VSX 7000 Series Administrator's Guide
3 1 FAIR-RITE PN 2661665702 OR POLYCOM APPROVED EQUIVALENT
FLEXIBLE CABLE, CONSISTING OF TWO 28 AWG. STRANDED TWISTED PAIRS, ONE 24 AWG.
2 30 FT
STRANDED CONDUCTOR, WITH OVERALL SPIRAL PAPER PLUS TINNED COPPER SHIELD.
1 2 OFFSET TAB RJ11 PLUG, 6P6C, STEWART P/N: 937-SP-3066R-OST OR EQUIVALENT
ITEM
QTY.
P1
6
5
4
3
2
1
1
SHIELD
PIN OUT
P1
3
TWISTED PAIR
6
4
TWISTED PAIR
5
1
SPIRAL SHIELD
2
Appendix - 6
DESCRIPTION
5/8" MAX.
MOLDED STRAIN RELIEF
SEE NOTE 3
1.5"
3.35"
4
5.5" ±.5"
2.75"±.25"
P2
3
6
4
5
1
2
Conference Link Cable 2457-20910-001, 30 ft (9 m)
6
3 SEE NOTE
2
5
30 FEET
NOTES:
1. CABLE MUST BE UL TYPE CL2 RATED AND MEET UL VW-1
REQUIREMENTS. INCLUDE CERTIFICATE OF COMPLIANCE WITH
SHIPMENT. DO NOT MARK CABLE ITSELF.
2. O.D. OF CABLE: 4.0MM MAX.
3. MOLDING MATERIAL: PVC UL94 V-0
COLOR: BROWN, APPROXIMATE MATCH TO PANTONE #497 U.
4 TIE DIAMETERS TO MINIMIZE CURL
5 BARCODE LABEL TO CONTAIN LAST 8 DIGITS OF
CABLE PART NO. (REMOVE 2457).
CABLE SPEC: LASER LABEL
SIZE: 12mm X 76mm
6 OVERMOLD ITEM 3, FERRITE CORE. POSITION
FERRITE 1.5 INCHES FROM CONNECTOR AND WRAP
THE CABLE ONE TURN AROUND THE FERRITE
CORE PRIOR TO OVERMOLDING.
L. SIMPSON
. .
5/8" MAX.
MOLDED STRAIN RELIEF
SEE NOTE 3
CBL, MICPD, RJ11, OFFSET TAB,
092001 30 FEET
N.T.S.
www.polycom.com/videodocumentation
. .
P2
6
5
4
3
2
1
1
2457-20910-001
