Chapter 2 Cisco IOS XR Basic Configuration Management
Figure 2-4
the possible configuration submodes is shown.
Figure 2-4
Logical router configuration mode
(not available in current systems)

Identifying the Command Mode in the CLI Prompt

The command mode is identified in the CLI prompt after the router name.
For example, when the router enters global configuration mode from the EXEC mode, the CLI prompt
changes to include "
RP/0/RP0/CPU0:routername# configure
RP/0/RP0/CPU0:routername(config)#
When the router enters interface configuration submode, the prompt changes to include "
after the router name:
RP/0/RP0/CPU0:routername(config)# interface POS 0/2/0/0
RP/0/RP0/CPU0:routername(config-if)#
illustrates the basic command mode navigation for the CLI. Note that only a small sample of
Example of Command Mode Navigation in Cisco IOS XR software
EXEC mode
Admin EXEC mode
Admin configuration mode
" after the router name:
(config)
Login
Global configuration mode
Cisco CRS-1 Series Carrier Routing System Getting Started Guide
Navigating the Cisco IOS XR Command Modes
Configuration submode
examples
Interface
configuration submode
Router
configuration submode
Line template
configuration submode
Task group
configuration submode
"
(config-if)
2-9
