Table 1-1. Cdm-625 Optional Hardware And Accessories - Comtech EF Data CDM-625 Installation And Operation Manual

CDM-625 Advanced Satellite Modem
Introduction
Feature CEFD P/N
LDPC/TPC KT-0000093
VersaFEC
KT-0000092
Codec
CnC
KT-0000094
KT-0000176
IP Packet
KT-0000174
Processor
KT-0000175
KT/6228-2
Rack
Installation
KT/6228-3
PL-0000307
CA-0000163
CA-0000164
Data
Interface
KT-0000122
KT-0020570
CA/WR12685-1
KT-0020703
KT-0000226
KT-0000283
KT-0020701
PS-0000075
AC Power
PS-0000065
CA/17725
CA/90025-5FT
KT/11633-1
CA/17850
PP-0000097
PP-0020556
PL/12587-2
KT-0020683
KT-0020680
KT-0000282
PS-0000066
DC Power PS-0020545
CA-0000455
KT/9640-3
KT-0000029
KT-0000185
KT-0000186

Table 1-1. CDM-625 Optional Hardware and Accessories

Description
Combination Low-density Parity Check / TPC Codec daughter card providing
data rates up to 25 Mbps and a full range of code rates/modulation
VersaFEC Codec daughter card providing data rates up to 16 Mbps, 12
combinations of modulation and code rate (ModCod)
DoubleTalk® Carrier-in-Carrier® daughter card
IP Packet Processor daughter card with Fan
IP Packet Processor Kit for AC units (includes 175W Power Supply)
IP Packet Processor Kit for DC units (includes 125W Power Supply).
Rear Rack-Mount Kit – 4" Bracket
Rear Rack-Mount Kit – 10" Bracket
CiC-60 (HSSI) Interface Adapter Module
Quad E1 Adapter Y-Cable (for 2 E1 Ports: D-Type 9-pin Male to 2X D-Type 15-
pin Female)
Quad E1 Adapter Y-Cable (for 2 E1 Ports: D-Type-9-pin Male to 2X RJ-48)
Quad E1 Balanced/Unbalanced Adapter Kit, 6"
Quad E1 Balanced/Unbalanced Adapter Kit, 3 Ft
Adapter Cable: 25-pin D-Type Male to 37-pin D-Type Female, 8" (RTS/CTS
Control)
AC to 24V DC Conversion Kit
AC to 48V DC Conversion Kit
AC Primary Power Supply: 100-240 VAC (65W Power Supply) w/required
cables
AC Primary Power Supply: 100-240 VAC (175W Power Supply) w/required
cables
AC 65W Power Supply
AC 175W Power Supply
AC Power Cord, Standard (IEC-60320 Type C13) – USA
AC Power Jumper Cord, Standard (IEC-60320 Type C13)
AC Power Cord Retainer Kit (for any AC Cord)
AC Power Cord – European / French
AC Power Cord – Japanese
AC Power Cord – India
Modem Chassis – DC
DC to AC Conversion Kit for CDM-625 Base Modem
DC to AC Conversion Kit for CDM-625 with IP Packet Processor
DC Primary Power Supply: -48 VDC, w/required cables
DC 48V 125W Power Supply
DC 24V 120W Power Supply
DC Pigtail Adapter
BUC Power Supply: 24 VDC 90W (50° C) (100-240 VAC Input)
BUC Power Supply: 48 VDC 150W (50° C) (100-240 VAC Input)
BUC Power Supply: 24 VDC 90W (50° C) (-48 VDC Input)
BUC Power Supply: 48 VDC 150W (50° C) (-48 VDC Input)
1–6
Revision 13
MN-CDM625
Chapter
7.7
7.8
10.7
18.1.1
2.2.1
3.2.2.1.1
3.2.2.2.3.1
3.2.2.2.3.2
3.2.2.2.3.3
N/A
3.3.2
3.3.3
