2.4.15

USB Connectors (USB1, USB2)

The 10-pin standard Universal Serial Bus (USB) connectors, USB1, USB2, on this board
are for installing versatile USB interface peripherals.
Pin Signal
1 USB
3 USB2-
5 USB2+
7 GND
9 GND
Pin Signal
1 USB
3 USB4-
5 USB4+
7 GND
2.4.16

USB Port Connector (USB3, USB4)

The 4-pin standard Universal Serial Bus (USB) port connector on the board is for the
installation of peripherals supporting the USB interface.
Pin Signal
1 USB POWER
2 USB -
3 USB +
4 GND
2.4.17

DB15 CRT Connector (VGA1)

VGA1 is a DB15 connector commonly used for the CRT Monitor.
Pin Signal
1 Red
4 NC
7 GND
10 GND
Horizontal Sync
13
Board and Pin Assignments
Pin Signal
2 USB
4 USB3-
6 USB3+
8 GND
10 GND
Pin Signal
2 USB
4 USB5-
6 USB5+
8 GND
10 GND
Pin Signal
2 Green
5 GND
8 GND
11 NC
14 Vertical Sync
SHB101 LGA775 SBC User's Manual
USB1
USB2
1 2 3 4
Pin Signal
3 Blue
6 DETECT
9 VCC
12 DDC DATA
15 DDC CLK
5 1
10 6
15
11
15
