Operation, cont'd
IP information
To set up the ISS for operation via its Ethernet port, you need to know and be able
to change the IP address. One way to do this is via the IP address and hardware
address screen.
To access the IP address and hardware address screen, press and hold the
Color/Tint and Detail buttons while you apply power to the ISS (figure 3-19).
When the ISS is finished intializing, it displays both addresses.
Select the IP address subfield
with the Adjust
Figure 3-19 — IP information flowchart
If you need to change the IP address, use the Adjust
subfield. Rotate the Adjust knob to change the value. Repeat the adjustment for
other subfields as required.
Valid IP addresses consist of four 1-, 2-, or 3-digit numeric subfields separated by
dots (periods). Each field can be numbered from 000 through 255. Leading zeroes,
up to 3 digits total per field, are optional. Values of 256 and above are invalid.
Optimizing the Video
Perform the following steps, in sequence, after you have installed the ISS. This
procedure will help you to configure the switcher for the best settings for your
display environment. In a multi-screen environment, perform this procedure for
each display.
See Advanced Configuration menu earlier in this chapter to select and output a test
pattern and to select and output blue only video.
See Picture adjustments, earlier in this chapter, to make adjustments to the picture
quality.
See User Presets menu, earlier in this chapter to save presets.
3-20
Integration Seamless Switcher • Operation
Press and hold both buttons
simultaneously while applying power
COLOR/
DETAIL
TINT
IP Address
>
192.168.255.255
Hardware Address
00-80-00-00-04-04
Change the subfield value
knob.
with the Adjust
IP Address
>
192.168.255
253
Hardware Address
00-80-00-00-04-04
NOTE
10 sec.
Default
Cycle
If the local system administrators have not changed the value, the factory-
specified default, 192.168.254.254, is the correct value for this field.
The hardware address is hardcoded and cannot be changed.
Power
knob.
The hardware address is
hardcoded and cannot
be changed.
knob to select the desired
