Canon imagePROGRAF iPF5000 Series Service Manual page 170

Chapter 6
J12 (Main controller PCB J3501)
Pin Number Signal name
23 GND
24 H0-E-DATA-9-EV
25 GND
26 H0-E-HE-9
27 GND
28 H0-F-DATA-10-EV
29 GND
30 H0-F-DATA-11-EV
31 GND
32 H0-F-HE-11
33 GND
34 H0-F-DATA-11-OD
35 GND
36 H0-F-HE-10
37 GND
38 H0-E-DATA-9-OD
39 GND
40 H0-F-DATA-10-OD
41 GND
42 H0-E-DATA-8-OD
43 GND
44 H0-E-HE-8
45 GND
46 H0-D-DATA-7-OD
47 GND
48 H-DASH LICC2 B
49 GND
50 GND
J13 (Main controller PCB J3601)
Pin Number Signal name
1 GND
2 H0-A-HE-0
3 GND
4 H0-A-DATA-0-EV
5 GND
6 H0-A-HE-1
7 GND
8 H0-A-DATA-1-EV
9 GND
10 H0-B-DATA-2-EV
11 GND
12 H0-B-DATA-3-EV
13 GND
14 H0-C-DATA-4-EV
15 GND
16 H0-B-HE-3
17 GND
18 H0-C-DATA-5-EV
19 GND
20 HEAD_3V
21 GND
22 H0-LT
23 GND
24 H0_CLK
25 GND
26 GND
27 LICSEL2
28 LICSEL1
29 LICSEL0
30 GND
31 GND
6-18
IN/OUT Function
- GND
IN Even head R data signal 9(E)
- GND
IN Head R heat enable signal 9(E)
- GND
IN Even head R data signal 10(F)
- GND
IN Even head R data signal 11(F)
- GND
IN Head R heat enable signal 11(F)
- GND
IN Odd head R data signal 11(F)
- GND
IN Head R heat enable signal 10(F)
- GND
IN Odd head R data signal 9(E)
- GND
IN Odd head R data signal 10(F)
- GND
IN Odd head R data signal 8(E)
- GND
IN Head R heat enable signal 8(E)
- GND
IN Odd head R data signal 7(D)
- GND
IN Analogue switch A/D trigger signal
- GND
- GND
T-6-37
IN/OUT Function
- GND
IN Head R heat enable signal 8(E)
- GND
IN Even head R data signal 0(A)
- GND
IN Head R heat enable signal 8(E)
- GND
IN Even head R data signal 1(A)
- GND
IN Even head R data signal 2(B)
- GND
IN Even head R data signal 3(B)
- GND
IN Even head R data signal 4(C)
- GND
IN Head R heat enable signal 8(E)
- GND
IN Even head R data signal 5(C)
- GND
IN Power supply (+3V)
- GND
IN Head R data latch signal
- GND
IN Head R data clock signal
- GND
- GND
IN Head R analogue switch latch signal
IN Head R analogue switch data signal
IN Head R analogue switch clock signal
- GND
- GND
