Install the Open-Frame Rack Mounting Shelf
Before mounting the chassis in an open-frame rack, you must first install the open-frame
rack mounting shelf.
To install the open-frame rack mounting shelf, (see
On the rear of each rack rail, partially insert a mounting screw into the highest hole
1.
specified in
Table 3 on page 9
Install the open-frame rack mounting shelf on the rack. Hang the shelf over the
2.
mounting screws using the keyhole slots located near the top of the shelf flanges.
Partially insert screws into the open holes in the flanges of the open-frame rack
3.
mounting shelf.
Tighten all the screws completely.
4.
Figure 4: Installing the TX Matrix Plus Mounting Hardware for an
Open-Frame Rack
Insert screws in the holes specified in
location). The hole distances are relative to the standard U division on the rack that is
aligned with the bottom of the mounting shelf.
Install the Open-Frame Rack Mounting Shelf
Figure 4 on page
for the open-frame rack mounting shelf.
Table 5 on page 12
(an X indicates a mounting hole
11):
11
