- Page 1 Small-scale automation solution NT3S HMI-SERIES p o w e r f u l a n d f l e x i b l e t o u c h t e c h n o l o g y Advanced Industrial Automation...
- Page 2 You can create your own “function keys” wherever you want them on your screen and at the same time make use of text in multiple languages. You can also use comprehensive graphics to monitor your application. This product is a step up from our NT2S/NT11S function key series and a step up to our more intelligent NS-series.
- Page 3 On the NT3S you can show different kind of bar graphs. Single Analogue meters can also monitor values of connected bar graphs can be filled in different directions and multiple bar devices. You can set the range, angle, and “colours”...
- Page 4 PLC and “copy” them to a drive, for instance to start/stop (historical alarms in RTC version only) the drive. Also you can start and stop a drive from the NT3S • Trend graph for defined tags (RTC models only) directly or write variables/parameters like speed, distance, voltage or torque.
- Page 5 You can also use the NT3S to connect Omron Inverters to another PLC brand. In this solution the NT3S can communicate with the third party PLC* and at the same time the NT3S can change data in the Omron Inverters. Inverter settings can be changed directly from the screen but also from the PLC program.
- Page 6 NT3S to mini-peripheral port CJ1/CS1-series and CPM2C-series; 2 metre NT2S-CN002 NT2S and NT3S programming cable; 2 metre OMRON EUROPE B.V. Wegalaan 67-69, NL-2132 JD, Hoofddorp, The Netherlands. Tel: +31 (0) 23 568 13 00 Fax: +31 (0) 23 568 13 88 www.europe.omron.com Austria France...
