TX Matrix Plus Router Quick Start
10
Table 3: Mounting Hole Locations for Installing a TX Matrix Plus
Open-Frame Rack Shelf (continued)
Hole
Distance Above U Division
21
12.0 in. (30.5 cm)
18
10.25 in. (26.0 cm)
15
8.5 in. (21.6 cm)
12
6.75 in. (17.1 cm)
9
5.0 in. (12.7 cm)
6
3.25 in. (3.8 cm)
The holes in the center-mounting brackets are spaced at 2 U (3.5 in. or 8.9 cm).
Table 4: Mounting Hole Locations for Installing a TX Matrix Plus Chassis
in an Open-Frame Rack
Hole
Distance Above U Division
90
52.5 in. (132.7 cm)
84
48.75 in. (123.8 cm)
78
45.25 in. (114.9 cm)
72
41.75 in. (106.0 cm)
66
38.25 in. (97.2 cm)
60
34.75 in. (88.3 cm)
54
31.25 in. (79.4 cm)
48
27.75 in. (70.5 cm)
42
24.25 in. (61.6 cm)
36
20.75 in. (52.7 cm)
30
17.25 in. (43.8 cm)
24
13.75 in. (34.9 cm)
18
10.25 in. (26.0 cm)
12
6.75 in. (17.1 cm)
Open-Frame MountingShelf
6.86 U
X
5.86 U
X
4.86 U
X
3.86 U
X
2.86 U
X
1.86 U
X
Chassis
29.86 U
X
27.86 U
X
25.86 U
X
23.86 U
X
21.86 U
X
19.86 U
X
17.86 U
X
15.86 U
X
13.86 U
X
11.86 U
X
9.86 U
X
7.86 U
X
5.86 U
X
3.86 U
X
Copyright © 2015, Juniper Networks, Inc.
