ProScan PS27152FX1 Technical Service Data

SAFETY PRECA SAFETY PRECA
SAFETY PRECA SAFETY PRECA SAFETY PRECAUTIONS
SER SERVICE SER VICE WARNING VICE VICE WARNING WARNING WARNING
SER SER VICE WARNING
Only qualified service technicians who are familiar with safety checks
and guidelines should perform service work. Before replacing parts,
disconnect power source to protect electrostatically sensitive parts. Do
not attempt to modify any circuit unless so recommended by the
manufacturer. When servicing the receiver, use an isolation transformer
between the line cord and power receptacle.
SER SER SERVICING SER SER VICING VICING VICING THE HIGH VICING THE HIGH THE HIGH V V V V V OL THE HIGH THE HIGH OL OL OL OLT T T T T A A A A A GE AND CR GE AND CR GE AND CR GE AND CRT T T T T GE AND CR
Use EXTREME CAUTION when servicing the high voltage circuits. To
discharge static high voltage, connect a 10K ohms resistor in series with a
test lead between the receiver ground and CRT anode lead. DO NOT lift
the CRT by the neck. Always wear shatterproof goggles when handling
the CRT to protect eyes in case of implosion.
X-RA X-RA X-RAY RADIA X-RA X-RA Y RADIA Y RADIA Y RADIATION AND HIGH Y RADIA TION AND HIGH TION AND HIGH V V V V V OL TION AND HIGH TION AND HIGH OL OL OL OLT T T T T A A A A A GE LIMITS GE LIMITS GE LIMITS GE LIMITS GE LIMITS
Be aware of the instructions and procedures covering X-ray radiation. In
solid-state receivers and monitors, the CRT is the only potential source of
X-rays. Keep an accurate high voltage meter available at all times. Check
meter calibration periodically. Whenever servicing a receiver, check the
high voltage at various brightness levels to be sure it is regulating
properly. Keep high voltage at rated value, NO HIGHER. Excessive high
voltage may cause X-ray radiation or failure of associated components.
DO NOT depend on protection circuits to keep voltage at rated value.
When troubleshooting a receiver with excessive high voltage, avoid close
contact with the CRT. DO NOT operate the receiver longer than
necessary. To locate the cause of excessive high voltage, use a variable
AC transformer to regulate voltage. In present receivers, many electrical
and mechanical components have safety related characteristics which are
not detectable by visual inspection. Such components are identified by a
# on both the schematic and the parts list. For SAFETY, use only
equivalent replacement parts when replacing these components.
GENERAL GUIDELINES GENERAL GUIDELINES
GENERAL GUIDELINES GENERAL GUIDELINES GENERAL GUIDELINES
Perform a final SAFETY CHECK before returning receiver to customer.
Check repaired area for poorly soldered connections, and check entire
circuit board for solder splashes. Check board wiring for pinched wires or
wires contacting any high wattage resistors. Check that all control knobs,
shields, covers, grounds, and mounting hardware have been replaced. Be
sure to replace all insulators and restore proper lead dress.
HIGH V V V V V OL HIGH HIGH OLT T T T T A A A A A GE SHUTDO OL OL GE SHUTDOWN GE SHUTDO GE SHUTDO
HIGH HIGH OL GE SHUTDO
Apply 120VAC to set, turn set on, and adjust brightness and contrast to maximum. Short
XRP-1 to XRP-2. The set should shut down and then cycle on and off. If the set does not
shut down and then cycle on and off, the shutdown circuoit requires repair. To resume normal
operation remove the short from XRP-1 to XRP-2.
The listing of any available replacement part herein in no case constitutes a recommendation, warranty, or guarantee by
SAMS Technical Publishing as to the quality and suitability of such replacement part. The numbers of the listed parts have
been compiled from information furnished to SAMS Technical Publishing by the manufacturers of the specific type of
replacement part listed.
Reproduction or use, without express permission, of editorial or pictorial content, in any manner, is prohibited. No patent
liability is assumed with respect to the use of the information contained herein.
© 2002
5436 West 78th Street
Indianapolis, IN 46268-4149
Printed in the United States of America 5 4 3 2 1
P P P P P a a a a a g g g g g e 1 e 1 e 1 e 1 e 1 SET 4544 SET 4544 SET 4544 SET 4544 SET 4544
All manuals and user guides at all-guides.com
UTIONS UTIONS
UTIONS UTIONS
SAFETY CHECKS — FIRE AND SHOCK HAZARD SAFETY CHECKS — FIRE AND SHOCK HAZARD SAFETY CHECKS — FIRE AND SHOCK HAZARD
SAFETY CHECKS — FIRE AND SHOCK HAZARD SAFETY CHECKS — FIRE AND SHOCK HAZARD
Cold Leakag g g g g e Chec Cold Leaka Cold Leaka Cold Leaka Cold Leaka e Chec e Chec e Chec e Checks f ks f ks f ks for Receiver ks f or Receivers with Isolated Gr or Receiver or Receiver or Receiver s with Isolated Ground s with Isolated Gr s with Isolated Gr s with Isolated Gr ound ound ound ound
Unplug the AC cord, connect a jumper across the plug prongs, and turn
the power switch on (if applicable). Use an ohmmeter to measure the
resistance between the jumped AC plug and any exposed metal cabinet
parts such as antenna screw heads, control shafts, or handle brackets.
Exposed metal parts with a return path should measure between 1M
ohms and 5.2M ohms. Parts without a return path must measure infinity.
Hot Leaka Hot Leaka Hot Leaka Hot Leaka Hot Leakag g g g g e Current Chec e Current Check k k k k e Current Chec e Current Chec e Current Chec
Plug the AC cord directly into an AC outlet. DO NOT use an isolation
transformer. Use a 1500 ohms, 10W resistor in parallel with a .15µF
capacitor to connect between any exposed metal parts on the receiver and
a good earth ground. (See figure below.) Use an AC voltmeter with at
least 5000 ohms per volt sensitivity to measure the voltage across the
resistor. Check all exposed metal parts and measure voltage at each point.
Voltage measurements should not exceed .75VAC, 500µA. Any value
exceeding this limit constitutes a potential shock hazard and must be
corrected. If the AC plug is not polarized, reverse the AC plug and repeat
exposed metal part voltage measurement at each point.
WN TEST WN WN TEST TEST TEST
WN TEST
UPC
HERE
02PF01843
Technical Service Data
