 Soft-Off by PWR-BTTN
This option only works with systems using an ATX power supply. It also allows users to define
which type of soft power OFF sequence the system will follow. The default value is
"Instant-Off".
Instant-Off This option follows the conventional manner of system performance when turning the
power to OFF. Instant-Off is a software power OFF sequence requiring the power
supply button is switched to OFF.
Delay 4 Sec. Upon the system's turning OFF through the power switch, this option will delay the
complete system power OFF sequence approximately 4 seconds. Within this delay
period, the system will temporarily enter into the Suspend Mode enabling you to
restart the system at once.
 Power On by Ring
This option allows the system to resume or wake up upon detecting any ring signals coming
from an installed modem. The default value is "Enabled".
Reload Global Timer Events
Global Timer (power management) events can prevent the system from entering a power
saving mode or can awaken the system from such a mode.
 HPET Support
Use this item to enable or disable HPET (High Precision Event Timer), which is designed to
have very fine-grained resolution, fast access times, and support for aperiodic behavior.
 HPET Mode
Use this item to configure the HPET (High Precision Event Timer) mode.
Press <Esc> to return to the Main Menu page.
PHOENIX-AWARD BIOS Utility
SHB101 LGA775 SBC User's Manual
45
