Command Syntax for Hardware Nodes (location nodeID)
Figure 7-2 Display NodeID with the show platform Command
Node column displays
the nodeID for each card
RP/0/RP0/CPU0:router# show platform
Node
-------------------------------------------------------------------------------------------------------------------
0/1/SP
0/1/CPU0
0/2/SP
The nodeID for
0/2/CPU0
MSC cards
0/3/SP
contains "CPU0"
0/3/CPU0
0/RP0/CPU0 RP(Active)
0/RP1/CPU0 RP(Standby) N/A
0/SM0/SP
0/SM1/SP
RP/0/RP0/CPU0:router#
Note For each line card installed in the system, there are two entries in the show platform output. For CLI
commands, use the entry with the module "CPU0." This entry also displays the Physical Line Interface
Module (PLIM) type. Example:
Node
-----------------------------------------------------------------------------
0/2/CPU0
Examples of nodeID Command Syntax
The following examples of nodeID syntax are provided:
•
•
NodeID for a Switch Fabric Module Command
The following command displays the connectivity information for a fabric card:
admin show controllers fabric connectivity location nodeID
Example:
RP/0/RPO/CPU:router# admin show controllers fabric connectivity location 0/SM0/SP
Card
R/S/M
-------------------------------------------------------------------------------
In this example, the command references the fabric card in rack "0," slot "SM0," with module "SP."
