CDM-625 Advanced Satellite Modem
Appendix D
D.5.5
Bulk Configuration Strings
Note: In order to completely get/set the configuration of the modem, the following commands must be queried/set:
•
MGC
•
OGC (L-Band Only)
•
Drop and Insert (specified in MGC):
o
DNI (Open Network DNI);
o
DIC (Closed Network DNI++);
o
QDI (Quad DNI), one for each active port up to a maximum of four.
Command
Parameter
Number of
(Instruction
Type
Arguments
& Qualifier)
Global
MGC=
224 bytes,
Configuration
numerical
entries, fixed
values and
delimiters
Description of Arguments
Command or Query.
Global Configuration of CDM625, in the form shown in the Response to Query column (to right) where:
* FFFF.FFFF=Tx Frequency
DDDDD.DDD=TX Data Rate
G=Tx FEC Type
Y=Tx Reed-Solomon Type
R=Tx FEC Rate
M=Tx Modulation Type
V=Tx Spectrum Inversion
S=Tx Scrambler State
PP.P Tx Power Level
B=AUPC Enable
aaa.aa=AUPC Parameter Setup
C=Tx Clock Source
X=Tx Carrier State
I=Tx Interface Type
K=Tx Ternary Code
N=Tx Framing Mode
* Z=Tx Clock Invert
* ffff.ffff=Rx Frequency
ddddd.ddd=Rx Data Rate
g=Rx FEC Type
y=Rx Reed-Solomon Type
r=Rx FEC Rate
m=Rx Modulation Type
v=Rx Spectrum Inversion
s=Rx Scrambler State
* www=Rx Sweep Width
c=Rx Clock Source
ll.l=Eb/No Alarm Point
bbbbb=Rx Buffer Size
i=Rx Interface Type
k=Rx Ternary Code
same as TFQ
same as TDR
same as TFT
same as TRS
same as TCR
same as TMD
same as TSI
same as TSC
same as TPL
same as AUP
same as APP
same as TCK
same as TXO
same as TIT
same as TTC
same as TFM
same as TCI
same as RFQ
same as RDR
same as RFT
same as RRS
same as RCR
same as RMD
same as RSI
same as RDS
same as RSW
same as RCK
same as EBA
same as RBS
same as RIT
same as RTC
D–41
Revision 13
MN-CDM625
Query
Response to
Response to
(Instruction &
Command
Qualifier)
MGC=
MGC?
MGC=FFFF.FFFFD
MGC?
MGC?n (where
DDDD.DDDGYRMV
MGC*
n = 0 to 9.
SPP.PBaaa.aaCXIK
MGC#
Returns the
NZffff.ffffddddd.dddg
MGC portion of
yrmvswwwcll.lbbbbb
1 of 10 stored
iknzOEEEETeeeee
configurations)
eeeeeeeeWALQUH
HHHhhhhJJJJjjjjabc
defxxxxxxxxxxrrrrr.rr
rsssss.ssshgkpmnn
nttuuu.uuu.uuu.uuu.
uuvvv.vvv.vvv.vvvx
GHIJKwAAABBBC
CCeexEFGGGH
Query
