Canon imagePROGRAF iPF5000 Series Service Manual page 156

Chapter 6
J1001 (1394 board)
Pin Number Signal name
82 +3.3V
83 +3.3V
84 +3.3V
85 GND
86 GND
87 GND
88 GND
J1201 (Network)
Pin Number Signal name
1 TX+
2 TX-
3 RX+
4 -
5 -
6 RX-
7 -
8 -
9 GREEN_LED_C
10 GREEN_LED_A
11 YELLOW_LED_C
12 YELLOW_LED_A
J1401
Unused
J1402
Unused
J1801 (Connect to power supply)
Pin Number Signal name
1 HD1_VHFBH
2 HD1_VHFBG
3 VH
4 GND
5 VH
6 GND
7 RGV20(VCC)
8 GND
9 VM
10 GND
11 VM2
12 GND
13 VH_ENB
14 PW_CONT
J2101
Unused
J2501 (Connect to Spur motor/spur cam sensor/Lift cam sensor/mist fan)
Pin Number Signal name
1 HAKUSHA_MOTOR_AM
2 HAKUSHA_MOTOR_AP
3 SNS_3V_1
4 GND
5 HAKUSHA_CAM_SNS
6 FAN_VM
7 MIST_FAN_LOCK
8 MIST_FAN_PWM
9 GND
6-4
IN/OUT Function
OUT Power supply (+3.3V)
OUT Power supply (+3.3V)
OUT Power supply (+3.3V)
- GND
- GND
- GND
- GND
T-6-4
IN/OUT Function
OUT Ethernet data TX line (+)
OUT Ethernet data TX line (-)
IN Ethernet data RX line (+)
- Not used
- Not used
IN Ethernet data RX line (-)
- Not used
- Not used
OUT Link LED (green:100Mb/s) cathode terminal
OUT Link LED (green:100Mb/s) anode terminal
OUT Link LED (yellow:10Mb/s) cathode terminal
OUT Link LED (yellow:10Mb/s) anode terminal
T-6-5
T-6-6
T-6-7
IN/OUT Function
OUT VH feedback voltage +
OUT VH feedback voltage -
IN Power supply (+21.5V)
- GND
IN Power supply (+21.5V)
- GND
IN Power supply (+21.5V)
- GND
IN Power supply (+26V)
- GND
IN Power supply (+26V)
- GND
OUT VH power supply ON/OFF signal
OUT Normal/power saving switch signal
T-6-8
T-6-9
IN/OUT Function
OUT Spur motor drive signal AM
OUT Spur motor drive signal AP
OUT Power supply (+3.3V)
- GND
IN Spur cam sensor output signal
OUT Power supply (+26V)
IN Mist fan lock signal
OUT Mist fan duty control signal
- GND
