EPSON Perfection V700 Photo
4.1.2

Recommended Tools

To protect this product from damage, use the tools indicated in the
following table.
Table 4-1. Specified Tools
Name
Phillips screwdriver, No. 2
Flat-blade screwdriver
Tweezers
Hexagonal Box driver, 5mm
Long-nose pliers
Open-end wrench
Hexagonal wrench
Disassembly / Assembly
Epson Part Number
1080532
1080527
1080561
1080584
1080561
1080580
1080589
Overview
4.1.3

Recommended Screws

The following table indicates the screws used in the EPSON Perfection
V700 Photo Scanner.
Table 4-2. Recommended Screws
No. Name Definition
1 C.B. 3x3 Phillips Bind Screw, size M3, 3 mm length
2 C.B.P. 3x6 Phillips Bind P-tite Screw, size M3, 6 mm length
3 C.B.P. 3x8 Phillips Bind P-tite Screw, size M3, 8 mm length
4 C.B.P. 3x10 Phillips Bind P-tite Screw, size M3, 10 mm length
5 C.B.P. 3x12 Phillips Bind P-tite Screw, size M3, 12 mm length
6 C.B.P. 4x12 Phillips Bind P-tite Screw, size M4, 12 mm length
7 C.B.S. 3x5 Phillips Bind S-tite Screw, size M3, 5 mm length
8 C.C.P. 3x8 Phillips Cup P-tite Screw, size M3, 8 mm length
9 C.P.F.P. 3x8 Phillips Pan Flange P-tite Screw, size M3, 8 mm length
10 C.P.F.S. 3x10 Phillips Pan Flange S-tite Screw, size M3, 10 mm length
11 H.N.-2,3 Hex-Nut Class-2, 3 mm
12 H.N.,5 Hex-Nut, 5 mm
Revision A
37
