- This operation is performed only when "ON" is selected for "Detect Remaining Roll Media".
- If the roll media does not have a bar code pattern on it, enter the length of the roll media using the menu on the operation panel.
*2
- The purpose of the first leading edge detection is to detect presence of media.
- The purpose of the second leading edge detection is to detect the printing start position.
2.3.3.2.5 Structure of the Manual Feed Unit
a) Manual feed (from front)
The cut sheet fed from the front (ejection unit) of the printer is fed to the rear of the printer [1], and then fed onto to platen [2] for printing.
This method of feeding paper can be used only when an accept media type is selected from the Manual Feed menu in the use mode. If you select the Manual Feed
