Canon imagePROGRAF iPF5000 Series Service Manual page 79

Chapter 2
The detected head temperature is used to control the head operation and to detect abnormal head temperatures.
Printhead contact detection
The printhead contact status is detected by testing the electrical conductivity.
It is detected according to the voltage changes at the two terminals of the contact faces, power supply terminals, and GND terminal.
2-39
