Parts
May 2013
Key Description

PWB Assembly

(see figure 8‐2 and 8‐4)
DVC6200 and DVC6205
Note
Contact your Emerson Process Management sales office for PWB
Assembly FS numbers.
50* PWB Assembly
Standard
For instrument level AC
For instrument level HC
For instrument level AD
For instrument level PD
For instrument level ODV
Extreme Temperature option (fluorosilicone elastomers)
For instrument level AC
For instrument level HC
For instrument level AD
For instrument level PD
For instrument level ODV
116
Key Description
Pressure Gauges, Pipe Plugs, or
Tire Valve Assemblies
(see figure 8‐3)
DVC6200 and DVC6205
47* Pressure Gauge, nickel‐plated brass case, brass connection
Double‐acting (3 req'd); Single‐acting (2 req'd)
PSI/MPA Gauge Scale
To 60 PSI, 0.4 MPa
To 160 PSI, 1.1 MPa
PSI/bar Gauge Scale
To 60 PSI, 4 bar
To 160 PSI, 11 bar
2
PSI/KG/CM Gauge Scale
2
To 60 PSI, 4 KG/CM
To 160 PSI, 11 KG/CM
66 Pipe Plug, hex head
For double‐acting and single‐acting direct w/gauges
(none req'd)
For single‐acting reverse w/gauges (1 req'd)
For all units w/o gauges (3 req'd)
67 Tire Valve, used with Tire Valve Option only
Double‐acting (3 req'd); Single‐acting (2 req'd)

HART Filters

HF340, DIN rail mount
HF341, DIN rail Mount, pass through (no filter)
*Recommended spare parts
Instruction Manual
D103409X012
Part Number
18B7713X042
18B7713X022
18B7713X032
18B7713X012
18B7713X072
2
18B7713X082
39B5411X022
39B5412X012
