Operation, cont'd

Picture adjustments

The picture adjustments allow you to fine tune the image quality of the selected
input. When you press one of the Picture Adjustments buttons (Color/Tint,
Brightness/Contrast, Size, Center, or Filter) once, the corresponding image
adjustment menu for the preview image appears on the LCD screen. Press the
button again, and the corresponding image adjustment menu for the program
image appears. In either screen, adjustments can then be made by rotating the
Adjust
nonvolatile memory; when the switcher is powered down and powered up, the
settings are restored.
Adjust an image for centering, sizing, brightness, contrast, color, tint, zoom, or
detail as follows (figure 3-17).
COLOR/
TINT
Preview
Color Tint
127 128
Press again for Prog
COLOR/
TINT
Program
Color Tint
127 128
Press again for Prev
NOTE
Figure 3-17 — Picture adjustments flowchart
1.
3-18 Integration Seamless Switcher • Operation
knob or the Adjust knob. Picture adjustment settings are stored in
Power
on
BRT/
CONT
Preview Preview
Brightness Contrast Horz
063 063 450
Press again for Prog Press again for Prog
BRT/
CONT
Program Program
Brightness Contrast Horz
063 063 450
Press again for Prev Press again for Prev
The Adjust knob and the Adjust knob are used to adjust the
image settings on the left and right sides of the LCD screen, respectively.
Press the desired input button to select the input to adjust.
The adjustments are made to the input signal as it is switched to the output
(preview or program) shown in the LCD only. The adjustments do not affect
the same input switched to the other output.
Color adjustments are available only for component video, S-video, and
composite video inputs.
Tint adjustments are available only for S-video and composite video inputs.
Extron Electronics Extron Electronics
ISS 408 with DVI ISS 408 with DVI
Integration
Seamless Switcher Version x . xx
2 sec.
SIZE CENTER
Preview
Size Vert Horz Center
400 500
Press again for Prog
SIZE CENTER
Program
Size Vert Horz Center
400 500
Press again for Prev
60-423-01
Display
2 sec.
Cycle
FILTER
Preview
Vert Horz Filter Vert
550 3 7
Press again for Prog
10 sec.
timeout
FILTER
Program
Vert Horz Filter Vert
550 3 7
Press again for Prev
10 sec.
timeout
