b) Eject roller unit
4) Eject roller bearing
5) Eject roller center bearing
c) Spur unit
6) Spur cam
PG 641
Approx.20mg
F-4-99
PG 641
Approx.12mg
PG 641
Approx.12mg
iPF500/5000
and two locations on iPF600
PG 641
Approx.12mg
F-4-100
