VSX 7000 Series Administrator's Guide
Multipoint Dialing Speed Information
Cable Descriptions
Cable
LAN cable
Orange RJ-45
Monitor cable
S-Video, yellow 4-pin mini-DIN
Conference link cable
Brown RJ-9, offset tab
Appendix - 2
In a multipoint call, all parties must be connected at the same speed.
The following table shows the maximum allowable dialing speeds for the number
of sites, including the main site, in a call.
Network Interface
BRI
H.323 Only
The following table gives information about the cables shipped with the system.
Drawings for these cables are included in this appendix.
Maximum approved
length
100 ft (30 m)
50 ft (15 m)
100 ft (30 m)
—
Number of Maximum Speed for Each Party in the
Sites in a Call Call (Kbps)
H.320
2 with 2 lines 256
2 with 3 lines 384
2 with 4 lines 512
3 with 2 lines 128
3 with 3 lines 192
3 with 4 lines 256
4 with 2 lines 64
4 with 3 lines 128
4 with 4 lines 128
Refer to H.323 speeds in this table.
Part number shipped
2457-08343-001
12 ft (3.6 m)
2457-08409-001
25 ft (7.6 m)
2457-20910-001
30 ft (9 m)
0.5 ft (0.15 m)
H.323
1920
1920
1920
512
512
512
384
384
384
Other cables available
2457-09204-001
50 ft (15 m)
2457-20910-002
10 ft (3 m)
