Freezer Evaporator Defrost will not operate if unit is in Sabbath Mode.
ICE
Figure 3-16. Initiate Manual Freezer Evaporator Defrost - Press and Hold the ICE key for 5 Seconds
3
(700- BASE)
OFF
FREEZER
FREEZER
Then Press the UNIT ON/OFF Key
FREEZER
Series
COLDER WARMER COLDER WARMER
COLDER WARMER COLDER WARMER
COLDER WARMER COLDER WARMER
Press and hold for 5 seconds
3-9
