Admin | Firmware | Packet Processor
This nested page is accessible only to Admin users and when you install and
enable the optional IP Packet Processor card. See Sect. 7.5.3.1 for complete
details about using conditional access pages.
Use this page to view the status window for the optional IP Packet Processor's currently loaded
firmware, and to set the firmware load preference for the IP Packet Processor upon power-
up/reboot of the unit.
Firmware
•
(Read-only) The IP Packet Processor's Bootrom, Image 1, Image 2, and current Running
image are identified here.
•
Boot From – Use the drop-down list to boot the IP Packet Processor from Latest, Image
1, or Image 2, and then click [Submit] to save this selection.
Ethernet-based Remote Product Management
Figure 7-9. Admin | Firmware | Packet Processor Page
CDM-425 Advanced Satellite Modem
7–24
Revision 0
MN-CDM-425
