4
Command Line Interface
Command Usage
• Use the policy-map command to specify the name of the policy map, and
then use the class command to configure policies for traffic that matches
criteria defined in a class map.
• A policy map can contain multiple class statements that can be applied to the
same interface with the service-policy command (page 4-199).
• You must create a Class Map (page 4-195) before assigning it to a Policy Map.
Example
This example creates a policy called "rd_policy," uses the class command to specify
the previously defined "rd_class," uses the set command to classify the service that
incoming packets will receive, and then uses the police command to limit the
average bandwidth to 100,000 Kbps, the burst rate to 1522 bytes, and configure the
response to drop any violating packets.
Console(config)#policy-map rd_policy
Console(config-pmap)#class rd_class
Console(config-pmap-c)#set ip dscp 3
Console(config-pmap-c)#police 100000 1522 exceed-action drop
Console(config-pmap-c)#

class

This command defines a traffic classification upon which a policy can act, and enters
Policy Map Class configuration mode. Use the no form to delete a class map and
return to Policy Map configuration mode.
Syntax
[no] class class-map-name
class-map-name - Name of the class map. (Range: 1-16 characters)
Default Setting
None
Command Mode
Policy Map Configuration
Command Usage
• Use the policy-map command to specify a policy map and enter Policy Map
configuration mode. Then use the class command to enter Policy Map Class
configuration mode. And finally, use the set and police commands to specify
the match criteria, where the:
- set command classifies the service that an IP packet will receive.
- police command defines the maximum throughput, burst rate, and the
action that results from a policy violation.
•
You can configure up to 16 rules per Class Map. You can also include multiple
classes in a Policy Map
4-196
.
