VSX 7000 Series Administrator's Guide
Data
Audio Protocol (Rx)
Video Protocol (Tx)
Video Protocol (Rx)
Video Format (Tx)
Video Format (Rx)
Reason for Disconnect
Q.850 Cause Code
Total H.320 Errors
Percent of Packet Loss (Tx)
Percent of Packet Loss (Rx)
Total Packets Lost (Tx)
Total Packets Lost (Rx)
Average Latency (Tx)
Average Latency (Rx)
Maximum Latency (Tx)
Maximum Latency (Rx)
Average Jitter (Tx)
Average Jitter (Rx)
Maximum Jitter (Tx)
Maximum Jitter (Rx)
84
Description
The audio protocol received from the far site, such as G.728 or G.722.
The video protocol transmitted to the far site, such as H.263 or H.264.
The video protocol received from the far site, such as H.261 or H.263.
The video format transmitted to the far site, such as CIF or SIF.
The video format received from the far site, such as CIF or SIF.
The description of the Q.850 (ISDN) cause code showing how the call ended.
The Q.850 cause code showing how the call ended.
The number of errors during an H.320 call.
The percentage of packets transmitted that were lost in the previous 5 seconds
during an H.323 call.
The percentage of packets from the far site that were lost in the previous 5 seconds
during an H.323 call.
The total number of packets transmitted that were lost during an H.323 call.
The total number of packets from the far site that were lost during an H.323 call.
The average latency of packets transmitted during the call, calculated from sample
tests done once per minute.
The average latency of packets received during the call, calculated from sample tests
done once per minute.
The maximum latency for packets transmitted during the call, calculated from sample
tests done once per minute.
The maximum latency for packets received during the call, calculated from sample
tests done once per minute.
The average jitter of packets transmitted during the call, calculated from sample tests
done once per minute.
The average jitter of packets received during the call, calculated from sample tests
done once per minute.
The maximum jitter of packets transmitted during the call, calculated from sample
tests done once per minute.
The maximum jitter of packets received during the call, calculated from sample tests
done once per minute.
