Connectors

Connectors connect this board with other parts of the system. Loose or improper connection
might cause problems. Make sure all connectors are properly and firmly connected.
Here is a summary table shows you all connectors on the board.
Connectors
ATX 4 Pin 12V In
Front Panel Connector
LAN2 Link / Active LED
LAN2 Speed LED
LAN1 Speed LED
LAN1 Link / Active LED
Serial Port1 Connector
Serial Port2 Connector
CPU FAN Connector
System FAN Connector
System FAN Connector
Board and Pin Assignments
SHB101 LGA775 SBC User's Manual
Label Connectors
CN2 Floppy Connector
CN3 Parallel Port
CN4 Serial ATA Connectors
CN5 USB Connector
CN6 DB15 CRT Connector
CN7 DDRII DIMM Sockets
COM1 PS/2 Mouse Connector
COM2 PS/2 Keyboard Connector
FAN1 Intel HD Audio Digital Header
FAN2 LAN1 Connector
FAN3 LAN2 Connector
Label
FDD1
PRN1
SATA1~6
USB1~4
VGA1
DDR1~4
MS1
KB1
HDA1
LAN1
LAN2
9
