Special Recording onto VCR
This connection only allows you to record on the VCR
whatever is currently being displayed on the TV screen
except for menus and special effects. This is not a
common application for recording with your VCR, but you
may find it useful in certain situations. You will also be
able to record signals from another VCR (or similar
device) that is connected to the TV's
jacks.
The TV must remain turned on during recording. If you
change channels on the TV, the channel change will be
recorded on the VCR tape unless you pause the VCR
during recording.
Because your TV is cable-compatible, this application
may be used to record cable-TV programs from the TV
onto a VCR that is not cable-compatible.
You may also want to use this connection to dub or edit
VCR tapes with two or three VCR's. By connecting one
VCR (or camcorder) to the
(or camcorder) to the
INPUT
selectively edit and record whatever is playing on the TV
screen onto a third VCR (or camcorder) connected as
shown here to the
SELECT OUT
Optional S-VHS Cable" (such as 186008)
or
INPUT I INPUT
INPUT
jacks, you will be able to
2
jacks.
q lClt Id Iv
If you connect a surveillance system to your TV, you
will be able to record what the camcorder is displaying
on the TV screen by connecting a VCR (or camcorder)
to the jacks as shown here.
SELECT OUT
Optional S-VHS (Super VHS): If your VCR has an
or connector, connect it to the
S-VIDEO N
I
connector on the TV in addition
-
SELECT S VIDEO OUTPUT
to the left and right audio cables. An optional S-VHS
cable is required.
Operation: To see the signal from a device connected
to the
INPUT
92 to see the signal from a device connected to the
INPUT
override the regular video signal when it is available.
Notes: Menus and displays like clock and channel do not come
through the jacks.
OUT
SELECT
The inset picture from the picture-in-picture can be recorded from
the jacks.
SE OUT
LECT
