TX Matrix Plus Router Quick Start
Step 5: Install the TX Matrix Plus Rear Cable Management System and Front Cable
Manager
22
Figure 10: Console and Auxiliary Serial Ports on the TXP-CB
Figure 11: Console and Auxiliary Serial Port Connector
For instructions to install the rear cable management system and front cable manager,
see the TX Matrix Plus Router Hardware Guide.
Auxiliary port
Console port
