Cat.No. V034-E1-5
NT30/30C
Programmable Terminal
OPERATION MANUAL

Advertisement

Table of Contents
loading

Related Manuals for Omron NT30

Summary of Contents for Omron NT30

  • Page 1 Cat.No. V034-E1-5 NT30/30C Programmable Terminal OPERATION MANUAL...
  • Page 2 NT30/30C Programmable Terminal Operation Manual Revised January 2001...
  • Page 3 OMRON. No patent liability is assumed with respect to the use of the information contained herein. Moreover, because OMRON is constantly striving to improve its high-quality products, the information contained in this manual is subject to change without notice.

  • Page 4: Table Of Contents

    ......Role and Operation of NT30/30C ......... . .
  • Page 5 ........Maintenance of the NT30/30C .

  • Page 6: About This Manual

    NT30/30C operation. Section 4 describes the functions of the NT30/30C when it is connected to a PC. Section 5 describes how to use the NT30/30C when it is connected to the PC using a Host Link or NT Link. Section 6 describes the corrective action to take when the system does not operate normally, and how to carry out daily maintenance of the NT30/30C.

  • Page 7: Precautions

    PRECAUTIONS This section provides general precautions for using the Programmable Terminal. The information contained in this section is important for the safe and reliable application of the Programmable Ter- minal. You must read this section and understand the information contained before attempting to set up or operate a Programmable Terminal.

  • Page 8: Intended Audience

    OMRON rep- resentative. Make sure that the ratings and performance characteristics of the PT are suffi- cient for the systems, machines, and equipment, and be sure to provide the sys- tems, machines, and equipment with double safety mechanisms.

  • Page 9: Safety Precautions

    Safety Precautions Safety Precautions Read these safety precautions carefully and make sure you understand them before using the Programmable Terminal so that you can use it safely and cor- rectly. WARNING S Never attempt repairs, modification or disassembly. You could sustain an elec- tric shock.
  • Page 10 Safety Precautions S Do not apply an AC power supply across the power supply terminals. S Use a DC power supply with a low voltage fluctuation. S When complying with EC low voltage directives use a power supply with rein- forced insulation.

  • Page 11: Functions Of The Nt30/30C

    SECTION 1 Functions of the NT30/30C This section gives the operation examples and characteristics of the NT30/30C so that you will understand the applications of the NT30/30C. Role and Operation of NT30/30C ..........

  • Page 12: Role And Operation Of Nt30/30C

    – is defective. Panel Switch Functions Setting touch switches on the NT30/30C can be set up to allow workers to use the NT30/30C as a control panel. Production data input to the NT30/30C can be transmitted to a PC. Electroplating Control...

  • Page 13: Operations Of Nt30/30C

    Receives Data from a PC NT30/30C can be connected to a PC by a Host Link or NT Link and receive nec- essary data from the PC. Host Link, NT Link Sends Data to a PC Data input through a touch panel can be sent to a PC.

  • Page 14: Functions Of Nt30/30C

    Construction Best Suited to the FA Environment • Easy-to-read screen even in direct sunlight. • The panel is a LCD panel with white/red backlight for the NT30, and an STN color LCD panel with backlight for the NT30C. • Its backlight unit and battery can be replaced at the operation site.

  • Page 15: Principal Functions Of Nt30/30C

    Expanded I/O Functions on B7A Units addition to fixed displays, numeric keys and character keys can be set inside The NT30/30C can receive a switching input from a B7A the window. The window need be Unit, and turns ON/OFF the output.

  • Page 16: Displays

    The NT30/30C can display various kinds of elements such as characters, numer- ic value, lamps, touch switches, and graphs on a screen. The screen data dis- played on the NT30/30C are created by using the NT-series Support Tool on a computer.

  • Page 17: System Configuration

    Section System Configuration This section gives the basic configuration of a system that uses an NT30/30C. Use an RS-232C cable or an RS-422A cable to connect to a PC. Refer to the manuals for individual devices for information on devices other than the NT30/30C in the system.

  • Page 18: Communications Using The Direct Connection Function

    A direct connection enables reading the data to be displayed on the NT30/30C from a memory area in the PC and writing it to a memory table in the NT30/30C. Also, the data input at the NT30/30C can be written to a PC memory area. The NT30/30C screen status can be switched according to PC memory area data, and NT30/30C status data can be written to a PC memory area.
  • Page 19 PC. By changing the contents of the bits and words, the NT30/30C can be controlled by the PC. It is also possible to send data to the PC by pressing the touch switches on the NT30/30C.
  • Page 20 Switch 2: OFF (IR/CIO 000101) Lamp #2 (IR/CIO 000101) The PC’s bit status can be displayed by lamps on the NT30/30C. The lamp lights or flashes when the PC’s bit status (i.e., the lamp bit) is ON (1), and goes OFF when it is OFF (0).
  • Page 21 Communications Using the Direct Connection Function Section S Character String Memory Table (page 136) Allocated to: Words NT30/30C (“a”, “b”) (“c”, “d”) (“e”, “f”) Character string memory table entry 1 Number of words allocated: 3 words First word: DM0100 The character string memory table is allocated to words in the PC. If word con-...
  • Page 22 Copy PT Status Notify Area (NT30/30C to PC) The PT Status Notify Area is used to notify the PC of changes in the NT30/30C status. When a change is made in the NT30/30C status, the change is written to this area in the PC. By reading the data from the area, the NT30/30C status can be checked from the PC.

  • Page 23: Before Operating

    Before Operating Section Before Operating Use the procedure given below to start the NT30/30C. NT30/30C NT-series Support Tool Install NT-series Check and change Set the DIP switch. Support Tool on the the PC settings. computer. (page 18) S For the Host Link, refer...
  • Page 24 Before Operating Section Refer to the following manuals for the product information. Product Manual Title Cat No. System Installer NT-series Support Tool for Windows Operation Manual V061-E1-j NT-series Support Tool NT-series Support Tool Operation Manual V028-E1-j NT-series Support Tool for Windows Operation Manual V061-E1-j SYSMAC CPM1 Operation Manual W262-E1-j...

  • Page 25: Hardware Settings And Connections

    SECTION 2 Hardware Settings and Connections This section describes the settings of the NT30/30C, connections to a PC, and other hardware settings. Description of Parts and Settings ..........

  • Page 26: Description Of Parts And Settings

    DIP switch on the NT30/30C. Caution On unpacking the NT30/30C, check its external appearance and confirm that there is no damage. Also confirm that there is no abnormal noise on shaking the Unit lightly. The product may malfunction if it is damaged.
  • Page 27 Contrast control Use a fine flat-blade screwdriver. Turn clockwise to increase the brightness. Reset switch Used to initialize all the statuses of the NT30/30C. However, the screen data memory and memory switches retain their statuses before initialization. Printer connector Connect the printer cable here. Output...

  • Page 28: Dip Switch Settings

    Description of Parts and Settings Section 2-1-2 DIP Switch Settings Set the NT30/30C operation status with the DIP switch located in the bottom right corner on the rear side of the body. RESET –CONTRAST 1 2 3 4 5 6 7 8...

  • Page 29: Installation

    Before switching ON the power for the first time, set DIP switch pin 6 of the NT30/30C to ON (they are set to OFF on shipping). If they are left OFF, messages will not be displayed normally.

  • Page 30: Power Supply Connection

    Installation Section (1) Open a hole, shown below, in the panel and install the NT30/30C from the front side of the panel. +0.5 mm 131.0 0 mm +0.5 mm 184.0 0 mm (2) Attach the panel fittings at four positions for the upper/lower sides and at two positions for the right and left sides, shown below, on the rear side of the NT30/30C.

  • Page 31: Connecting To The Support Tool

    2-2-3 Ground Wire Connection The NT30/NT30C has a functional ground terminal. To prevent malfunctions due to excessive noise, or to prevent electric shocks, wire the NT30/NT30C to a ground of 100 Ω or less using a separate ground wire (2 mm min.).

  • Page 32: Installing The System Program

    (page 281). Installing the System Program With the NT30/NT30C, the system program is not fixed and can be installed (or re-installed). This means that the system program can be easily replaced when grading up or changing the system configuration.

  • Page 33: Connection To A Pc By Host Link Via Rs-232C

    In the System Installer settings, specify the type of PT to which the system pro- gram is installed. Specify either NT30 or NT30C as the PT model (with DOS versions, the setting is as the NT-series model under the tool settings). Make other settings according to the operating conditions of the System Installer.
  • Page 34 Connection to a PC by Host Link via RS-232C Section PC Series CPU Units with the Host Link CPU Units Connectable Using Host Link Unit or Connect- Function Built In a Host Link Unit or Communica- Communications able PC tions Board Board CS1G-CPU42/43/44/45 (-EV1) CS1G-CPU42/43/44/45 (-EV1)

  • Page 35: Connecting The Nt30/30C

    Connecting to a PC with a 25-pin Connector Use a connector cable with a 25-pin connector on one end and a 9-pin connector on the other end (NT30/30C side) to connect the NT30/30C to a PC with a 25-pin connector.
  • Page 36 Communications This is a 25-pin RS-232C connector. Use a connector cable with a 25-pin conne- port 1 ctor on one end and a 9-pin connector on the other end (NT30/30C side). (RS-232C) S To Connect to Communication Port 2 Communications port 2 This is a 9-pin RS-232C/RS-422A connector.

  • Page 37: Pc Switch Settings

    Connecting the NT30/30C to a C-series CQM1H With C-series CQM1H PCs, in addition to the CPU Unit’s RS-232C port and peripheral port, the NT30/NT30C can also be connected to port 1 of the Serial Communications Board. Provide an RS-232C, 9-pin connecting cable.
  • Page 38 For details, refer to Selecting the Host Link Baud Rate (page 86). The 1-to-N setting enables BCC (Block Check Character). It is not possible to connect more than one NT30/30C in a single Host Link. When using the CVM1/CV series, always set CPU Unit execution processing Correct use (execution control 2) in the PC Setup to synchronous processing.
  • Page 39 Connection to a PC by Host Link via RS-232C Section Setting the Rear Switches S 1-to-1/1-to-N selection (DIP switch) Set #3 to ON. selector switch S CTS selection (selector switch) External Set this always to 0 V (ON). 0V (ON) S C500/C1000H Rack-mounting Host Link Unit: C500-LK201-V1 Setting the Front Switches Host...
  • Page 40 Connection to a PC by Host Link via RS-232C Section S C500/C1000H Rack-mounting Host Link Unit: C500-LK203 Setting the Rear Switches S I/O port selection (selector switch) Set this to RS-232C. S Unit #, parity, and transfer code (DIP switch SW1 pins 5V supply 1 to 7) Set pins 1 to 7 to OFF (0).
  • Page 41 Setting the Front Switches Set the operating conditions with the CPU Bus Unit setting functions when a CVM1/CV-series Host Link Unit is connected to the NT30/30C. The CPU Bus Unit setting can be made directly from the Programming Device (CX-Program- mer) or the CPU Bus Unit setting information created with a Programming De- vice can be transferred to the CPU Unit.
  • Page 42 Connection to a PC by Host Link via RS-232C Section Connecting the NT30/30C to a CS1-series Serial Communications Unit S CS1-series Rack-mounting Model: CS1W-SCU21 Setting the Front Switches Set the unit number of the Serial Communications Unit using the rotary switch on the front of the Unit.
  • Page 43 S C-series CjjH, CVM1/CV-series (-EVj) Set the operating conditions with the PC Setup functions when a CjjH, CVM1/CV-series CPU Unit is connected to the NT30/30C. The PC Setup can be made directly from the Programming Device (CX-Programmer) or the PC Setup information created with a Programming Device can be transferred to the CPU Unit.
  • Page 44 PC Setup. Item Contents of Settings at Host Communications Host Link mode Baud rate Set to the same baud rate as the NT30/NT30C (See note 1.) Stop bit 2 stop bits Parity Even Data length ASCII 7 bits...
  • Page 45 Connection to a PC by Host Link via RS-232C Section S Peripheral Port of CPM2A, CPM2C, CQM1H, SRM1 Word Setting Setting Contents Host Link mode DM6650 0001 Conditions set by the contents of DM. Data length: 7 bits, 2 stop bits, even parity, 0303 baud rate: 9,600 bps DM6651...
  • Page 46 Connection to a PC by Host Link via RS-232C Section DIP Switch Setting for C200HX/HG/HE(-Z), CQM1, CQM1H With the C200HX/HG/HE(-Z), CQM1, and CQM1H, in order that the PC Setup settings (data memory) are enabled, set the DIP switch on the front panel in the way shown below.
  • Page 47 9,600 bps, there is no need to make any changes to the default set- tings. Item Contents of Settings at Host Baud rate Set to the same baud rate as the NT30/NT30C (See note 1.) Stop bit 2 stop bits Parity Even...
  • Page 48 Setting the Front Switches Set DIP switch 4 or 5 of the CPU Unit according to the port to which the NT30/NT30C is connected in the following way. DIP Switch (Inside Battery Cover) When the NT30/NT30C is connected to the peripheral port, set SW4 to ON (perform com- munications according to PC Setup settings).
  • Page 49 Connection to a PC by Host Link via RS-232C Section Area). After the settings have been written, they will be enabled when the power supply is reset, the Unit is restarted, the communications ports are restarted, or a STUP instruction is executed. The DM Area words that are allocated and the contents of the settings are shown in the following table.

  • Page 50: Connection To A Pc By Host Link Via Rs-422A

    Connect the NT30/30C to an OMRON PC by using the RS-422A Host Link meth- If the distance between the NT30/30C and the PC is greater than 15 m, this meth- od should be used. The maximum distance over which a connection can be made is 500 m.
  • Page 51 CPM1-CIF01 RS-232C Adapter, or the CPM1-CIF11 RS-422A Adapter is required. (*2) Connection to CVM1/CV series PC CPU Units that are not suffixed “-Vj” is not possible. In the case of these CPU Units, make the connection to the NT30/30C by using a Host Link Unit.

  • Page 52: Parts Required For Connection

    One connector and one connector cover is supplied with the PC. However, a cable of the type recommended by OMRON must be prepared. For details on making the cable, refer to Making the Cable on page 279. The table below lists the components supplied with each Unit and the recommended cables.

  • Page 53: Connector Specifications And Wiring For Each Unit

    S Ground the FG terminal of the PC to 100 Ω or less. For details, refer to the Correct use manual for the PC. S Switch OFF the NT30/30C power supply before connecting or disconnecting a connector. S After connecting the connector cable, be sure to secure the connector with screws.
  • Page 54 Connector cover RS-422A cable S Connecting the NT30/30C to a C-series Host Link Unit (insulated) C-series Host Link Connector Specifications - Applicable Host Link Units: C500-LK203 (insulated) - Electrical characteristics: Conform to EIA RS-422A - Signal direction: Signal input and output is relative to the Host Link Unit.
  • Page 55 Connector cover RS-422A cable S Connecting the NT30/30C to a CVM1/CV-series Host Link Unit CVM1/CV-series Host Link Unit Connector Specifications - Applicable Host Link Units: CV500-LK201 (communication port 2) - Electrical characteristics: Conform to EIA RS-422A - Signal direction: Signal input and output is relative to the Host Link Unit.
  • Page 56 Connection to a PC by Host Link via RS-422A Section S Connecting the NT30/30C to a CVM1/CV-series CPU Unit CVM1/CV-series CPU Unit Connector Specifications - Applicable Host Link Units: CV500-CPU01-EV1 CV1000-CPU01-EV1 CV2000-CPU01-EV1 CVM1-CPU01-EVV CVM1-CPU11-EVV CVM1-CPU21-EVV Only the CVM1/CV-series CPU Units of version 1 (suffix of “-EV1”) or later can be connected to the NT30/30C.
  • Page 57 Connection to a PC by Host Link via RS-422A Section S Connecting the NT30/30C to a Communications Board on a C200HX/HG/HE(-Z) or to a Serial Commu- nications Board on a CS1-series PC or CQM1H Board RS-422A Connector Specifications - Applicable Boards:...

  • Page 58: Pc Switch Settings

    Section 2-6-5 PC Switch Settings When the NT30/30C and PC are connected to each other, set the conditions at the PC Host Link Unit or the CPU Unit as given in the table below. The following is a general description of switch settings.
  • Page 59 Connection to a PC by Host Link via RS-422A Section C200H-LK202-V1 This Unit has an RS-422A connector. S Terminator setting (selector switch) Set this switch to ON. selector 1–to–1 switch Note: Set the link adapter to ON also. protocol External (ON) (ON) 1–to–N...
  • Page 60 Connection to a PC by Host Link via RS-422A Section Setting the Rear Switches - C500-LK203 S I/O port selection (selector switch) - If connecting to an RS-232C connector, set this to RS-232C. f connecting to an RS-422A connector, set this to RS-422A. S Machine No., parity, transfer code settings 5V supply (DIP switch SW1 pins 1 to 7)
  • Page 61 Setting the Front Switches Set the operating conditions with the CPU Bus Unit setting functions when an NT30/30C and a CVM1/CV-series Host Link Unit is connected to the NT30/30C. The CPU Bus Unit setting can be made directly from the Programming Device (CX-Programmer) or the CPU Bus Unit setting information created with a Pro- gramming Device can be transferred to the CPU Unit.
  • Page 62 Connecting to a CPU Unit Set the communication conditions with the PC Setup functions when a CVM1/CV-series Host Link Unit is connected to the NT30/30C. The PC Setup can be made directly from the Programming Device (CX-Programmer) or the PC Setup information created with a Programming Device can be transferred to the CPU Unit.
  • Page 63 Note: Set the Link Adapter to ON also. PC Setup Settings Set the following communications settings in the PC Setup. Item Possible Settings Baud rate Set to the same baud rate as the NT30/NT30C (See note 1.) Stop bit 2 stop bits Parity Even Data length...
  • Page 64 Contents of Settings at Host I/O port RS-422A Communications Host Link mode Baud rate Set to the same baud rate as the NT30/NT30C (See note 1.) Stop bit 2 stop bits Parity Even Data length ASCII 7 bits Unit # Set the Host Link baud rate to 9,600 bps or 19,200 bps with the memory switch for the baud rate.
  • Page 65 Connection to a PC by Host Link via RS-422A Section Connecting the NT30/30C to a C-series CPM2C The CPM2C has only one connector, which is the same shape as the CS1-series peripheral port. The signals in this connector, however, are divided internally into those for the RS-232C port and those for the peripheral port.

  • Page 66: Connection To A Pc By The Nt Link

    To connect an NT30/30C to a PC by the NT Link method, the communications method memory switch of the NT30/30C must be set to NT Link. For details on the communication method memory switch setting, refer to Selecting of the Host Communication Method (page 85).
  • Page 67 Connection to a PC by the NT Link Section PC series CPU Units with the NT CPU Units Connect- Connectable Link Function Built In able Using a Commu- nications Board CPM1-10CDR-j (*1) CPM1-20CDR-j (*1) CPM1-30CDR-j (*1) CPM1-30CDR-j-V1 CPM1A-10CDj-j (*1) CPM1 CPM1A-20CDj-j (*1) CPM1A-30CDj-j...

  • Page 68: Connecting The Nt30/30C

    2-7-2 Connecting the NT30/30C Refer to the illustrations below to select the appropriate cable for the Unit con- nectors and connect the NT30/30C to the PC. A Host Link connector cable can also be used. To make a connector cable, refer to the appendix Making the Cable for Connection to the PC (page 271).

  • Page 69: Pc Switch Settings (Rs-232C At Pc Side)

    2. RS-232C port of Serial Communications Board. For details of PC Setup operations, refer to the manual for the PC used. Connecting the NT30/30C to a C-series CPM2C The CPM2C has only one connector, which is the same shape as the CS1-series peripheral port.
  • Page 70 Connection to a PC by the NT Link Section DIP Switch Setting for C200HX/HG/HE(-Z), CQM1, CQM1H With the C200HX/HG/HE(-Z), CQM1, and CQM1H, in order that the PC Setup settings (data memory) are enabled, set the DIP switch on the front panel in the way shown below.

  • Page 71: Pc Switch Settings (Rs-422A At Pc Side)

    Connection to a PC by the NT Link Section Switch Setting for the RS-232C Adapter When using the CPM1-CIF01 RS-232C Adapter, set the mode setting switch in the way shown below. CPM1 -CIF01 CPM1 S Set the mode setting switch to NT (down position).
  • Page 72 Connection to a PC by the NT Link Section Setting the Front Switches S Host Link communications method (selector switch) - Set to RS-422A. I/O port selector S Communications method (DIP switch pin 3) switch RS-232C Set pin 3 to ON (NT Link). RS-422A S Terminator setting (DIP switch pin 6) Set pin 6 to ON (terminating resistance enabled).

  • Page 73: Connecting A Printer

    Hard copies of screens can be printed (printing of screen images) onto a printer connected to the NT30/30C. In order to make a hard copy at a printer connected to the NT30/30C, it is neces- sary either to create a screen print key as a touch switch on the screen to be printed during screen creation, or to issue a print instruction from the PC.

  • Page 74: Connection Of Expanded I/O

    Connection of Expanded I/O Section 2-8-1 How to Connect Connect the printer to the NT30/30C with a Centronics cable. The length of the cable should not exceed 3 meters. Reference If the connection cable is connected or disconnected while the power of the printer is on, the NT30/30C may malfunction.

  • Page 75: B7A Interface Unit Specifications

    Connection of Expanded I/O Section Transmission Delay + – Terminal Wiring Type I/O Format Model Classification Time Configuration 16 output points Screw terminal Standard (Typ. 19.2 ms) NPN open collector + only B7A-R6B11 100 mA/point 100 mA/point B7A-R6B31 PNP open collector –...

  • Page 76: B7A Interface Unit Part Names

    (1) Peel off the label on the right side of the rear face of the NT30/30C. Under- neath the label are the connector and screw holes for installing the B7A In-...

  • Page 77: B7A Interface Unit Settings

    Connection of Expanded I/O Section (2) As shown in the figure below, install the NT30/30C on the rear face of the NT30/30C, and secure it with the two mounting screws. Mounting screws 2-9-5 B7A Interface Unit Settings Set the operating conditions of the B7A Interface Unit as shown below.
  • Page 78 Connection of Expanded I/O Section Connecting a B7A Unit with 16 Input Points - When separate power supplies are provided (DIP switch SW1 pin 2 set- ting: Standard) B7A Interface Unit B7A Unit (16 input points) Power Power S-IN S-OUT supply supply “–”...
  • Page 79 Connection of Expanded I/O Section - When using a common power supply (DIP switch SW1 pin 2 setting: High speed) B7A Interface Unit B7A Unit (16 input points) Power Power S-IN S-OUT supply supply “–” “+” Shield Power Power supply supply “+”...
  • Page 80 Connection of Expanded I/O Section - When separate power supplies are provided (DIP switch SW1 pin 2 set- ting: High speed) B7A Interface Unit B7A Unit (16 output points) Power Power S-IN S-OUT supply supply “–” “+” Shield Power Power supply supply “+”...
  • Page 81 Connection of Expanded I/O Section - When using a common power supply (DIP switch SW1 pin 2 setting: Standard) B7A Interface Unit B7A Unit (8 input points, 8 output points) Power Power S-IN S-OUT supply supply “–” “+” S-OUT – Power Power –...

  • Page 82: System Menu Operation

    System Menu Operation This section describes the operation of the System Menu focusing on the procedure to start up the NT30/30C. Functions that are convenient to use the NT30/30C and those that are useful for the system maintenance are also explained here.

  • Page 83: Operation Flow By The System Menu

    Follow the procedure below when using the NT30/30C for the first time or when changing the system. System Program Installation When using the NT30/30C for the first time, erase the system program loaded on shipping, and transfer the new system program to the NT30/30C by using the NT series system installer.

  • Page 84: Operation Modes And The System Menu

    For details on the system program installation method, refer to 2-4 Installing the System Program (page 22). If the NT30/30C has failed to start up normally; an error message is displayed or no screen is displayed, memory needs to be initialized.

  • Page 85: Menu Tree

    Operation Modes and the System Menu Section 3-3-2 Menu Tree The System Menu allows the user to effect various NT30/30C functions by using the touch switches. The NT30/30C’s functions with respect to the System Menu are related as shown below.

  • Page 86: Operations With The System Menu

    The RUN indicator goes OFF when the System Menu is displayed. The NT30/30C display screen has four touch switches to display the System Menu in the four corners (about 7.2 mm x 7.2 mm size). Press any two of these switches at the same time to call the System Menu screen.

  • Page 87: Initializing Memory

    • The screen (touch switches) is not pressed for over 10 seconds. Initializing Memory If the NT30/30C is used for the first time or if the screen data is ruined and the NT30/30C cannot be normally started, the memory needs to be initialized.

  • Page 88: Initialization Of The Screen Data

    Initializing Memory Section The following memory data can be initialized. • Image data memory • Memory tables • Display history The screen data is initialized regardless of the setting for the resume function (see page 96). 3-4-1 Initialization of the Screen Data The screen data can be initialized by either of the following two methods.
  • Page 89 Be sure to turn the power OFF before setting the NT30/30C DIP switch. Set the DIP switch as follows to initialize the screen data memory. Operation 1 Set DIP switch SW2 pin 4 on the NT30/30C to ON and turn the power ON. Select “Yes.” The screen data Initialize Screen Memory? memory is initialized.

  • Page 90: Initialization Of The Memory Tables

    Initializing Memory Section S The NT30/30C DIP switch SW2 pin 4 is used to enable/disable the screen data Reference forced initialization. Setting this to ON selects enable initialization, and OFF to disable it. S Regardless of whether initialization is executed or not, on completion of the operation, switch DIP switch SW2 pin 4 OFF while the power to the NT30/30C is OFF, then start up the NT30/30C again.

  • Page 91: Initialization Of The Display History Data Memory

    Initialize Memory Table? The memory table is initial- ized. • If no is selected instead of yes, the NT30/30C returns to the Initialize Memory Menu without initializing the memory. Upon completion of memory table initialization, the NT30/30C returns to the Ini- tialize Memory Menu.

  • Page 92: Setting Communications With The Pc Using Memory Switches

    Setting Communications with the PC Using Memory Switches The NT30/30C can be connected to a PC by the Host Link or NT link. The link can be selected by setting the memory switch. Also, the Host Link baud rate, auto- matic reset function, RS-232C communication conditions, etc.
  • Page 93 The memory switches can also be set in “System Setting” under “PT Configura- tion” on the NT-series Support Tool. The settings made using the NT-series Sup- port Tool are written to the NT30/30C on screen data registration. For details, refer to the NT-series Support Tool for Windows Operation Manual (V061).

  • Page 94: Selecting The Host Communications Method

    Section 3-5-1 Selecting the Host Communications Method The NT30/30C can be connected to a PC by the Host Link or NT link. Either link can be selected by setting the Communications Method memory switch. The factory setting has been made to the Host Link. Select the communications method that is supported by the PC to be connected.

  • Page 95: Selecting The Host Link Baud Rate

    Setting Communications with the PC Using Memory Switches Section 3-5-2 Selecting the Host Link Baud Rate When the Host Link is used, the baud rate of the communications with the PC can be set. Use the Baud Rate switch and select 9600 bps or 19200 bps. If the NT link has been selected, the Host Link baud rate setting does not have any effect.

  • Page 96: Selecting The Host Link Communications Port

    Section 3-5-3 Selecting the Host Link Communications Port When using the NT30/30C with the Host Link, the port for communications with the PC (communication type) can be selected. Select either RS-232C or RS-422 by using the Communications Port” memory switch.

  • Page 97: Selecting The Automatic Reset Function

    Setting Communications with the PC Using Memory Switches Section 3-5-4 Selecting the Automatic Reset Function The Automatic Reset memory switch is used to set whether or not the commu- nication is automatically reset after the occurrence of a communication error. The factory setting has been made to exist.

  • Page 98: Registering The Screen Data

    The screen data is created by using the NT-series Support Tool and registered to the NT30/30C screen data memory. This section describes the procedure to reg- ister the screen data to the NT30/30C. For the screen data creation and NT-se- ries Support Tool operation, refer to the NT-series Support Tool Operation Manu- Transmission –...
  • Page 99 ON the NT30/30C. Turn ON the computer, start up the NT-series Support Tool, and open the screen data to be transmitted. Enter the Transmit Mode by operating the menu of the NT30/30C shown be- low. Select “Transmit Mode.”...

  • Page 100: Starting The Operation

    • The cable connecting the NT30/30C to the computer on which the NT-series Support Tool is running is disconnected or has a broken wire. • The Cancel touch switch on the NT30/30C screen is pressed to end the trans- mission during screen data transfer.

  • Page 101: System Settings

    3-8-1 Setting the Key Press Sound It is possible to set whether or not the key sound is sounded when a touch switch on the NT30/30C screen is pressed or an expanded I/O input comes ON by using the Key Press Sound memory switch.

  • Page 102: Using The Buzzer

    To set the buzzer to sound in other cases, the fol- lowing two procedures can be used. S Controlled by the PC It is possible to control the NT30/30C from the PC to sound the buzzer during the operation. Refer to 5-7 NT30/30C Status Control (page 239).
  • Page 103 System Settings Section To Stop the Buzzer Sound The buzzer sound can be stopped by the following operations. • Control by the PC • Switch the screen to a screen that does not have a buzzer attribute. • Press the touch switch to which the buzzer stop attribute has been set. •...

  • Page 104: Screen Saver Function

    Mode regardless of the buzzer setting. 3-8-3 Screen Saver Function The NT30/30C has a function that turns OFF the screen display if no operation is performed for a certain period of time to maximize the service life of the backlight and prevent the formation of an afterimage on the screen.

  • Page 105: Resume Function

    3-8-4 Resume Function The NT30/30C has a function to protect the contents of the memory tables (value setting key input, data from the PC, etc.) from being erased even if the power to the NT30/30C is shut OFF during operation. This function is called the resume function.
  • Page 106 Initialization of the Memory Tables (page 81). Reference If the voltage of the battery in the NT30/30C gets too low, the contents of the memory tables cannot be saved even if the resume function is effective. Use the memory switches to set whether or not the resume function is used.

  • Page 107: Screen Printing Function

    Section 3-8-5 Screen Printing Function The NT30/30C can print a hard copy of the displayed screens onto a printer con- nected to the NT30/30C. This function is called the screen printing function. The NT30/30C will continue operating even when such a hard copy is being printed.
  • Page 108 System Settings Section Each time the Printer touch < MEMORY SWITCH > Next Quit switch is pressed, the next item in the applicable cycle of Key Press Sound options below is selected: Buzzer Sound ESC/P COL. Screen Saver 10min ESC/P MONO. Resume Memory Table None PR201H COL.

  • Page 109: System Maintenance

    System Maintenance Section System Maintenance The NT30/30C has self-maintenance functions, such as display history record- ing, I/O check and PT setting display. 3-9-1 Using the Display History Recording Function The display history recording function is used to record the display sequence and frequency of screens during operation.

  • Page 110: System Maintenance

    System Maintenance Section - In Order of Occurrence Recorded data is displayed in order of occurrence. Screen# ( Y/ H: Mi) Message ( 93/ 23: 30) ( 93/ 02: 17) Quit ( 93/ 11: 05) 2000 ( 93/ 21: 48) - In Order of Frequency Recorded data is displayed in order of display frequency with the accumu- lated number of times each screen has been displayed.

  • Page 111: I/O Check

    System Maintenance Section Select “Display History.” [ MAINTENANCE MENU ] Quit Memory Switch Display History I/O Check PT Settings Init. Memory Select “Occurrence” or “Fre- [ History Record ] quency.” Quit The recorded data will be dis- played in accordance with the Occurrence selected method.
  • Page 112 40 dots (two regular touch switch widths). When using an NT30C, select white as the background color for the screen. 3-9-2 I/O Check The I/O operations for the following items of the NT30/30C are checked by the I/O check function. • Expansion I/O Unit (B7A Unit): Buzzer Check •...
  • Page 113 System Maintenance Section Select “I/O Check.” [ MAINTENANCE MENU ] Quit Memory Switch Display History I/O Check PT Settings Init. Memory Select “Exp. I/O Unit” (B7A [ I/O CHECK MENU ] Next Unit). Quit Buzzer Exp. I/O Unit Touch Switch Calendar Communication Battery...
  • Page 114 System Maintenance Section Checking the Touch Switches Execute a touch switch check by the menu operation from the System Menu shown below. Select “Maintenance Mode.” [ SYSTEM MENU ] Quit Transmit Mode Maintenance Mode Select “I/O Check.” [ MAINTENANCE MENU ] Quit Memory Switch Display History...
  • Page 115 Execute a NT30/30C-to-PC communication check by the menu operation from the System Menu shown below. The NT30/30C uses the same connector for connection to the NT-series Support Tool and RS-232C connection to the PC. To establish an RS-232C connection with the PC, disconnect the cable from the NT-series Support Tool and connect it to the PC: the communication check can then be performed.
  • Page 116 • When the check is finished, press the End touch switch. The Communication Check Menu will be redisplayed. Checking the LCD Display Check the NT30/30C LCD display by using the menu operation from the System Menu shown below. Select “Maintenance Mode.”...
  • Page 117 • To discontinue a screen display check, press the touch switch at the top right corner of the screen. The I/O Check Menu” will be redisplayed. Checking the Buzzer Check the NT30/30C buzzer by using the menu operation from the System Menu shown below. Select “Maintenance Mode.”...
  • Page 118 Calendar Communication Battery LCD Display Printer The RUN indicator on the front face of the NT30/30C will flash alternately green and red. The POWER indicator remains lit. • To quit the indicator check, press the LED Check touch switch again.
  • Page 119 System Maintenance Section Checking the Calendar and Time Check the setting of the internal clock function by using the menu operation from the System Menu shown below. Select “Maintenance Mode.” [ SYSTEM MENU ] Quit Transmit Mode Maintenance Mode Select “I/O Check.” [ MAINTENANCE MENU ] Quit Memory Switch...
  • Page 120 System Maintenance Section Checking the Battery Voltage Check the battery voltage by using the menu operation from the System Menu shown below. Select “Maintenance Mode.” [ SYSTEM MENU ] Quit Transmit Mode Maintenance Mode Select “I/O Check.” [ MAINTENANCE MENU ] Quit Memory Switch Display History...
  • Page 121 System Maintenance Section Checking the Printer Check communication with the printer by using the menu operation from the Sys- tem Menu shown below. Select “Maintenance Mode.” [ SYSTEM MENU ] Quit Transmit Mode Maintenance Mode Select “I/O Check.” [ MAINTENANCE MENU ] Quit Memory Switch Display History...
  • Page 122 Prev. Quit Backlight • When “Backlight” is selected, the backlight will start flashing. The NT30 has two backlight colors and this flashing follows the sequence shown below in the case of the NT30: Red only lights → red OFF → white only lights → white OFF → ...

  • Page 123: Checking The Pt Setting Status

    System Maintenance Section 3-9-3 Checking the PT Setting Status Checking the PT Setting Status Display the NT30/30C settings by using the menu operation from the System Menu shown below. Select “Maintenance Mode.” [ SYSTEM MENU ] Quit Transmit Mode Maintenance Mode Select “PT Settings.”...

  • Page 124: Nt30/30C Functions

    SECTION 4 NT30/30C Functions This section describes the functions of the NT30/30C. Creating and Transmitting Screen Data ........

  • Page 125: Creating And Transmitting Screen Data

    • Creating a new file; • Editing an existing file to create a new. The same screen data can be used for both the NT30 and NT30C. Also, NT-se- ries Support Tool for Windows can be used to convert screen data from the NT20S, NT620C, or NT625C for use with the NT30 or NT30C.
  • Page 126 Creating and Transmitting Screen Data Section Screen Data Creation Procedure The following gives the basic screen data creation procedure. Required settings and reference pages are given for each step of the procedure. 1, 2, 3... 1. After starting the Support Tool, open a screen file to use for storing the screen data from the File Menu.
  • Page 127 The following PT Configuration Window will appear when “New File” has been selected. (The name of the screen data file is input later.) 2. Set the PT Model to NT30 or NT30C and the PLC Vendor to OMRON and click the OK Button.
  • Page 128 4. Click the Control/Notify Area Tab to set the PT Status Control Area and PT Status Notify Area as described below before selecting the screen number. • PT Status Control Area: 5-7 NT30/30C Status Control (page 239) • PT Status Notify Area: 5-8 Notification of the Operating Status to the PC (page 244) 5.
  • Page 129 Creating and Transmitting Screen Data Section Open command. The creation screen for screen number 1 will also be dis- played. 6. From the Application Manager, the screen to be edited can be designated, screens can be copied, and memory tables can be edited. The following tables can be edited: •...
  • Page 130 Creating and Transmitting Screen Data Section 8. Double-click one of the screen numbers in the Application Manager to open the window to edit screen data. Data of one screen can be created by registering (laying out) the following display elements and attributes on the screen. •...
  • Page 131 Transmit the screen data created by using the NT-series Support Tool to the NT30/30C screen data memory. Connect the NT30/30C to the NT-series Support Tool and set the NT30/30C to Transmit Mode. Then, press the [F6] (Transmit) key in the File List screen to transmit the created screen data to the NT30/30C.

  • Page 132: Outline Of Functions

    Outline of Functions Section Outline of Functions 4-2-1 NT30/30C Screen This section gives the outline of the screen, which is the basis of all NT30/30C functions. For specific operating procedures, such as screen switching, refer to Switching the Screen Display (page 195).

  • Page 133: Color Display (Nt30C Only)

    Specify a color as an attribute for each display element when creating a screen on the NT-series Support Tool. The NT30 is not capable of color display. Available Colors The following eight colors can be selected: Black, blue, red, magenta, green, cyan, yellow, white The four color combinations below are exclusive ORed.
  • Page 134 Outline of Functions Section Transparent Display When two display elements overlap with each other, the background color of the overlying element conceals the underlaid display element. Besides the above eight colors, the color “transparency” is available for the back- ground of some display elements. When transparency is set, nothing appears behind a display element, and the display element or screen background color under it becomes visible.

  • Page 135: Characters And Figures That Can Be Displayed

    (2,000 characters) The NT30/30C is provided with marks, image data, and library data in addition to fixed characters. S Marks A mark is a graphic pattern combining 16 x 16, 32 x 32 and 64 x 64 dots. The 32- dot and 64-dot marks, however, are combinations of 4 (2 x 2) and 16 (4 x 4) 16-dot marks, respectively.
  • Page 136 Tool’s image data creation functionality. It is also possible to download files created using commercial image creation software and use them as image data for the NT30/30C. Image data for up to 224 images can be registered on a screen data file using 2-byte codes from FE20 to FEFF.
  • Page 137 Outline of Functions Section S Enlargement of Characters and Marks Characters and marks can be enlarged to the following scales. Image data and library data are exceptions. Wide High S Smoothing Characters (or marks) enlarged to x4 scales or larger are displayed with the outline automatically smoothed.
  • Page 138 Outline of Functions Section Graphic Types and Their Attributes On the NT30/30C, the following types of graphic can be entered and dis- played: Polylines Square Polygon * A continuous straight line with * A polygon with up to 255 up to 255 middle points can be drawn.

  • Page 139: Communications With The Pc

    4-2-4 Communications with the PC Using Host Link/NT Link The NT30/30C can communicate with a PC by using the Host Link or NT Link. Using these functions, bits and words can be allocated to almost any area in PC memory and data can be written to and read from these bits and words directly.

  • Page 140: Screen Displays

    Printer operating status Whether the printer is printing or stopped For the actual methods used to determine the operation status of the NT30/30C, see 5-8 Notifying the PC of the Operating Status (page 244). Note To ensure system safety, be sure to regularly confirm that the PT is operating normally by reading the PT Operating Status Bit at the host.
  • Page 141 Details on each screen type are given below. Normal Screens A normal screen is the basic screen of the NT30/30C. It is not necessary to select a screen type (overlapping or consecutive) to create screen data for a normal screen.
  • Page 142 Screen Displays Section The base screen used for registering the consecutive screens is called the par- ent screen, and the consecutive screens are called child screens. The current screen number and the total number of consecutive screens can be displayed in the top right corner of the screen. This is called the page number display.

  • Page 143: Screen Attributes

    The following several attributes can be set with one screen. S Buzzer Attribute This attribute will become effective to sound the buzzer in the NT30/30C when the screen to which this attribute has been set is displayed. The buzzer sound can be set as follows: Buzzer does not sound when the screen is displayed.
  • Page 144 S Backlight Attributes Select whether the backlight is lit or flashes when the screen is displayed. When using an NT30, these attributes can be used in conjunction with the backlight color attribute. There are two types of backlight attribute in the screen...

  • Page 145: Memory Tables

    Section Memory Tables The NT30/30C has three memory areas that can be written to and updated by the PC. There is a character string memory table for character data, a numeral memory table for numerical data, and a bit memory table for bit data.
  • Page 146 The character attributes are set in the edit screen when creating the screen data by using the NT-series Support Tool. The following characters can be displayed on the NT30/30C: Maximum number of characters displayed on Character...

  • Page 147: Numeral Memory Table

    8 colors 4-4-2 Numeral Memory Table The numeral memory table is an NT30/30C internal memory are used to store numeral data. Up to 1,000 numeral memory table entries can be used, and up to eight digits (four bytes) of numeral data (including signs) can be stored in each numeral memory table entry.
  • Page 148 When the NT30/30C is operated, the screen displays the contents of the numeral memory table entry. For the actual method used to modify a currently displayed numerical value, refer to Changing Displayed Numerals or Character Strings (pages 207, 209).

  • Page 149: Bit Memory Table

    The bit memory table is an internal memory area for bit data. The NT30/30C can use a maximum of 256 bit memory table entries. One bit sta- tus in the PC can be stored in a single bit memory table entry.

  • Page 150: Graphs

    When specifying the DM Area, specify the bit number (00 to 15) along with the word address. Graphs The contents of numeral memory table entries of the NT30/30C can be displayed as graphs as well as numeral data. Three types of graph can be displayed: Bar graphs, trend graphs, and broken line graphs.

  • Page 151: Bar Graph Functions

    Bar Graph Attributes The following attributes can be set with the NT30/30C for the bar graph display: S Graph Frame This attribute specifies a rectangular area used to display a graph.
  • Page 152 Graphs Section - Memory Table Access Method The numeral memory table entry number to be accessed is specified instead of a numeric value. With this method specified, data can be changed from the host during operation. S % Display % Value can be displayed. % Value can be calculated according to the following equation: Numeral memory table entry value –...

  • Page 153: Trend Graph Setting

    Although it is possible to select either direct or indirect as the access method with the NT-series Support Tool, only the direct setting is used by the NT30/30C. It is not possible to use hexadecimal values for bar graphs. If hexadecimal val-...
  • Page 154 When the displacement increases to the right, a graph varies as shown below. When a polygonal line reaches the end of a screen, it is cleared once and the NT30/30C starts drawing a polygonal line again from the first. Direction of increase...
  • Page 155 Graphs Section S Direction of Movement The normal type can select the direction that the display position of the latest data moves with the lapse of time. The pen recorder type can select the direc- tion that entire graph moves. Rightward Upward Leftward...
  • Page 156 S When the Graph Width Is Not an Integral Multiple of the Drawing Width In the normal type, when a graph is over the graph frame next time, the NT30/30C draws a graph of the latest data at the end of the frame.

  • Page 157: Broken Line Graph Setting

    Although it is possible to select either direct or indirect as the access method with the NT-series Support Tool, only the direct setting is used by the NT30/30C. It is not possible to use hexadecimal values for broken line graphs. If hexadeci- mal values are specified in numeral memory table entries for the graph values, the graph will not be displayed.
  • Page 158 Graphs Section - Background Color in a Frame (NT30C Only): 8 Colors Separate background color can be specified for positive and negative value display area. S Direction This attribute can select the direction of putting the memory table entry values in order.
  • Page 159 Graphs Section can be references for the graph frame width is determined by the following equation. Graph frame width (number of dots) y Number of memory table entries S % Data Value (Line Attribute) This attribute specifies the % data value at every polygonal line. For the speci- fying method, the same is also true as the bar graph.

  • Page 160: Lamps

    Lamps Section S If a graph is duplicated by drawing multiple graph lines of the same % value, it Reference is overwritten and displayed in the order of setting. At this time, since the part that the lines are duplicated is displayed by use of those colors of the Exclusive OR display (Refer to page 124), the line type and line color are displayed differ- ently than that specified.
  • Page 161 Be careful when creating a control program. Example 1: When the normal lamp is turned ON after updating the memory table entry Lamp OFF Lamp OFF Lamp ON OMRON Memory table Lamp ON entry update The characters are displayed in LAMP...

  • Page 162: Image/Library Lamp Function

    Lamps Section Example 2: When the memory table entry is updated while normal lamp is ON Lamp OFF Lamp ON Lamp ON OMRON OMRON Memory table Lamp ON entry update The characters The memory table are displayed in entry display area...

  • Page 163: Touch Switches

    Positions to be displayed during ON and OFF are specified. Touch Switches The NT30/30C has a function whereby input operations can be performed by us- ing touch panels displayed on the screen. NT30/30C screens can be switched or bit information can be sent to the PC by pressing (lightly touching) the touch switches on the panel.

  • Page 164: Functions Of Touch Switches

    Touch Switches Section S If touch switches are pressed in rapid succession, their inputs may not be Correct use successfully received. Confirm that the input of a touch switch has been successfully received before moving on to the next operation. S Note on pressing 3 touch switches When multiple touch are set in positions that form a row and three of these touch switches are pressed at the same time, a malfunction occurs due to...
  • Page 165 This attribute can specify the Touch Switch so as to be shown in reverse video when it is touched and operated. S Guide Display Labels can be assigned to touch switches. When the touch switch is ON, the label is displayed in reverse video in the case of an NT30 and in the exclusive...

  • Page 166: Stand Alone Function

    OFF color: 8 colors or transparency ON/Flashing, entry color: 8 colors 4-7-2 Stand Alone Function The NT30/30C can switch over the screen only by operating the switches without instructions from the PC. When screen data is created with the NT-series Support Tool, the screen number of a screen to be switched over is assigned to the input terminal of the touch switch.
  • Page 167 Touch Switches Section Screen Number in the Range 0 Set Screen number 0 is set to the touch switch 1. Menu Screen Previous screen Screen switchover S Instructed by the PC Operation 1 S Screen switchover key Operation 2 Menu Screen Touch switch is pressed Operation 1 Operation 2...

  • Page 168: Input Key Function

    Touch Switches Section 4-7-3 Input Key Function This is a function that allows touch switches to be used for input and is mainly used when using numeral/character string setting functions. Input keys are clas- sified into the following three types: Character keys (character string input function): Used to input character strings when using a character–string setting func- tion.

  • Page 169: Copy Key Function

    Two kinds of keys can be set: START key that starts the printing operation and CANCEL key that cancels the printing operation. Even when the screen hard copy is being carried out, the NT30/30C continues operation. Screen hard copy START key When this key is pressed, screen hard copy is started.

  • Page 170: Numeral Setting

    (2) The numeral value entered is displayed in the numeral setting area on a screen. (3) When the numeral value entered is confirmed, it is written into the numeral memory table entry and simultaneously sent to the host. Numeral setting input field NT30/30C Writing Notifying 1234 1234...

  • Page 171: Types Of Numeral Setting

    Numeral Setting Section - Range of Numeral Values Range of numeral values that can be entered differs depending on a sign. With a sign not displayed: 0 to 99999999 (8-digit) With a sign displayed: –9999999 to +99999999 (7-digit negative num- ber, 8-digit positive number) For a thumb wheel type, numeric values are up to 7-digit for both positive and negative numbers with signs displayed.
  • Page 172 Numeral Setting Section Using a Touch Panel Displayed in the numeral setting input column NT30/30C Writing Notifying 1234 1234 Numeral memory table 1 2 3 entry Enter 4 5 6 7 8 9 When the key is pressed, an input value is...

  • Page 173: Numeric Key Creation

    Numeral Setting Section 4-8-3 Numeric Key Creation In order to use the numeric key type numeral setting, it is necessary to create not only the numeral setting input column on a screen but also a numeric key for per- forming an input operation. Screen Attribute Setting A numeric key type can be selected by setting a screen attribute.

  • Page 174: How To Use Numeric Key Settings

    Numeral Setting Section Allocation of Numeric Keys Numeric keys can be allocated to the touch switches or B7A Unit. S Allocation to Touch Switches When the touch switches are used as numeric keys, the numeric keys allo- cated are specified when creating the touch switches. For numeral settings, the following numeric keys (system keys) can be used.
  • Page 175 Numeral Setting Section S Specifying the Column Using Numeric Keys The numeral setting input column is specified with the HOME, keys out of the numeric keys. A cursor can be moved between the numeral set- ting input columns using these keys as shown below. →...
  • Page 176 NT30/30C will operate as follows: - RETURN ( ) Key The display is cleared by 0. The NT30/30C starts entering the integer part. - Sign (+/–) Key The display is cleared by 0, but the sign is not reversed (when entering a deci- mal number or displaying a sign).
  • Page 177 Using touch switches set as copy keys (see page 160) allows you to input the val- ue or code (constant) in a numeral memory table entry into a numeral setting input field in a one-touch operation. NT30/30C Numeral memory Numeral...

  • Page 178: How To Use Thumbwheel Settings

    Numeral Setting Section 4-8-5 How to Use Thumbwheel Settings For numeral setting with a thumbwheel, a numeric value is entered by directly touching the increment/decrement (+, –) keys. Keys such as numeric key are not required. Entering the Numeric Values The numeric values are entered using the increment/decrement (+, –) keys pro- vided at each digit.

  • Page 179: Setting Items For Numeral Setting

    Numeral Setting Section 4-8-6 Setting Items for Numeral Setting For the numeral setting, the following items are set when being created with the NT-series Support Tool. However, for numeral setting of thumb wheel type, there are some restrictions on the setting of several items. Items to be Set S Numeral Memory Table Entry To Access The number of the numeral memory table entry is specified to register the nu-...

  • Page 180: Character String Setting

    (3) When the Enter ( ) key is pressed, the character string of the character string input column is written into the character string memory table entry and simultaneously notified to the PC. Character string setting input column NT30/30C Write + Notify Display NT30C...

  • Page 181: How To Enter Character Strings

    Character String Setting Section 4-9-2 How to Enter Character Strings An appropriate character string setting input column must be specified to be ready for an input operation before a character string is entered by the character key. S Specifying the Character String Setting Input Column To Be Entered The character string setting input column to be entered is specified by either ten-key, system key, or touch switch (numeral/character string setting cursor moving key).

  • Page 182: Pop-Up Window Function

    PC. 4-10 Pop-Up Window Function The NT30/30C features a pop-up window function, which is used to display win- dows overlaying the currently displayed screen (base screen). These windows can be opened whenever required by pressing touch switches.

  • Page 183: Functions Of Pop-Up Windows

    Pop-Up Window Function Section 4-10 4-10-1 Functions of Pop-Up Windows The functions of pop-up windows are described below. What is a Window? A window is a screen that can be displayed overlaying a currently displayed screen (the base screen). Its size and display position can be changed. Windows are mainly used for the following applications.
  • Page 184 (display area). The window will then open in a display area of the specified size and at the specified position. The following elements can be displayed in NT30/30C windows. If elements oth- er than these are registered on a window screen, they will not be displayed when the window opens.

  • Page 185: Opening And Closing Windows

    Pop-Up Window Function Section 4-10 4-10-2 Opening and Closing Windows Windows are opened and closed by using touch switches with the pop-up win- dow/keyboard function: either the window keys or cursor moving keys. Opening and Closing Windows with the Window Keys Window keys can be used in the following way to open and close windows (note that window keys can be created either on the base screen or in a window).

  • Page 186: Temporary Input Fields

    Pop-Up Window Function Section 4-10 Opening Windows with the Cursor Moving Keys It is possible to set a window key open function for the cursor moving keys used for numeral/character string setting, in addition to their cursor moving function. Doing this makes it possible to specify an input field and also display the window to be used in a one touch operation.
  • Page 187 Pop-Up Window Function Section 4-10 Numeral setting input Temporary input field (displays data being input) 1 2 3 4 5 6 555 . 44 7 8 9 ↑ – 4 1. 8 4 5 6 ↓ 0 0 2 .7 1 1 2 3 ±...
  • Page 188 Pop-Up Window Function Section 4-10 Operation Example Temporary input operation example Base Screen Window 5 input settings Temporary input field 8 integer digits, no Integer digits: 8; Decimal fraction digits: 0; 00000001 sign display (8 digits Sign display: No; Zero suppress: No can be displayed) Integer digits: 8;...

  • Page 189: Alarm List & History Display Functions

    4-11 4-11 Alarm List & History Display Functions The NT30/30C can monitor the state of PC bits of the host and display the corre- sponding message (using the character string memory table entry) or image/li- brary data (alarm list display) when a specific bit becomes 1 (ON).
  • Page 190 Alarm List & History Display Functions Section 4-11 Example: Message (character string No. 32) set to bit memory table entry num- ber 14 Character String table No. 13 entry No. 50 Character String table entry No. Image data FE52 A000000 Character String table No.
  • Page 191 Alarm List & History Display Functions Section 4-11 S Scrolling Keys Shown in Reverse Video Since these scrolling keys are automatically shown in reverse video when there are any messages in front or behind those keys, it is found whether or not there are any messages that are not displayed.
  • Page 192 Alarm List & History Display Functions Section 4-11 S Display Color (NT30C Only) Character color of a message is set. S Image/Library Data Code of image/library data displayed together with a message is set. S Screen Switchover Screen number displayed by the alarm list and history display function is set. S Bit (PC Address) Bit in the PC, to which the bit memory table entry is assigned, is set.

  • Page 193: Displaying The Alarm History

    1 (i.e., turns ON). The bits recorded in the alarm history are always monitored irrespective of the display screen of the NT30/30C. If the number of bits are increased excessively, the processing speed of the NT30/30C may become slower.

  • Page 194: Operation Of B7A Units

    4-12 Operation of B7A Units A B7A Unit can be used to connect external devices, such as switches and indi- cators, to the NT30/30C. This section describes the operation of the B7A Unit. The B7A Unit has the following five functions: •...

  • Page 195: Operation Of B7A Units

    Reference In order to use expansion I/O, the B7A Interface Unit intended specifically for expanded I/O must be installed on the NT30/NT30C and connected to the B7A Unit by cable. For the installation and connection methods, see 2-9 Connection of Expanded I/O (page 64).
  • Page 196 Operation of B7A Units Section 4-12 S Numeric Key (System Key) Function With the numeric keys (system keys) assigned to the input terminals, the input terminals can function similar to those keys specified. However, with the sys- tem keys assigned to the input terminals, those terminals cannot be used as the system keys other than the operation mode (system menu, etc.).
  • Page 197 For example, with the screen saver attribute set to the terminals without this function, the PT screen can be displayed when a person approaches to the NT30/30C, by combining with a sensor as shown below. NT30/30C During...

  • Page 198: Using Host Link And Nt Link

    SECTION 5 Using Host Link and NT Link This section describes how the NT30/30C can be used when using the Host Link and NT link. Outline of Host Link and NT Link Operations ........

  • Page 199: Outline Of Host Link And Nt Link Operations

    This section explains the fundamentals when using the Host Link/NT link - allo- cated bits and words, and the method for control of the NT30/NT30C and notifi- cation to the PC - and also describes the actual procedure used for screen switching.

  • Page 200: Nt30/30C Status Control And Notification To Pc

    Number of saved words: 3 Number of saved words: 1 Controlling the NT30/30C Status Using Allocated Bits and Words ..PT Status Control Area (PC to PT) The PT Status Control Area (PC to PT) is provided to control the NT30/30C sta- tus from the PC.
  • Page 201 Area and the PT Status Notify Area. S Screen Switch Settings (refer to page 195) Specify the screen # to switch the screen displayed on the NT30/30C. S Copy Memory Table Entry Settings (refer to page 212) Specify the memory table entry number to copy the contents of a memory table entry internally in the NT30/30C.
  • Page 202 0 1 0 0 1 0 0 0 Notifying the NT30/30C Status by Using Allocated Bits and Words ..PT Status Notify Area (PT to PC) The PT Status Notify Area (PT to PC) is provided to notify the NT30/30C status changes to the PC.
  • Page 203 The number of the numeral or character string table entry is written to the word when the numeral or character string memory table entry contents change due to the touch switch operation on the NT30/30C. (The contents of the word to which the numeral or character string table entry has been allocated also change.)

  • Page 204: Switching The Screen Display Using The Pt Status Control Area

    (pages 157, 187) or the next section, Switching the Screen Display (by Using a Bit Memory Table Entry. To switch the NT30/30C screen display by controlling from the PC, write a screen number at the screen switch setting in the PT Status Control Area.
  • Page 205 Notify Area (PT to PC) also change. S Startup Screen When the NT30/30C starts up, it displays the screen whose screen number is written in the screen switch setting. The startup screen set with the NT-series Support Tool is invalid.

  • Page 206: Switching The Screen Display Using A Bit Memory Table Entry

    (3) When the screen switch strobe flag turns ON, the number of the currently displayed screen is read and written to the currently displayed screen word in the PT Status Notify Area. In this case, the NT30/30C will not write the same screen twice.
  • Page 207 Screen Display Using the PT Status Control Area (page 195). To switch the screen displayed on the screen of the NT30/30C under the control of the PC, the allocated bit of the bit memory table entry in which the screen num- ber of the screen to be displayed is registered is set to 1 (ON).

  • Page 208: Notification Of Number Of Currently Displayed Screen

    To display the number of the currently displayed screen, use the currently dis- played screen word. When the screen has switched, the NT30/30C notifies the following to PT Status Notify Area (PT to PC) allocated to the PC. Screen switch notification: Screen switch strobe flag of the PT status word...
  • Page 209 Outline of Host Link and NT Link Operations Section By reading the currently displayed screen word when the screen switch strobe flag has turned ON, the number of the currently displayed screen on the NT30/30C is displayed. NT30/30C PT Status Notify Area Currently displayed screen...

  • Page 210: Memory Tables And Graphs

    (IR/CIO 11212) turns ON, the contents of DM0100 are transferred to DM0101. The number of the previously displayed screen is stored in word 0101. (2) The new screen number notified by the NT30/30C is read and transferred to DM0100. The number of the currently displayed screen is stored in DM0100.
  • Page 211 S Direct Specification Direct specification is a method of specification in which the contents of dis- played memory table entries are directly correlated with the contents of the al- located words. NT30/30C Allocated word (character string memory Character string table entry 51)
  • Page 212 During operation, automatic updating is performed to ensure that the currently displayed NT30/30C numeral memory table entry contents and PC word con- tents always match each other. There are two methods for accessing numeral memory table entries used for nu-...
  • Page 213 S Direct Specification Direct specification is a method of specification in which the contents of dis- played memory table entries are directly correlated with the contents of the al- located words. NT30/30C Allocated word (character string Character string memory table entry 18)

  • Page 214: Allocated Words And Display Of The Memory Tables

    Memory Tables and Graphs Section Setting the Words of the Numeral Memory Table When creating the screen data by using the NT-series Support Tool, make the following settings for each numbered numeral: S Initialization setting Set whether or not the PC words are initialized with the numeral memory table initial value registered to the screen data memory when the main power supply is turned ON or reset.
  • Page 215 Memory Tables and Graphs Section Example: 12345678 Word 15 to12 11 to 8 7 to 4 3 to 0 Bit Start Start+ 1 S Displaying Numeral Memory Table Entry Numerals can be displayed in three different ways according to the contents of the numeral memory table entry, as mentioned below.
  • Page 216 To change the numerals or character strings displayed on the NT30/30C, make changes with the numeral or character string memory table entry. To make chan- ges with the numeral or character string memory table entry of the NT30/30C, change the contents of words by the PC.
  • Page 217 (20H). If unnecessary characters are left in the area, the character string will not be displayed correctly. If the character font for character strings displayed on the NT30/30C screen is set as half size and a normal-size character string is written after displaying a 2-byte code (mark), part of the mark will remain displayed, as shown below.

  • Page 218: Changing Displayed Numerals Or Character Strings, Direct Specification

    S Program Operation (1) The contents of word DM0000 are incremented by 1 each second. The val- ue displayed on the NT30/30C in numeral table entry No. 1 increases by 1 each second. (2) When the counter in (1) above causes an increase in the most significant digits, the contents of word DM0001 are incremented by 1 each second.
  • Page 219 Method (2) involves changing the contents of the allocated table entry. For de- tails, refer to the sections on memory table entry copy (page 212) and changing displayed numerals or character strings (direct specification) (page 207). NT30/30C Allocated word (numeral Indirect numeral table entry 41 table entry 41) 0 0 3 9 ²0039...
  • Page 220 DM0000 used for indirect specification S Program Operation (1) Each time IR/CIO 00100 comes ON, the display on the NT30/30C chan- ges to the next item in the following sequence. NT610G → NT610C → NT30 → NT30C (2) Each time IR/CIO 00101 comes ON, the display on the PT changes to the next item in the following sequence.

  • Page 221: Copying Memory Table Entries

    Write a memory table entry number etc. to the copy memory table entry setting area in the PT Status Control Area in the PC memory. Data will be copied be- tween the memory table entries in the NT30/30C and the displayed value will change accordingly.
  • Page 222 PT Status Control Area (PC to PT). The NT30/30C reads the area sometimes when the PC is writing the settings. If the copy source memory table entry number has been written first and is changed, unexpected memory table entry may possibly be changed.
  • Page 223 Memory Tables and Graphs Section To repeat copying of the same copy source and same copy destination, write a value other than 0 or 1 for the copy type, and then, write a correct value again. S Copying a Numeral Memory Table Entry If the display method or the number of registered words include discrepancies, a numeral memory table entry may not be copied and displayed correctly.
  • Page 224 The following describes the procedure to upgrade the graph display on the NT30/30C by changing the contents of the allocated words. To change the graph display on the NT30/30C, change the contents of the PC words to which the numeral memory table entries have been allocated.

  • Page 225: Lamps And Touch Switches

    The following describes the procedure to change the lamp display status on the NT30/30C by changing the contents of the allocated bits. To change the lamp display status on the NT30/30C, turn ON and OFF the lamp control bit allocated in the PC.
  • Page 226 ON. S Image/Library Lamp Data With the NT30/30C, it is possible to set lamps that display any required image or library data in their lit status and in their unlit status. For details, see Image Library Lamp Function (page 153).

  • Page 227: Allocated Bits, And Display, Of Touch Switches

    Section 5-3-3 Allocated Bits, and Display, of Touch Switches Method for PC Notification and NT30/30C Control Two types of bit can be allocated to touch switches: notify bits - which serve to notify statuses to the PC - and control bits (lamp bits), which control the lighting (flashing) of the touch switches.
  • Page 228 Lamps and Touch Switches Section S Important Points Relating to Notification Operations Details on touch switch notification operations are listed below. When using Host Link Type of notification When using NT link When using NT link (DM operation (other than DM area) area) (1) Notification in word units Momentary...

  • Page 229: Touch Switch Status

    This section describes how the status of a touch switch (whether it has been pressed or not) is accessed. With the NT30/30C, when a touch switch is pressed, the notify bit allocated to that touch switch in the PC memory is automatically notified.
  • Page 230 Lamps and Touch Switches Section In order to determine the status of a touch switch, the status of the touch switch notification bit allocated to it is determined. The touch switch notify bits can be allocated to the following areas of the PC memory.
  • Page 231 KEEP instruction will be turned OFF. In order to avoid this, allocate a bit from an area other than the DM Area, even when communicating via NT Link. Application Example This example uses the touch switches as normal switches (bits) in order to use the NT30/30C as an operating panel.
  • Page 232 Lamps and Touch Switches Section S NT-series Support Tool Settings Make the following settings using the NT-series Support Tool. Touch switch No. 10: Function: Notify Bit Shape: 3-D Lamp attributes: Light Control bit: IR/CIO 05000 (Run flag) ... Guide message: RUN Notify bit: IR/CIO 06000 Touch switch No.

  • Page 233: Numeral And Character String Setting

    PC using the numeral setting function (numeral input function). In order to determine when numerical data has been input at the NT30/30C, the numeral setting strobe flag in the PT Status Notify Area is used. In order to deter- mine the upgraded numeral memory table entry number, the content upgrade memory table entry in the PT Status Notify Area is used.
  • Page 234 Numeral and Character String Setting Section Content Upgrade Memory Table Entry Set in the PT Status Notify Area and PT Status 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0 Bit Word Content upgrade memory table entry Numeral memory table No.
  • Page 235 Application Example This example shows the reading of the numeral memory table entry number after a value has been changed by inputting numerical data at the NT30/30C. S NT-series Support Tool Settings Make the following settings using the NT-series Support Tool.

  • Page 236: Notification Of Character String To The Pc

    Section 5-4-2 Notification of Character String to the PC This section describes how the character string data input at an NT30/30C is ac- cessed by the PC. In order to determine when character string data has been input at the NT30/30C, the character string setting strobe flag in the PT Status Notify Area is used.
  • Page 237 S Disabling Character String Input Character string input can be disabled by a PT Status Control Area operation. For details, see 5-7 NT30/30C Status Control (page 239). Application Example This example shows the reading of the character string memory table entry num- ber after a value has been changed by inputting character string data at the NT30/30C.

  • Page 238: Alarm Lists

    Alarm Lists Section Exported From U. S. A. Character-string memory table #2 Exported To Australia Character-string memory table #3 U. S. A. Australia Japan Touch switches Taiwan New Zealand China S PC Program Include the following in the PC ladder program. 11210 @MOV(21) Notification word for content upgrade...

  • Page 239: Displaying Alarm Lists Using Bit Memory Table Entries

    5-5-2 Displaying Alarm Lists Using Bit Memory Table Entries This section explains the actual procedure used to display the alarm messages of the alarm list function on the screen of the NT30/30C. In order to display an alarm message, the allocated bit of the bit memory table entry allocated to the PC has to be switched ON.
  • Page 240 Bit memory table entry No. 24: LR 001004 Data registered for the screen: Alarm list Image/library data display area Alarm list Starting bit table entry number: 20 Number of accessed table entries: 5 S PC Program Ladder programming to control the NT30/30C is not required.
  • Page 241 Alarm Lists Section S NT30/30C Operation When the created alarm message screen is displayed, the following opera- tions will take place in accordance with the status of the allocated bits. - When all allocated bits are OFF ± - When AR0000 comes ON Contents of character string memory table entry corresponding to bit memory table entry No.
  • Page 242 Alarm Lists Section ± - When the second from top alarm message is pressed Image/library data corresponding to se- cond from top alarm message The alarm list is composed of touch switches. By of touch switches. By pressing the touch switch of PROCESS 3 STOPPED a displayed alarm message, corresponding im ge/libr ry...

  • Page 243: Clock Function

    As shown in the table below, numbers 247 through 253 are for display and read- ing only, and numbers 254 and 255 are for time setting. Numbers 247 through 253 store clock data that is updated by the internal clock of the NT30/30C. This data cannot be rewritten by the PC.

  • Page 244: Date And Time Setting

    254 and 255 and then copying it into table entries 254 and 255 by using the memory table entry copy function. NT30/30C 95 / 03 / 21 Date, hour,...
  • Page 245 Clock Function Section 2. Next, at the PC, specify the date and time that are to be set in numeral memory table entries 254 and 255 in these allocated words. 3. Copy the settings from the copy source numeral memory table entries to nu- meral memory table entries 254 and 255.
  • Page 246 (2) to be completed, copy the contents of numeral memory table entry 265 (day of the week, year, month) into numeral memory table entry 255, which used for setting the clock function. The date and time set at the PC will also be set at the NT30/30C and displayed.

  • Page 247: Notification Of The Date And Time To The Pc

    Section 5-6-4 Notification of the Date and Time to the PC The date and time set at the NT30/30C can be notified to the PC. The numeral memory table entries numbered 247 through 253 are used for display. They can- not be allocated to PC areas.

  • Page 248: Nt30/30C Status Control

    258 and 259. NT30/30C Status Control In order to control the status of the NT30/30C from the PC, the PT status control bits in the PT Status Control Area are used.

  • Page 249: Controllable Nt30/30C Functions

    PT status control bits do not match the actual status of the NT30/30C. For example, the buzzer may sound even though the setting for continuous buzzer bit 13 is OFF.
  • Page 250 After initialization, it returns to the 0 (OFF) status. S Backlight Color (Bit 10), Backlight Mode (Bit 8) In the case of the NT30, the backlight is controlled by the combination of bit 10 and bit 8 statuses, as shown below.

  • Page 251: How To Control Nt30/30C Functions

    Status Control Area. S Control Timing of PT Status Control Bits The PT status control bit is not read when the NT30/30C starts up. It is only read, and control is only executed, when the contents of the PT Status Control Area are changed after the NT30/30C has been started up.
  • Page 252 Screen display (bit 15) 1 (Performed) Short intermittent buzzer (bit 12) 1 (Sounded) The NT30/30C short intermittent buzzer sounds. (3) The PT status control bits are set as shown below when both IR/CIO 09002 and IR/CIO 09003 turn ON. Continuous buzzer (bit 13)

  • Page 253: Notifying The Pc Of Pt Operating Status

    S PT Operating Status (Bit 15) When the NT30/30C is in the RUN mode this bit is set to ON (1). In other modes and while the system menu is displayed it is OFF (0). When this bit is OFF allo- cated bits and words cannot be read or written to.

  • Page 254: Reading Nt30/30C Operating Status

    Section S Numeral Setting Strobe Flag (Bit 11) When numerical data is input to a numeral table entry using the NT30/30C nu- meral setting function, the numeral setting strobe flag comes ON (1). On notifi- cation to the PC, it returns to the OFF (0) status.
  • Page 255 NT30/30C status is changed during operation. Example of Using the PT Status Notify Bit An operation example in which the NT30/30C status is checked by operating the PT status notify bit is explained below. S NT-series Support Tool Settings Perform the following setting with the NT-series Support Tool.

  • Page 256: Troubleshooting And Maintenance

    SECTION 6 Troubleshooting and Maintenance This section describes the action to take when NT30/30C errors occur, and how to carry out maintenance and inspections to prevent the occurrence of errors. Hardware Faults ............

  • Page 257: Hardware Faults

    Hardware Faults Section Hardware Faults When a fault relating to the operation of the NT30/30C occurs, find the symptoms in the table below and respond by following the corresponding remedy indicated in the table. NT30/30C Symptoms Cause Remedy POWER indicator fails to Power is not being supplied.

  • Page 258: Responding To Displayed Error Messages

    1 word in the PC to the numeral memory table. Responding to Displayed Error Messages When the NT30/30C displays an error message, find the corresponding symp- toms in the appropriate table below and respond by following the remedy indi- cated in the table.

  • Page 259: Errors Occurring During Operation

    S Operation when a Communication Error Occurs When a communication error occurs, the error message is displayed at the NT30/30C, and the buzzer sounds. Error messages are displayed when the Automatic Reset memory switch is set (OFF). Some error messages are displayed even if the Automatic Reset memory switch is set (ON).
  • Page 260 If there is a possibility of noise, separate cables displayed) from the source of the noise, and insert noise filters in power lines. If the NT30/NT30C is used in an environment with high levels of noise, use a noise-resistant cable and make the cable length as short as possible.

  • Page 261: Maintenance Of The Nt30/30C

    Danger of electric shock. Switch OFF the NT30/30C power before changing the backlight. Procedure 1. Turn OFF the power to the NT30/30C, grasp the backlight unit by its grips (this will cause the catches at either side of the backlight unit to disengage from the NT30/30C body) and pull the backlight unit toward you to remove it.

  • Page 262: Replacing The Battery

    The NT30/30C uses a lithium battery to back up the memory contents. The battery life is 5 years if the NT30/30C is used in a location where the ambient temperature is 25_C. If the temperature at the location of use is higher than this, the battery life will be shorter.
  • Page 263 The connector of the new battery must be connected within 5 minutes after disconnecting the old battery’s connector. However, the battery can be re- placed while the NT30/30C power is ON, and in this case there is no time restriction.

  • Page 264: Inspection And Cleaning

    Inspection and Cleaning Section Inspection and Cleaning Clean and inspect the NT30/30C regularly to ensure that it is always used in its optimum condition. Cleaning Method If the display is dirty the screen is difficult to see. Clean the screen from time to time as follows.
  • Page 265 Cautions on replacing the NT30/30C When replacing the NT30/30C after discovering a fault during inspections, note the following points: S Be sure to switch the power OFF before replacement. S After replacement, check that the new NT30/30C is not subject to the same error.

  • Page 266: A Specifications

    Appendix A Specifications General Specifications Item Specification Power supply voltage 24 VDC Allowable power supply voltage range 20.4 VDC to 26.4 VDC (24 VDC –15% +10%) Power consumption 15 W max. Ambient operating temperature 0 to +50_C (with no freezing) Storage temperature –20 to +70_C (with no freezing) Ambient operating humidity...
  • Page 267 Indicators POWER (Green Lit while power is being supplied. indicator) Lit in green during operation. Lit in orange (during operation) or in red (when NT30/NT30C stopped) if battery voltage becomes low. Panel Specifications Item Specification Touch panel Number of switches: 192 (16 horizontally x 12 vertically)
  • Page 268 1999 screen is a host connecting screen, and 1999 screen is the screen displayed during connection to the host.) Screen registration method By transferring screen data created using the support tool to the NT30/30C. Screen saving method (screen data Flash memory (storing format unique to NT30/30C) memory) (*1) The total number of display elements for numeral display, graphs, and numeral settings must be 1024 or less.
  • Page 269 Appendix A Specifications Display Element Specifications Item Specifications Display characters Half-size characters (8 x 8 dots): Alphanumerics and symbols Normal-size characters (8 x 16 dots): Alphanumerics and symbols Mark (16 x 16 dots): User-defined pictographs (32 x 32 dots) (64 x 64 dots) Image data: 8 x 8 to 320 x 240 dots, User-defined image character size is set freely in the unit of 8 x 8 dots.
  • Page 270 Appendix A Specifications Special Features Item Specifications Buzzer Three kinds of sound (continuous sound, intermittent short-sound, intermittent long-sound) Reception of a command from the PC, buzzer setting screen display, error screen display such as abnormal reception OFF: Reception of a command from the PC, key input, screen display without buzzer setting Sound pressure: Min.
  • Page 271 Appendix A Specifications Communications Specifications For a Host Link via RS-232C Item Specification Communications standard EIA RS-232C Communications settings Start-stop synchronization Baud rate: 9600, 19,200 bps Data length: 7 bits Stop bits: 2 bits Parity: Even Connector 9-pin, D-sub connector (female) Number of Units connected 1 to 1 Transmission distance...

  • Page 272: B Dimensions

    Appendix B Dimensions Programming Terminals (NT30-ST131(B)-E, NT30C-ST141(B)-E) 183.5 (7.22) POWER 130.5 (5.59) (5.14) 5 (0.20) 55.6 (2.19) (7.68) Unit : mm (inch) Shown with B7A Interface Unit installed. (2.95)
  • Page 273 Appendix B Dimensions Mounting bracket dimensions (8.11) (2.36 (2.36 POWER (6.46 5(0.2) NT30 15.5 Mounting (0.61) Mounting 33(1.3) bracket plate (Min.) (1.97) Unit : mm (inch) 37(1.46) (Max.)

  • Page 274: C Using Rs-232C/Rs-422A Link Adapters

    Appendix C Using RS-232C/RS-422A Link Adapters This section outlines the external dimensions, procedure for mounting and removal, and specifications of an RS-232C/RS-422A Link Adapter (NT-AL001). Refer to this information when designing the control panel. Dimensions 53.5 om on NT–AL001 74.5 100.2 (30) 105 max.
  • Page 275 Appendix C Using RS-232C/RS-422A Link Adapters Removal from a DIN Track Remove the end plates at right and left of the Link Adapter and, as shown in the figure below, insert a flat blade screwdriver into the track stopper at the bottom face of the Link Adapter and prize it free. Mounting to an Operation Panel Drill two mounting screw holes in an operation panel with a thickness of at least 2 mm and secure the Link Adapter with screws.

  • Page 276: D Nt30/30C Internal Processing

    Appendix D NT30/30C Internal Processing The following processing is executed inside the NT30/30C. Processing is divided into two types: periodic proces- sing and event processing. Periodic Processing The following processing is executed inside the NT30/30C to enable high-speed control from the PC.
  • Page 277 Appendix D NT30/30C Internal Processing S Number of Words for Screen Element Registration The number of words used for screen element registration is as follows. Allocated words: Number of words Allocated bits: Number of words calculated by summing the number of bits in each area and taking 1 word to be 16 bits.
  • Page 278 NT30/30C Internal Processing Event Processing When the status of the NT30/30C changes during operation, the processing for writing the changed data to the relevant area of the PC memory is executed. This kind of processing is only executed when statuses change. When changes occur simultaneously, processing is executed in accordance with the order of priority.
  • Page 279 C120-LK201-V1 Note When connecting the NT30/30C to an OMRON PLC CjjH , the connector and the connector hood must be prepared separately since they are not supplied with the CjjH. The connector provided in the CPU Unit of the CjjH is a 9-pin connector. For the connection, the follow- ing connector and connector hood should be prepared.
  • Page 280 * Before using the +5V supply of pin No. 6, check that the current capacity of the equipment to be supplied is no greater than 150 mA. The +5V output of NT30/30C is +5V " 5% 150 mA max. Connecting an NT30/30C to a C-Series Host Link...
  • Page 281 S Wiring Connections The NT30/30C does not use pin 4 (RS) or pin 5 (CS). Either short the RS and CS pins of the PC connector togeth- er or set the CTS setting selector switch at the rear face of the Host Link Unit to “0V” (see < in the figure).
  • Page 282 CVM1/CV-series Host Link Units have two types of connector, which must be wired differently. The NT30/30C does not use pin 4 (RS) or pin 5 (CS). Either short the RS and CS pins of the PC connector togeth- er or set the CTS setting selector switch at the rear face of the Host Link Unit to “0V” (see < in the figure).
  • Page 283 Appendix E Making the Cable to Connect to the PC Communications Port 1 (25-pin Connector) NT30/30C PC (Host Link Unit) Abbrevi- Abbrevi- ation number number ation Connector Connector cover cover RS-232C RS-232C interface interface < – – – – Shield –...
  • Page 284 Appendix E Making the Cable to Connect to the PC Connecting an NT30/30C to an SRM1, a CS1-series Serial Communications Unit, or a CPU Unit Other Than a C-Series CjjH CPU Unit S CS1-series CS1G/H, C-series C200HS, C200HX/HG/HE(-Z), CPM1, CPM2A, CPM2C, CQM1, CQM1H,...
  • Page 285 S Wiring Connections The NT30/30C does not use pin 4 (RS) or pin 5 (CS). Either short the RS and CS pins of the PC connector togeth- er or set the CTS setting selector switch at the rear face of the Host Link Unit to “0V” (see < in the figure).
  • Page 286 Send data (–) Send data (+) Signal ground – – Function ground – – Note: Signals CSA and CSB are those for special applications. S Wiring Connections - RS-232C type NT30/30C NT30/30C NT-AL001 Host RS-232C RS-422A Terminal Signal Name Abbrev. Pin No.
  • Page 287 Appendix E Making the Cable to Connect to the PC - RS-422A type NT30/30C NT30/30C NT-AL001 Host RS-422A RS-232C Terminal Pin No. Abbrev. Abbrev. Abbrev. Abbrev. RS-422A Terminal block RS-232C RS-422A RS-232C interface interface interface Shield Terminal block Shield (9-pin) Making the Cable The procedure to make up the cable is described below.
  • Page 288 Appendix E Making the Cable to Connect to the PC (3) Cut back the shield with scissors. (4) Use wire strippers to strip the insulation from each wire. (5) Wrap vinyl tape over the cut off end of the shield. 40 (1.57) (RS-232C) 25 (1.00) (RS-422A) 5(0.19)

  • Page 289: F Connecting Cable Specifications

    Use the following recommended products when making the connecting cable. Name Model Remarks XM2A-2501 25-pin, Made by OMRON, for personal Connector computer XM2A-0901 9-pin, Made by OMRON, for NT30/30C body XM2S-2511 25-pin, Made by OMRON, for personal Connector cover computer XM2S-0911 9-pin, Made by OMRON, for NT30/30C...
  • Page 290 Use the following recommended products when making the connecting cable. Name Model Remarks Connector XM2D-0901 9-pin, Made by OMRON, for personal computer XM2A-0901 9-pin, Made by OMRON, for NT30/30C body Connector XM2S-0911 9-pin, Made by OMRON (Two) cover Multi-core shielded cable, Made by Cable AWG28 5P Fujikura, Ltd.

  • Page 291: G Connection Using Rs-232C/Rs-422A Link Adapters

    By using the RS-232C/RS422A Link Adapter (NT-AL001), RS-232C can be converted to RS-422A, and commu- nications over a distance of up to 500 m is possible. Connection is possible using the NT30/NT30C’s RS-232C connector or using the NT30/NT30’s RS-422A terminal block. The methods differ in the way shown below.
  • Page 292 Shield with NT30/NT30C. Switch Settings S DIP Switch Setting for the RS-232C/RS-422A Link Adapter S DIP Switch Setting for the NT30/NT30C (Settings for other DIP switch pins will depend on other factors.) Set the NT30/NT30C’s memory switches for RS-422A communications.

  • Page 293: H Standard Models

    Appendix H Standard Models Programmable Terminals (PTs) Model Specification NT30-ST131-E Monochrome display, ivory NT30-ST131B-E Monochrome display, black NT30C-ST141-E STN color display, ivory NT30C-ST141B-E STN color display, black Host Link Units Model Specification Applicable PC C120-LK201-V1 CPU-mounting Unit with RS-232C connector...
  • Page 294 Appendix H Standard Models Model Specification Applicable PC CPM1-10CDR-j RS-232C adapter RS-422A adapter connected to the C-series CPM1-20CDR-j peripheral port. CPM1 CPM1-30CDR-j CPM1-30CDR-j-V1 CPM1A-10CDj-j CPM1A-20CDj-j CPM1A-30CDj-j CPM1A-40CDj-j CPM2A-30CDj-j Features a 9-pin connector for RS-232C connections C-series CPM2A-40CDj-j CPM2A CPM2A-60CDj-j CPM2C-10jjjjjj-j The communications connector contains the functionality of C-series both a peripheral port and an RS-232C port.
  • Page 295 Appendix H Standard Models CPU Units for Connection via NT Link Name Model PC series RS-232C adapter RS-422A adapter connected to the C-series CPM1-10CDR-j peripheral port. CPM1-20CDR-j CPM1 CPM1-30CDR-j CPM1-30CDR-j-V1 CPM1A-10CDj-j CPM1A-20CDj-j CPM1A-30CDj-j CPM1A-40CDj-j CPM2A-30CDjj-j Features a 9-pin connector for RS-232C connections C-series CPM2A-40CDjj-j CPM2A...
  • Page 296 Options NT30-CFL01 Replaceable Backlight (NT30) NT30C-CFL01 Replaceable Backlight (NT30C) NT30-KBA01 Silicone rubber chemical-proof cover NT30-KBA04 Reflection-suppressing protective sheets C500-BAT08 Battery * The DOS versions of the NT Support Tool (NT-ZA3PC/ZA3DV-Vj) and the System Installer (NT30-ZS3PC/ ZS3DV-V1) can also be used.
  • Page 297 Printer cable for half pitch (1.5 m), manufactured by OMRON Connecting Cable for Peripheral Port of CS1-series PCs Model Specification Manufactured by OMRON. (CS1-series peripheral port ↔ D-SUB, 9-pin, female connector) CS1W-CN118 Connecting Cable for CPM2C Communications Port Model Specification Manufactured by OMRON.

  • Page 298: I Options

    Appendix I Options Replaceable Backlight ... NT30-CFL01 for NT30, NT30C-CFL01 for NT30C This is a backlight for replacement purposes. Note When disposing of a backlight that is no longer required, be sure to comply with any local restrictions that apply to its disposal.
  • Page 299 Request S Since the cover is milky white, it makes the display slightly less clear. S This cover does not protect the connector between the NT30/30C and panel. Battery ... C500-BAT08 This is a lithium battery used for memory backup.

  • Page 300: Pc Memory Maps

    (-Vj) (*1) Included in the CIO area in the case of CVM1/CV-series PCs. (*2) This is the area that can be used with an NT30/30C. The DM area itself occupies the range 00000 to 24575. OMRON CS1-Series CS1G/H Memory Map...

  • Page 301: K Special Characters

    Appendix K Special Characters English Character Codes When using the terminal for the first time, the system program must be installed with pin 6 of SW2 ON to en- able English language messages to use the following codes. Example: Hex code is represented by 30, decimal code by 48, and character by 0. Code 20 and 32 in the table represents a space, as indicated by “SP”.
  • Page 302 Appendix K Special Characters Hex Digits α ≡ á β " í Γ ≥ ó π ≤ ú Σ ⌠ ñ σ ⌡ Ñ ÷ τ ≈ Φ ¿ Θ Ω < δ < ∞ < < ¡ ø < ε...

  • Page 303: Index

    261 Communications Boards, connecting to, 47 bit memory table, 140 allocated bits for alarm list, 229 comparison between NT30 and NT30C, 4 used to display alarm list, 230 used to switch screen display, 197 compatibility, 4 buzzer, 93, 134...
  • Page 304 Index display history recording, 100 external output, 187 I/O check, 103 data, sent to the PC, 9 input key, 159 numeral setting, 161 dimensions, 263 overview, 4 DIP switch settings pop-up window, 173 at startup, 74 resume, 96 details, 18 SCREEN PRINT key, 160 initializing screen data, 80 screen printing, 98, 241...
  • Page 305 138, 161 errors, 250 menu tree, 76 of display history data memory, 82 of memory tables, 81 messages, 2 of NT30/30C memory, 78 models of screen data, 79 batteries, 253, 292 input key function, 159 cables, 289 chemical-proof cover, 292...
  • Page 306 B7A Interface Units, 65 reading, 245 backlight, 258 batteries, 261 PT Status Control Area, 12 cables, 281 used to control NT30/30C status, 239 communications, 262 used to switch screen display, 195 connectors, 271 PT Status Notify Area, 12, 198 display, 258, 260...
  • Page 307 74 weight, 257 operation details, 77 selecting menu items, 77 windows, opening and closing, 176, 241–242 system program errors, 250 installation, 22 wiring connector cables, 281 system settings for OMRON Units, 271 changing, 75 details, 92 Host Link connections, 43...

  • Page 308: Revision History

    Revision History A manual revision code appears as a suffix to the catalog number on the front cover of the manual. Cat. No. V034-E1-5 Revision code The following table outlines the changes made to the manual during each revision. Page numbers refer to the previous version.

This manual is also suitable for:

Nt30c

Table of Contents
