Hysteresis (heat)
Hysteresis (cool)
• Sets the hysteresis for ensuring stable operation at ON/OFF switching.
• In a standard control system, use the "hysteresis (heat)" parameter. The "hystere-
sis (cool)" parameter cannot be used.
Function
• In a heating and cooling control system, the hysteresis can be set independently
for heating and cooling. Use the "hysteresis (heat)" parameter to set the heating
side hysteresis, and use the "hysteresis (cool)" parameter to set the cooling side
hysteresis.
Parameter
Hysteresis (heat)
Hysteresis (cool)
Setting
F Related description
4.1 Selecting the Control Method/ON/OFF control (page 4-5)
F Related parameters
See
"Control output 1 assignment" "Control output 2 assignment" (setup mode)
"PID/ON/OFF" (expansion mode)
E5EK-TAA2
Model
Conditions of Use
The control system must be ON/OFF
control.
Unit
Setting Range
0.01 to 99.99 %FS
0.01 to 99.99 %FS
Level 1 Mode
Default
0.10
0.10
5--21
