Switcher Software
Control Software for Windows
Two software programs accompany the ISS 108 and ISS 408:
•
•
Both programs are compatible with Windows 95/98, Windows NT, Windows Me.,
and Windows 2000. Updates to these programs can be downloaded from the
Extron Web site (http://www.extron.com).
Installing the software
The programs are contained on a CD-ROM, and it is most convenient to load the
program to the hard drive and run it from there.
To install the program from the CD-ROM to the hard drive, run SETUP.EXE from
the CD-ROM and follow the instructions that appear on the screen. The program
occupies approximately 1.5 Mb (megabytes) of hard-drive space.
By default the installation creates a C:\ISSISM folder, and it places three icons
(ISS/ISM Control Pgm, ISS/ISM Help, and Button-Label Generator) into a group or
folder named "Extron Electronics".
Software operation via Ethernet
When an ISS is connected to an Ethernet WAN or LAN, any number of users can
operate it, locally or remotely, using the ISS/ISM Control program. See Ethernet
connection in chapter 2, Installation, for Ethernet installation details
Connection to the switcher via the Ethernet is password protected. There are two
levels of password protection: administrator and user. Administrators have full
access to all ISS switching capabilities and editing functions. Users can select video
and/or audio for output, select test patterns, set RGB and audio mutes, select a
blue screen, and view all settings with the exception of passwords. If the same
passwords or no password is required for logging on, all personnel log on with
administrator privileges. Fields and functions that exceed user privileges are
grayed out in the ISS/ISM Control program when the operator is logged on as a
user.
Ethernet protocol settings
The IP settings/options screen (figure 5-6 on page 5-5) provides a location for
observing and, if connected via the RS-232 link or if logged on via the Ethernet port
as an administrator, editing settings unique to the Ethernet interface. None of the
fields on this screen can be edited while logged on as a user. See System
Configuration Page in chapter 6, Ethernet Operation, for details on the contents of
these fields. See appendix A, Ethernet Connection, for other basic information about
Internet protocol.
5-2
Integration Seamless Switcher • Switcher Software
The Extron ISS/ISM Control Program (Extron part #29-054-01), which
communicates with the switcher via the rear panel Remote port, provides an
easy way for you to control the switcher.
The Extron Button-Label Generator, which allows you to design and print a
label strip for the switcher's front panel input selection button window.
Editing variables on the IP settings/options screen while connected via the
Ethernet port can immediately disconnect the user from the ISS. Extron
recommends editing the settings on this screen using the RS-232 link and
protecting the Ethernet access to this screen by assigning an administrator's
password to qualified and knowledgeable personnel only.
