Each entry provides the following information:
Item
Entry Type
Entry Number
Date
Time
Description of the
fault/information
10.3.3.3.3.4.3.1.4 ODU: FSK-control  BUC  Advanced-FSK  LPOD (2LPODs Online/Offline LPOD)
Statistics
Statistics:
Config
Use the ▲▼ arrow keys to select Config or Stored-Statistics, and then press ENTER.
ODU: FSK-control  BUC  Advanced-FSK  LPOD (2LPODs
Online/Offline LPOD) Statistics Config
Stats: Logging=Enabled
Averaging=Disabled
Use the ▲▼ arrow keys to select Logging, Interval, Averaging, or Clear-All, and then use the
▲▼ arrow keys to set that setting:
Selection
Logging
Interval
Averaging
Clear-All
Press ENTER when done.
ODU (Transceiver, BUC, LNB) Operation
Info (Information)
•
Fault
•
Clear (fault cleared)
•
001 through 511
European Day-Month-Year (DD-MM-YY) format
Hour:Minute:Second (HH:MM:SS) format
Example: Info – PWR ON
Stored-Statistics
Interval=10 min
Clear-All=No (◄ ►)
Enabled or Disabled.
The Logging Interval is the period of time over which performance statistics are
measured. Set this interval as 00 to disable the feature (i.e., no logging) or,
otherwise, define the logging interval from 10 through 90 minutes in 10-minute
increments.
Enabled or Disabled.
When prompted, select YES.
