SHB101 LGA775 SBC User's Manual
4.4

I/O Port Address Map

®
™
The Intel Core 2 Quad / Core
There are total 1KB port addresses available for assignment to other devices via I/O expansion
cards.
24
™
2 Duo/Celeron
Address Devices
000-01F DMA controller #1
020-02D
024-025
Interrupt controller #1
028-029
02C-02D
02E-02F Forwarded to LPC(LPC Super I/O )
030-031
034-035
Interrupt controller #2
038-039
03C-03D
040-043
Timer/Counter (8254)
050-053
060 Forwarded to LPC (Microcontroller)
061 NMI
062-066 Forwarded to LPC (Microcontroller)
070-077 Real time clock, NMI
080-091 DMA page register
092 Processor I/F(Reset Generator)
093-09F DMA page register
0A0-0BF Interrupt controller #2
0C0-0DF DMA controller #2
0F0 Processor I/F
0F8-0FF Math processor
170-177 Forward to SATA (SATA Controller)
1F0-1F7 Forward to SATA (SATA Controller)
376 Forward to SATA(SATA Controller)
378-37F Parallel Port (LPT)
380-38F SDLC #2
3A0-3AF SDLC #1
3B0-3BF MDA video card
3C0-3CF EGA card
3D0-3DF CGA card
3F6 Forward to SATA(SATA Controller)
3F8-3FF Serial port #1 (COM1)
2F8-2FF Serial port #2 (COM2)
®
CPUs can communicate via I/O ports.
