Ethernet Connection, cont'd
Connect as a Telnet client
The Microsoft Telnet utility is available from the DOS prompt. Telnet allows you to
input SIS commands to the ISS from the PC via the Ethernet link and the LAN.
Access the DOS prompt and start Telnet as follows:
1.
2.
3.
4.
Figure A-3 — Telnet screen
Telnet tips
It is not the intention of this manual to detail all of the operations and functionality
of Telnet, however some basic level of understanding is necessary for operating the
ISS via Telnet.
Open
Connect to the ISS using the Open command. Once you are connected to the
switcher, you can enter the SIS commands the same as you would if you were using
the RS-232 link.
Connect to the ISS as follows:
1.
2.
A-4
Integration Seamless Switcher • Ethernet Connection
Click on Start > Run.
At the Open prompt, type command.
Click on the OK button.
At the DOS prompt, type telnet and press [Enter]. The computer returns a
display similar to figure A-3.
Microsoft (R) windows 2000 (TM) Version 5.0 (Build 2195)
Welcome to Microsoft Telnet Client
Telnet Client Build 5.00.99203.1
Escape Character is 'CTRL+]'
Microsoft Telnet>
At the Telnet prompt, type open {IP address} and then press [Enter].
If the switcher is not password protected, no further prompts are displayed
until you break or disconnect the connection to the ISS.
If the switcher is password protected, Telnet displays the password prompt.
If necessary, at the password prompt, type {password} and then press [Enter].
Connection to the switcher via the Ethernet can be password protected. There
are two levels of password protection: administrator and user. A person
logged on as an administrator has full access to all ISS switching capabilities
and editing functions. Users can select video and/or audio for output, select
test patterns, set RGB and audio mutes, select a blue screen, and view all
settings with the exception of passwords. By default, the ISS ships with both
passwords cleared (no password assigned).
