TX Matrix Plus Router Quick Start
20
Table 6: Mounting Hole Locations for Installing a TX Matrix Plus Chassis
in an Open-Frame Rack (continued)
Hole
Distance Above U Division
42
24.25 in. (61.6 cm)
36
20.75 in. (52.7 cm)
30
17.25 in. (43.8 cm)
24
13.75 in. (34.9 cm)
18
10.25 in. (26.0 cm)
12
6.75 in. (17.1 cm)
The holes in the front-mounting flanges are spaced at 2 U (3.5 in. or 8.9 cm).
Table 7: Mounting Hole Locations for Installing a TX Matrix Plus Chassis
in a Four-Post Rack
Hole
Distance Above U Division
87
50.50 in. (128.3 cm)
81
47.00 in. (119.4 cm)
75
43.50 in. (110.5 cm)
69
40.00 in. (101.6 cm)
63
36.5 in. (92.7 cm)
57
33.00 in. (88.8 cm)
51
29.50 in. (74.9 cm)
45
24.26 in. (61.6 cm)
39
22.51 in. (57.2 cm)
33
19.01 in. (48.3 cm)
27
15.51 in. (39.4 cm)
21
12.00 in. (30.5 cm)
15
8.50 in. (21.6 cm)
9
5.00 in. (12.7 cm)
Chassis
13.86 U
X
11.86 U
X
9.86 U
X
7.86 U
X
5.86 U
X
3.86 U
X
28.86 U
26.86 U
24.86 U
22.86 U
20.86 U
18.86 U
16.86 U
14.86 U
12.86 U
10.86 U
8.86 U
6.86 U
4.86 U
2.86 U
Copyright © 2015, Juniper Networks, Inc.
