Canon imagePROGRAF iPF5000 Series Service Manual page 189

Display Description
CLR-UNIT A EXC. Cumulative count of unit A(waste ink system) replacement count clearing
CLR-UNIT B EXC. Cumulative count of unit B(platen duct) replacement count clearing
CLR-UNIT D EXC. Cumulative count of unit D(carriage unit) replacement count clearing
CLR-UNIT F EXC. Cumulative count of unit F(ink supply system) replacement count clearing
CLR-UNIT H EXC. Cumulative count of unit H(purge) replacement count clearing
CLR-UNIT L EXC. Cumulative count of unit L(head management sensor) replacement count clearing
CLR-UNIT P EXC. Cumulative count of unit P(feed motor) replacement count clearing
CLR-UNIT Q EXC. Cumulative count of unit Q(feed roller) replacement count clearing
CLR-UNIT R EXC. Cumulative count of unit R(spur cam) replacement count clearing
CLR-UNIT V EXC. Cumulative count of unit V(mist fan unit) replacement count clearing
CLR-FACTORY For factory
CNT.
- EXCHANGE: Counters related to parts replacement
Display
CUTTER EXC.
MTC EXC.
HEAD R EXC.
HEAD L EXC.
BOARD EXC.(M/B)
UNIT A EXC.
UNIT B EXC.
UNIT D EXC.
UNIT F EXC.
UNIT H EXC.
UNIT L EXC.
UNIT P EXC.
UNIT Q EXC.
UNIT R EXC.
UNIT V EXC.
- DETAIL-CNT: Counters related to ink
Display
MOVE PRINTER
N-INKCHECK(XX)
MEDIACONFIG-
CNT
- INK-USE1: Counters related to ink
Display
INK USE1(XX)
INK USE1(TTL)
N-INK USE1(XX)
N-INK USE1(TTL)
- INK-USE2: Counters related to ink
Display
INK USE2(XX)
INK USE2(TTL)
N-INK USE2(XX)
N-INK USE2(TTL)
- INK-EXC: Counters related to ink
Display
INK USE EXC(XX)
Description
Cutter replacement count
Maintenance cartridge replacement count
Head R replacement count
Head L replacement count
Main controller PCB replacement count
Unit A(waste ink system) replacement count
Unit B(platen duct) replacement count
Unit D(carriage unit) replacement count
Unit F(ink supply system) replacement count
Unit H(purge) replacement count
Unit L(head management sensor) replacement count
Unit P(feed motor) replacement count
Unit Q(feed roller) replacement count
Unit R(spur cam) replacement count
Unit V(mist fan unit) replacement count
Description
Number of "Move Printer" operations
XX: Ink color
Number of "Stop Ink Check" operations
Number of times media was registered by media editor
Description
XX: Ink color
Cumulative consumption amount of each color of generic ink
Total consumption amount of generic ink
XX: Ink color
Cumulative consumption amount of each color of refill ink
Total consumption amount of each color of refill ink
Description
XX: Ink color
Cumulative consumption amount of each color of generic ink
Total consumption amount of generic ink
XX: Ink color
Cumulative consumption amount of each color of refill ink
Total consumption amount of each color of refill ink
Description
XX: Ink color
Cumulative count of generic ink replacement
T-7-13
T-7-14
T-7-15
T-7-16
T-7-17
Chapter 7
Unit
Times
Times
Times
Times
Times
Times
Times
Times
Times
Times
Times
Unit
Times
Times
Times
Times
Times
Times
Times
Times
Times
Times
Times
Times
Times
Times
Times
Unit
Times
Times
Times
Unit
ml
ml
ml
ml
Unit
ml
ml
ml
ml
Unit
ml
7-9
