VSX 7000 Series Administrator's Guide
VCR or DVD — To Play
VCR or DVD — To Record
28
If you have connected a second camera to the camera 2 S-Video input, you cannot connect
a VCR. The VCR inputs are not active when the S-Video connector is in use.
1. Connect the VCR or DVD's audio and video line out to the VCR inputs to the
left of the camera 2 input.
2. Refer to the manufacturer's instructions for configuring the VCR or DVD.
The VCR inputs are active when you select camera 3.
Connect monitor 1 using the monitor 1 S-Video connector, and connect the
1.
VCR's audio and video line in to the monitor 1 RCA outputs. The VCR will
record the same video and audio that monitor 1 receives.
2. Refer to the manufacturer's instructions for configuring the VCR.
www.polycom.com/videodocumentation
