Installation
May 2013
For general mounting guidelines, refer to the DVC6200 Series quick start guide (D103556X012), available at
www.fisher.com or your Emerson Process Management sales office.
Table 2‐1. DVC6200 Mounting Instructions
Instructions for Mounting:
585C/585CR Size 25 Actuator with or without Handjack
585C/585CR Size 50 Actuator with or without Handjack
657 and 667 Size 30-60 Actuators
657 and 667 Size 34-60 Actuators with Handwheel
657 and 667 Size 70, 76, and 87 Actuators (up to 2 inch travel)
657 and 667 Size 70, 76, and 87 Actuators (4 inch travel)
657 and 667 Size 80 Actuators (up to 2 inch travel)
657 and 667 Size 80 Actuators (4 inch travel)
1051 Size 33 and 1052 Size 20 and 33 Actuators (Window Mount)
1051 and 1052 Size 33 Actuators (End Mount)
1051 and 1052 Size 40-70 Actuators (Window Mount)
1051 and 1052 Size 40-70 Actuators (End Mount)
1052 Size 20 Actuator (End Mount)
1061 Size 30-68 Actuator (Window Mount)
1061 Size 80-100 Actuator (Window Mount)
2052 Size 1, 2, 3 Actuator (End Mount)
2052 Size 1, 2, 3 Actuator with Spacer (Window Mount)
Baumann Sliding‐Stem Actuators
GX Control Valve and Actuator System
IEC60534‐6‐1 (NAMUR) Sliding Stem Actuators
IEC60534‐6‐2 (NAMUR) Rotary Actuators

Mounting the DVC6205 Base Unit

For remote‐mounted digital valve controllers, the DVC6205 base unit ships separately from the control valve and does
not include tubing, fittings or wiring. See the instructions that come with the mounting kit for detailed information on
mounting the feedback unit to a specific actuator model.
Mount the DVC6205 base unit on a 50.8 mm (2 inch) pipestand or wall. The included bracket is used for either
mounting method.
Wall Mounting
Refer to figures 2‐4 and 2‐5. Drill two holes in the wall using the dimensions shown in figure 2‐4. Attach the mounting
bracket to the base unit using four spacers and 25.4 mm (1‐inch) 1/4‐20 hex head screws. Attach the base unit to the
wall using suitable screws or bolts.
Pipestand Mounting
Refer to figure 2‐6. Position a standoff on the back of the base unit. Using two 101.6 mm (4‐inch) 1/4‐20 hex head
screws loosely attach the base unit to the pipestand with the mounting bracket. Position the second standoff, then
using the remaining 101.6 mm (4‐inch) hex head screws, securely fasten the base unit to the pipe stand.
14
Instruction Manual
D103409X012
Part Number
D103439X012
D103440X012
D103441X012
D103442X012
D103443X012
D103444X012
D103445X012
D103446X012
D103447X012
D103448X012
D103449X012
D103450X012
D103451X012
D103453X012
D103452X012
D103454X012
D103455X012
D103456X012
D103457X012
D103458X012
D103459X012
