CDM-625 Advanced Satellite Modem
Introduction
1.3.3
Ethernet/IP Interface Compatibility
CDM-625 Configuration
Standard 4-port Ethernet Data
Interface without optional IP
Packet Processor – Managed
Switch Mode*
Standard 4-port Ethernet Data
Interface without optional IP
Packet Processor – Managed
Switch Mode*
CDM-625 Configuration
Optional IP Packet Processor –
Managed Switch Mode*
Optional IP Packet Processor –
Managed Switch Mode*
Optional IP Packet Processor –
Router Mode
Optional IP Packet Processor –
Router Mode
*Note: Managed Switch Mode is also known as Ethernet Bridge Mode.
1.3.4
Verification
The CDM-625 includes many test modes and loopbacks for rapid verification of the correct
functioning of the unit. Of particular note is the IF loopback, which permits you to perform a
quick diagnostic test without having to disturb external cabling. During the loopback, all of the
receive configuration parameters are temporarily changed to match those of the transmit side,
and an internal RF switch connects the modulator output to the demodulator input. When
normal operation is again selected, all of the previous values are restored.
1.3.5
Updating Modem Firmware
Chapter 4. UPDATING FIRMWARE
The CDM-625 stores its firmware internally in flash memory, which simplifies the firmware
updating process without having to open the modem. Firmware downloads are available via the
HDLC Encapsulation
Compatible CEFD
Compatible
IP Modem
CEFD IP Modem
Firmware
CDM-570/570L IP
CDM-570/570L
Firmware Versions
with IP Module
1.5.4 to 1.6.X
CDD-562L/564 IP
CDD-562L/564
Firmware Versions
IP Demodulator
1.5.4 to 1.6.X
Streamline Encapsulation
Compatible
Compatible CEFD IP
CEFD IP Modem
Modem Firmware
CDM-570/570L IP
CDM-570/570L
Firmware Version 1.7.0 or
with IP Module
later
CDD-562L/564
CDD-562L/564 IP Firmware
IP Demodulator
Version 1.7.0 or later
CDM-570/570L IP
CDM-570/570L
Firmware Version 1.7.0 or
with IP Module
later
CDD-562L/564
CDD-562L/564 IP Firmware
IP Demodulator
Version 1.7.0 or later
1–4
Revision 13
MN-CDM625
Compatible CEFD IP Modem
Configuration
CDM-570/570L must have Layer
2 (L2) Tx and Rx Header
Compression disabled –
Managed Switch Mode*
CDD-562L/564 must have Layer
2 (L2) Tx and Rx Header
Compression disabled –
Managed Switch Mode*
Compatible CEFD IP
Modem Configuration
Managed Switch Mode*
Managed Switch Mode*
Router Mode
Router Mode
