APPENDIX
Mode Parameter Name
Set point upper limit
Set point lower limit
PID / ON/OFF
Operation at power ON
End condition
Program time unit
Step time/Rate of rise pro-
gramming
Time unit of ramp rate
PV start
Expan- Expan
sion i
Wait width
Alarm during ramp step en-
able
Run all enable
α
AT calculated gain
Automatic return of display
mode
AT hysteresis
LB detection width
Event input assignment 1
Event input assignment 2
Communication stop bit
Communication data length
Communication parity
Communication baud rate
Communication unit No.
Option Option
Transfer output type
Transfer output upper limit
Transfer output lower limit
HBA latch
Motor calibration
Travel time
PV dead band
*9 When temperature input is selected, the range of the sensor selected in the "input type" parameter (setup mode) corresponds
to the scaling upper and lower limit value.
*10 Set the transfer output type parameter according to the following table.
Transfer Output Type
SP :Present SP
PV :Process value
O :Manipulated variable (heat)
C-O :Manipulated variable (cool)
V-M :Valve opening
Default : [SP]
D
A--10
Setting Range
Set point lower limit +1 to scaling upper limit
Scaling lower limit to Set point upper limit -1
PID / ON/OFF
CON/RST/RUN/MAN
RST/SP
HHMM/MMSS
TIME/PR
M/H
PV/SP
0 to 9999
ON/OFF
ON/OFF
0.00 to 1.00
0.1 to 10.0
0 to 99
0.1 to 9.9
0.0 to 999.9
NON/RST/MAN/HOLD/ADV/PTN0 to 2
NON/RST/MAN/HOLD/ADV/PTN0 to 2
1/2
7/8
NONE/EVEN/ODD
1.2/2.4/4.8/9.6/19.2
0 to 99
SP/PV/O/C-O/V-M
*10
*10
ON/OFF
ON/OFF
1 to 999
0 to 9999
Transfer Output Lower Limit to Transfer Output Upper Limit
-5.0 to 105.0% (standard control), 0.0 to 105.0% (heating and cooling control)
Unit Default Remarks
EU 1300
EU -200
None PID
None CON
None RST
None HHMM
None OFF
None OFF
None SP
EU 0
None ON
None OFF
None 0.65
None 1.0
Sec 0
%FS 0.2
%FS 0.2
None NON
None NON
bit 2
bit 7
None EVEN
kbps 9.6
None 0
None SP
*10 *10
*10 *10
None OFF
None OFF
Sec 30
EU 0
-1999 to 9999
-1999 to 9999
0.0 to 105.0%
-10.0 to 110.0%
Setting
*9
*9
