Product Specifications - Canon imagePROGRAF iPF5000 Series Service Manual

Chapter 1

1.3 Product Specifications

1.3.1 Product Specifications

Type
Feeding system
Feeding capacity
Delivery method
Sheet delivery capability
Cutter
Type of media
Supported thickness
Media size (Roll media)
Media size (Cut sheet)
Printable area (Roll media)
Printable area (Cut sheet)
Printing assurance area (Roll
media)
Printing assurance area (Cut
sheet)
Interface
Printhead/Ink Tank type
Printhead
Ink tank
Detection functions (Cover
system)
Detection functions (Ink passage
system)
Detection functions (Carriage
system)
1-4
Bubble jet large-sized paper printer
Automatic feeding of one roll media (option)/Cassette paper feeding/
One cut sheet (manual feed from front)/One cut sheet (manual feed from
top)
- Roll media (option)
One roll at the back/Outer diameter of roll: 150 mm or less/Inner
diameter of paper tube: 2 or 3 inches
-Cut sheet
Cassette:250 sheets(A4), 100 sheets(A3), 50 sheets(A2)
Delivers the media with its printed side up in the forward direction.
- Roll media (option)
1 sheet
- Cut sheet
50 sheets (plain paper of A3 or smaller) or 20 sheets (plain paper of larger
than A3)
Automatically cuts paper laterally. Cartridge-type (with round blade)
Plain paper, plain paper (high quality), plain paper (vivid color), coated
paper, extra heavy coated paper, premium matte paper, high-quality
dedicated paper, matte photo paper, photo glossy paper, photo semi-
glossy paper, photo glossy paper (heavy), photo semi-glossy paper
(heavy), professional photo paper, super photo paper, super photo paper
(silky), glossy paper, synthetic paper, adhesive synthetic paper, proofing
paper, newspaper proofing paper, tracing paper (CAD), semi-translucent
matte film (CAD), POP board
Roll media: 0.07 to 0.8 mm
Cassette: 0.08 to 0.3 mm
Manual feed from top: 0.08 to 0.5 mm
Manual feed from front: 0.5 to 1.5 mm
Maximum size: 432 mm x 18 m
Minimum size: 203.2 mm x 203.2 mm
Maximum outside diameter: 150 mm
- Manual feed from top
Maximum size: 432 mm x 609.6 mm (W x L)
Minimum size: 203.2 mm x 279 mm (W x L)
- Manual feed from front
Maximum size: 432 mm x 609.6 mm (W x L)
Minimum size: 203.2 mm x 520 mm (W x L)
Area excluding 3mm from the top, 3 mm from the bottom, and 3 mm
from the left and right edges.
Borderless printing: 0 mm from the top, bottom, and left and right edges.
Width of media allowing borderless printing:10inches, JIS B4, A3+,
14inches, 16inches, 17inches, ISO A2/A3
Media type allowing borderless printing:Coated paper (heavy), photo
glossy paper, photo semi-glossy paper, photo glossy paper (heavy),
photo semi-glossy paper (heavy), photo glossy paper, photo semi-glossy
paper, fine art (photo), fine art (photo heavy), fine art (painting),
premium matte, fine art (watercolor), fine art (block print)
Area excluding 3 mm from the top, 23 mm from the bottom (3 mm when
supplied from the cassette), and 3 mm from the left and right edges.
Printing assurance area (Roll sheet)
Area excluding 20 mm from top, 20 mm from the bottom and 5 mm from
the left and right edges (standard size).
Printing assurance area (cut sheet)
Area excluding 20 mm from the top, 23 mm from the bottom (20 mm
when fed from the cassette), and 5 mm from the left and right edges
(standard size).
USB2.0, Ethernet, IEEE1394 (option)
Printhead and separate ink tanks
[PF-01] Number nozzles: 2560 nozzles per color
[PFI-102]MBK,BK,GY,PGY,R,G,B,C,M,Y,PC,PM
Capacity: 130 ml per color (Ink tanks supplied with the printer contain
90 ml of each color.)
Detects opening/closing of the top cover and ink cover.
Detects presence/absence of ink tank, ink level, presence/absence of the
maintenance cartridge, waste ink full level, presence/absence of the
printhead, and opening/closing of the supply valve.
Detects the ambient temperature, head temperature, presence/absence of
the head, and no ink ejection.
0013-0610
