Canon imagePROGRAF iPF5000 Series Service Manual page 186

Chapter 7
Display Description
C Number of days passed since the C ink tank was installed
M Number of days passed since the M ink tank was installed
Y Number of days passed since the Y ink tank was installed
PC Number of days passed since the PC ink tank was installed
PM Number of days passed since the PM ink tank was installed
GY Number of days passed since the GY ink tank was installed
PGY Number of days passed since the PGY ink tank was installed
R Number of days passed since the R ink tank was installed
G Number of days passed since the G ink tank was installed
B Number of days passed since the B ink tank was installed
5) WARNING
Displays the warning history (up to 20 events). The newest event has the smallest history number.
6) ERROR
Displays the error history (up to 20 events). The newest event has the smallest history number.
7) INK CHECK
Displays the history of execution of "Ink Check Off" in the Main menu in the order of Y, PC, C, PGY, GY, MBK, PM, M, BK, R, G, and B from in this order.
0: No execution
1: Executed at least once
b) I/O DISPLAY (* To be supported by the next version)
Shows the statuses and sensors and switches on the display.
ON = 1
OFF = 0
Screen 1
I
0
1
Screen 2
I
0
17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 (Display position)
To switch between screens 1 and 2, use the
The relationship between display positions and sensor statuses is summarized in the following table.
Display
position
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
7-6
/ O D I S P L
0 0 0 0 0 0 0 0
2 3 4 5 6 7 8 9
/ O D I S P L
0 0 0 0 0 0 0 0
and buttons.
Sensor name LCD display contents
Pump Cam Sensor 0: Sensor ON , 1: Sensor OFF
Valve Open/Closed Detection 0: Sensor ON , 1: Sensor OFF
Sensor
(Not Used) -
(Not Used) -
Spur Cam Sensor 0: Sensor ON , 1: Sensor OFF
Lift Cam Sensor 0: Sensor ON , 1: Sensor OFF
Feed Roller Hp Sensor 0: Sensor ON , 1: Sensor OFF
Top Cover Sensor 0: Cover open , 1: Cover close
(Not Used) -
Ink Tank Cover Switch 0: Cover open , 1: Cover close
(Not Used) -
Paper Detection Sensor 0: Sensor ON , 1: Sensor OFF
Cassette Paper Detection Sensor 0: Sensor ON , 1: Sensor OFF
Cassette Detection Sensor 0: Sensor ON , 1: Sensor OFF
Cassette Pick-Up Sensor 0: Sensor ON , 1: Sensor OFF
Cassette Cam Sensor 0: Sensor ON , 1: Sensor OFF
Roll Media Sensor 0: Sensor ON , 1: Sensor OFF
Roll Cam Sensor 0: Sensor ON , 1: Sensor OFF
Cutter Lift Sensor 0: Sensor ON , 1: Sensor OFF
Cutter Right Position Sensor 0: Sensor ON , 1: Sensor OFF
T-7-4
A Y 1 Upper row
0 0 0 0 0 0 0 Lower row
10 11 12 13 14 15 16 (Display position)
T-7-5
A Y 2 Upper row
0 0 0 0 0 0 0 Lower row
T-7-6
Unit
Day(s)
Day(s)
Day(s)
Day(s)
Day(s)
Day(s)
Day(s)
Day(s)
Day(s)
Day(s)
