Canon imagePROGRAF iPF5000 Series Service Manual page 155

J1001 (1394 board)
Pin Number Signal name
20 AD31
21 AD30
22 AD29
23 AD28
24 GND
25 AD27
26 AD26
27 AD25
28 AD24
29 CBE3#
30 IDSEL
31 GND
32 GND
33 AD23
34 AD22
35 AD21
36 AD20
37 GND
38 AD19
39 AD18
40 AD17
41 AD16
42 CBE2#
43 GND
44 FRAME#
45 IRDY#
46 TRDY#
47 DEVSEL#
48 GND
49 STOP#
50 LOCK#
51 PERP#
52 SERR#
53 PAR
54 CBE1#
55 GND
56 GND
57 AD15
58 AD14
59 AD13
60 AD12
61 GND
62 AD11
63 AD10
64 AD9
65 AD8
66 CBE0#
67 GND
68 AD7
69 AD6
70 AD5
71 AD4
72 GND
73 AD3
74 AD2
75 AD1
76 AD0
77 GND
78 HDD_LED
79 +5V
80 +5V
81 +5V
IN/OUT Function
IN/OUT Address and data signal 31
IN/OUT Address and data signal 30
IN/OUT Address and data signal 29
IN/OUT Address and data signal 28
- GND
IN/OUT Address and data signal 27
IN/OUT Address and data signal 26
IN/OUT Address and data signal 25
IN/OUT Address and data signal 24
IN/OUT Bus command and byte enable signal 3
OUT Initialization device select signal
- GND
- GND
IN/OUT Address and data signal 23
IN/OUT Address and data signal 22
IN/OUT Address and data signal 21
IN/OUT Address and data signal 20
- GND
IN/OUT Address and data signal 19
IN/OUT Address and data signal 18
IN/OUT Address and data signal 17
IN/OUT Address and data signal 16
OUT Bus command and byte enable signal 2
- GND
IN/OUT Cycle frame signal
IN/OUT Initiator redy signal
IN/OUT Target redy signal
IN/OUT Device select signal
- GND
IN/OUT Stop signal
IN/OUT Lock signal
IN/OUT Parity error signal
IN/OUT System error signal
IN/OUT Parity signal
IN/OUT Bus command and byte enable signal 1
- GND
- GND
IN/OUT Address and data signal 15
IN/OUT Address and data signal 14
IN/OUT Address and data signal 13
IN/OUT Address and data signal 12
- GND
IN/OUT Address and data signal 11
IN/OUT Address and data signal 10
IN/OUT Address and data signal 09
IN/OUT Address and data signal 08
IN/OUT Bus command and byte enable signal 0
- GND
IN/OUT Address and data signal 07
IN/OUT Address and data signal 06
IN/OUT Address and data signal 05
IN/OUT Address and data signal 04
- GND
IN/OUT Address and data signal 03
IN/OUT Address and data signal 02
IN/OUT Address and data signal 01
IN/OUT Address and data signal 00
- GND
- N.C.
OUT Power supply (+5V)
OUT Power supply (+5V)
OUT Power supply (+5V)
Chapter 6
6-3
